KoamTac KBM-XP67 User Manual

Xpand 1d laser barcode scanner
Hide thumbs

Advertisement

Quick Links

Download this manual
67
KBM-XP
1
XPAND
D LASER BARCODE SCANNER
USER GUIDE
6
7
SONIM XP
& XP
1
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the KBM-XP67 and is the answer not in the manual?

Questions and answers

Related Manuals for KoamTac KBM-XP67

Summary of Contents for KoamTac KBM-XP67

  • Page 1 KBM-XP XPAND D LASER BARCODE SCANNER USER GUIDE SONIM XP & XP English...
  • Page 2 Data Process - Termination Character & Duplicate What is in the Box? Check KBM-XP67 Barcode Scanner Components System Installation———————— 6 Sleep Timeout Installing the KOAMTAC KBM-XP67 Barcode Scanner XPand Barcode Scanner Application Function Downloading Numbers About the User Guide Lower Case Alphabets Upper Case Alphabets Scanning————————...
  • Page 3 © 2016 KOAMTAC, Inc. and Sonim Technologies, Inc. Copyright 2016 KOAMTAC, Inc. © All rights reserved. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from KOAMTAC , Inc.
  • Page 4 Child Safety Disposal of Old Electrical Equipment Keep out of reach of children. Do not allow children The symbol of the crossed-out wheeled to play with mobile phones or accessories as there is bin indicates that this product, and any potential to harm themselves and/or others.

  • Page 5: Front View

    What is in the Box? * XPand Interface The following items are included in the box: Connector • KOAMTAC KBM-XP67 1D Laser Barcode Scanner • Assembly for BarBridge for XP6 (BarBridge for XP6 + Screws 2ea) Screws A - Back •...
  • Page 6 Installing the KOAMTAC KBM-XP67 Barcode Scanner Using the multi-tool screwdriver, attach the Follow the instructions for installing the KBM-XP67 KBM-XP67 Barcode Barcode Scanner on the compatible XP6 or XP7 phone. Scanner to the back of phone with Screws A. Unscrew the top two...
  • Page 7 About the User Guide This user guide provides instructions and screenshots for the KBM-XP67 Barcode Scanner when used with the XP7 phone. Most instructions apply to KBM-XP67 Barcode Scanner when used with the XP6 phone, as well, except the path the access the Settings or Options menu on the XP6 is different from the XP7.
  • Page 8 Initiating the Scan Changing Continuous Scan Options From the application menu on the phone, select XPand To access Settings, select Options ( ) on the Scanner icon ( XPand Barcode Scanner Application main screen. ) and the application start screen will appear: Select Settings >...
  • Page 9 Sonim Protect Notification Bar When the Sonim Protect application is installed on a On the notification bar, the Sonim Protect icon ( ) and device, the yellow key will not initiate a barcode scan. the XPand Barcode Scanner icon ( ) are displayed.
  • Page 10 Changing Default Vibrate Alert (Unsuccessful): Select the notification tone played for an unsuccessful scan. Select the tone and press OK. KBM-XP67 Barcode Scanner Disconnection If a scan is initiated while the KBM-XP Barcode Scanner is not connected to the phone, a unsuccessful scan alert tone will be play.
  • Page 11 Floating Widget Advanced Settings The Floating widget will appear at the top of the phone To access Advanced Settings, select Options ( ) on screen. It acts as an alternative yellow key, initiating a the XPand Barcode Scanner Application main screen. single or continuous scan.
  • Page 12 Data Transmission To access Settings, select Options ( ) on the XPand Barcode Scanner Application main screen. Select Settings > Data Transmit Options. By default, the minimum scan length is set to 4. The following 2 options are provided in the Settings: •...
  • Page 13 Power Management To access Settings, select Options ( ) on the KBM-XP67 Barcode Scanner Application main screen. Select Settings > Scanner Settings. Idle Time: When an Idle Time is selected, the XPand Barcode Scanner will shutdown when unused for the amount of Idle Time selected. The Idle Time options are: Never, 5, 10, 30, and 60 minutes.

  • Page 14: Corporate Headquarters

    KOAMTAC Contact Information CORPORATE HEADQUARTERS 116 Village Blvd, Suite 305 Princeton, NJ 08540, USA Phone: 609-256-4700, Fax: 609-228-4373 Email: support@koamtac.com For more information, visit www.koamtac.com SONIM Contact Information CORPORATE HEADQUARTERS 1825 S.Grant Street Suite 200 San Mateo, CA 94402, USA...
  • Page 15 You can configure KBM-XP67 by scanning the special Enable ITF14 Disable ITF14 barcodes listed below under the respective categories. Set Symbologies Enable EAN13 Disable EAN13 Enable Code128 Disable Code128 Enable EAN8 Disable EAN8 Enable I2 of 5 Disable I2 of 5...
  • Page 16 Enable Code35 Disable Code35 Enable GS1 Omni Disable GS1 Omni Enable Bookland EAN Disable Bookland EAN Enable GS1 Limited Disable GS1 Limited Enable EAN13 with Disable EAN13 with Addon Addon Enable GS1 Expanded Disable GS1 Expanded Enable EAN8 with Addon Disable EAN8 with Addon Barcode Options...
  • Page 17 Convert EAN8 to Do NOT Convert EAN8 to Verify check digit for Do NOT verify check digit EAN13 EAN13 I2of5 for I2of5 Verify check digit for Do NOT verify check digit Convert UPCE to Do NOT convert UPCE to Code39 for Code39 EAN13 EAN13...
  • Page 18 Scan Options Return check digit for Do NOT return check digit UPCA for UPCA Wide Scan Angle Narrow Scan Angle Return check digit for Do NOT return check digit Normal Filter Mode High Filter Mode EAN8 for EAN8 Enable Auto Trigger Disable Auto Trigger Return check digit for Do NOT return check digit...
  • Page 19 Reread Delay = Extra Scan Timeout = 8sec Scan Timeout = 9sec Long Scan Timeout = 10sec Scan Timeout Scan Timeout = Scan Timeout = 1sec 500msec Minimum Barcode Length Scan Timeout = 2sec Scan Timeout = 3sec Minimum Length = 2 Minimum Length = 3 Scan Timeout = 4sec Scan Timeout = 5sec...
  • Page 20 Minimum Length = 6 Minimum Length = 7 Minimum Length = 16 Minimum Length = 17 Minimum Length = 8 Minimum Length = 9 Minimum Length = 18 Minimum Length = 19 Minimum Length = 10 Minimum Length = 11 Minimum Length = 20 Minimum Length = 21 Minimum Length = 12...
  • Page 21 Minimum Length = 26 Minimum Length = 27 Minimum Length = 36 Minimum Length = 28 Minimum Length = 29 Security Level Security level = 1 Security level = 2 Minimum Length = 30 Minimum Length = 31 Security level = 3 Security level = 4 Minimum Length = 32 Minimum Length = 33...
  • Page 22 Store Only AIM ID In Suffix Data Process - Data Edit Data Process - Data Format & Handshake Start Prefix Enter Start Suffix Enter Data format = Data format = Packet data Barcode only Finish Prefix/Suffix Cancel Prefix/Suffix Enter Enter Data Process - Termination Character &...
  • Page 23 Termination Character Factory Default KDC Reset = Tab Enable Duplicate Disable Duplicate Check Sleep Timeout Check Sleep Timeout = Sleep Timeout = 1sec Disable System Erase Memory Sleep Timeout = 2sec Sleep Timeout = 3sec Enable Auto Erase Disable Auto Erase Sleep Timeout = 4sec Sleep Timeout = 5sec...
  • Page 24 Sleep Timeout = Sleep Timeout = 20sec 10sec Enable Reverse Disable Reverse Direction Direction Sleep Timeout = Sleep Timeout = 1min 30sec Enable Verify check Disable Verify check digit digit Sleep Timeout = 2min Sleep Timeout = 5min Enable Return check Disable Return check digit digit Sleep Timeout =...
  • Page 25 Numbers...
  • Page 26 Lower Case Alphabets...
  • Page 27 Upper Case Alphabets...
  • Page 29 Control Character Shift + Tab Symbol Character “ Space &...
  • Page 30 ‘ < >...
  • Page 31 • The string should be composed by scanning the Start-String”, number/alphabet/special characters, and “Stop-String” special barcodes. • The KBM-XP67 will abort string composition if the user do not scan “Stop-String” in one minute after scanning Start-String and number/alphabet/special characters.
