Page 1: Instruction Manual
INSTRUCTION MANUAL This instruction manual applies to machines from the following serial numbers onwards: # 2 771 790 296-12-19 139/002 Betriebsanleitung engl. 10.12... - Page 2 As an alternative to the internet download the adjustment manual can also be ordered in book form under part no. 296-12-19 140/002. The reprinting, copying or translation of PFAFF Instruction Manuals, whether in whole or in part, is only permitted with our previous authorization and with written reference to the source.
-
Page 3: Table Of Contents
Specialist personnel ....................... 7 Danger warnings ........................8 Proper use..........................9 Specifi cations ........................10 PFAFF 581, PFAFF 583 ......................10 Versions and subclasses ...................... 11 Disposal of Machine ......................12 Transportation, packing and storage ................13 Transportation to customer‘s premises ................13 Transportation inside the customer‘s premises .............. - Page 4 Mounting the table top (with PicoDrive and control unit P41 PD2 ........35 Block diagram ........................36 PFAFF 581 + 583 with MD-4-58-220-CE ................36 PFAFF 581 + 583 with PicoDrive and control unit P41 PD2 ..........37 Wearing parts ........................38...
-
Page 5: Safety
Safety Safety Directives The machine has been constructed in accordance with the requirements listed in the EC Declaration of Conformity and the Declaration of Incorporation. In addition to this Instruction Manual, also observe all generally accepted, statutory and other regulations and legal requirements and all valid environmental protection regulations! The regionally valid regulations of the social insurance society for occupational accidents or other supervisory organizations are to be strictly adhered to! General notes on safety... -
Page 6: Safety Symbols
● It is the obligation of the user to ensure that none of the safety mechanisms are removed or deactivated. ● It is the obligation of the user to ensure that only authorized persons operate and work on the machine. Further information can be obtained from your PFAFF agent. -
Page 7: Operating And Specialist Personnel
Safety Operating and specialist personnel Operating personnel .05.01 Operating personnel are persons responsible for the equipping, operating and cleaning of the machine as well as for taking care of problems arising in the sewing area. The operating personnel is required to observe the following points and must: ●... -
Page 8: Danger Warnings
Safety Danger warnings A working area of 1 m must be kept free both in front of and behind the machi- ne, so that easy access is possible at all times. Never put your hands or fi ngers in the sewing area during sewing! Danger of injury by the needle! While setting or adjusting the machine do not leave any objects on the table nor in the needle plate area! Objects may be trapped or fl... -
Page 9: Proper Use
Proper use The PFAFF 581 is an single-needle ultra-high-speed seamer with compound feed The PFAFF 583 is an single-needle ultra-high-speed seamer with drop feed These machines are used in the industry for sewing lockstitch seams. Any and all uses of this machine which have not been approved of by the... -
Page 10: Specifi Cations
Specifi cation Specifi cations PFAFF 581, PFAFF 583 Stitch type: ......................301 ( lockstitch ) Needle system: ........................134 Needle size in 1/100 mm: Version A: ........................60 - 70 Version B: ........................80 - 100 Version C: ........................110 - 140 Fabric clearance: ......................9 - 13 mm... -
Page 11: Versions And Subclasses
Specifi cation Versions and subclasses Version A: ...................for sewing light materials Version B: ..................for sewing medium materials Version C: ................for sewing medium-heavy materials Work aids: Subclass -900/....................thread trimmer Subclass -909/....................Thread trapper Subclass -910/....................automatic foot lift Subclass -911/.. -
Page 12: Disposal Of Machine
Disposal of Machine Disposal of Machine ● Proper disposal of the machine is the responsibility of the customer. ● The materials used for the machine are steel, aluminium, brass and various plastic materials. The electrical equipment comprises plastic materials and copper. ●... -
Page 13: Transportation, Packing And Storage
Transportation, packing and storage Transportation, packing and storage Transportation to customer‘s premises The machines are delivered completely packed. Transportation inside the customer‘s premises The manufacturer cannot be made liable for transportation inside the customer‘s premises nor to other operating locations. It must be ensured that the machines are only transported in an upright position. -
Page 14: Explanation Of Symbols
Explanation of symbols Explanation of symbols In this instruction manual, work to be carried out or important information is accentuated by symbols. These symbols have the following meanings: Note, information Cleaning, care Lubrication Maintenance, repairs, adjustment, service work (only to be carried out by technical staff) -
Page 15: Controls
Controls Controls On/off switch ● The power supply to the machine is switched on or off by turning switch 1. Fig. 7 - 01 Pedal ● With the on/off switch on = Machine stop +1 = Sew - 1 = Raise presser foot (for machines with -910/..) - 2 = Trim thread (for machines with -900/..) -
Page 16: Raising The Presser Foot
Controls Raising the presser foot Fig. 7 - 03 Fig. 7 - 03a Feed regulator disk / Reverse feed lever Fig. 7 - 04... -
Page 17: Keys On The Machine Head (Only For Machines With -911
Controls Keys on the machine head (only for machines with -911/..) ● As long as key 1 is pressed during sew- ing, the machine sews in reverse. Fig. 7 - 05 Control panel The description can be found in the separate instruction manual for the motor. -
Page 18: Installation And Commissioning
Installation and commissioning Installation and commissioning The machine must only be mounted and commissioned by qualifi ed personnel! All relevant safety regulations are to be observed! If the machine is delivered without a table, it must be ensured that the frame and the table top which you intend to use can hold the weight of the machine and the motor. -
Page 19: Assemble The Mounted Motor
Installation and commissioning Assemble the mounted motor .01.02 Fig. 8 - 02 ● Fix bearing plate 1 on to motor 2 using screws 3, as shown in fi g. 8-02. ● Mount drive belt wheel 4 onto motor shaft and attach with screws 5. ●... -
Page 20: Mounting The Sewing Head
Installation and commissioning Mounting the sewing head .01.04 ● Attach the hinges 1 with two screws each in the relevant bore holes on the base plate. ● Insert the sewing head with hinges 1 into the rear rubber pads. Fig. 8 - 04 Mount upper machine cover .01.05 ●... -
Page 21: Mounting The Spool Holder
Installation and commissioning Mounting the spool holder .01.06 ● Mount the spool holder as shown in Fig. 8-08. ● Insert the spool holder into the hole in the table top and fasten it with the nuts enclosed. Fig. 8 - 06 Connecting the plug-in connections and earth cables Fig. -
Page 22: Commissioning The Machine
Installation and commissioning Commissioning the machine ● Check machine and in particular electric lines for damage before fi rst commissioning. ● Remove pin 1 of the oil reservoir 2 (Fig. 8 - 08). The pin serves only to protect the machine from damage during transport and must not be used when sewing. -
Page 23: Basic Position Of The Machine Drive Unit
Installation and commissioning Basic position of the machine drive unit On machines with PicoDrive and control unit P41 PD2 .05.01 ● Switch on the machine. ● Call up the parameter input by pressing the "scroll" key. ● To switch the function keys to input (LED in the TE key lights up), press the TE key. ●... -
Page 24: Mount And Connect Approach Barrier
Installation and commissioning Mount and connect approach barrier Fig. 8 - 09 ● For machines delivered without table, plate 1 (included in the accessories) must be mounted underneath the table top in such a way that the switching plate 2 is fl ush with plate 1 when the sewing head is tilted upright. -
Page 25: Preparation
Preparation Preparation All regulations and instructions in this Instruction Manual are to be observed! Special attention is to be paid to the safety regulations! All preparation work is only to be carried out by appropriately trained personnel. Before all preparation work, the machine is to be separated from the electricity supply by removing the plug from the mains or switching off the On/Off switch! Inserting the needle Switch off the machine! -
Page 26: Winding The Bobbin Thread, Adjusting The Thread Tension
Preparation Winding the bobbin thread, adjusting the thread tension Fig. 9 - 02 ● Place an empty bobbin 1 onto bobbin shaft 2. ● Thread the bobbin in accordance with Fig. 9-02 and wind it clockwise around bobbin 1 a few times. ●... -
Page 27: Removing / Inserting The Bobbin Case
Preparation Removing / Inserting the bobbin case Switch off the machine! Danger of injury due to uninten- tional starting of the machine! Removing the bobbin case: ● Tilt back the machine. ● Raise latch 1 and remove bobbin case 2. Inserting the bobbin case: ●... -
Page 28: Threading The Needle Thread / Adjusting The Needle Thread Tension
Preparation Threading the needle thread / Adjusting the needle thread tension Fig. 9 - 05 Switch off the machine! Danger of injury due to unintentional starting of the machine! ● Thread the machine as shown in Fig. 9-05. ● Adjust the needle thread tension by turning disk 1. -
Page 29: Care And Maintenance
Care and maintenance Care and maintenance Servicing and maintenance intervals Clean the hook compartment ........Daily, several times if in continuous use Clean the entire machine ..................once a week Check oil level ....................once a month These maintenance intervals are calculated for the average running time of a single shift operation. -
Page 30: Topping Up The Oil Tank
Only use oil with a mean viscosity of 22.0 mm /s at 40°C and a density of 0.865 g/cm 15°C. Fig. 10- 02 We recommend PFAFF sewing machine oil, part no. 280-1-120 144. -
Page 31: Parameter Settings
Care and maintenance Parameter settings Parameter settings are described in the separate operations manual for the drive, and may only be changed by qualifi ed technicians! Parameter list for PicoDrive with control unit P41 PD2 .04.01 Speed for start backtackl B, C 300 - 2000 1400... -
Page 32: Parameter List For Drive System Md-4-58-220-Ce
0 - 359° 20° Switch off angle for thread trapper 0 - 359° 90° Machine version 0 - 4 2 = 581 + 583 See Chapter 3 Specifi cations Adjustment see Chapter 8.05 Basic position of the machine drive unit. -
Page 33: Mounting The Table Top
Mounting the table top Mounting the table top Table top cutout 906-4001-155 Vers. 24.03.10... -
Page 34: Mounting The Table Top (With Drive System Md-4-58-220-Ce)
Mounting the table top Mounting the table top (with drive system MD-4-58-220-CE) 91-265 438-95 Vers. 24.03.10... -
Page 35: Mounting The Table Top
Mounting the table top Mounting the table top (with PicoDrive and control unit P41 PD2 91-265 453-95 Vers. 12.04.10... -
Page 36: Block Diagram
Block diagram Block diagram PFAFF 581 + 583 with MD-4-58-220-CE Control panel C 200 - 1.0 Speedcontrolunit Control unit MD-4-58-220-CE power switch Mains plug... -
Page 37: Pfaff 581 + 583 With Picodrive And Control Unit P41 Pd2
Block diagram PFAFF 581 + 583 with PicoDrive and control unit P41 PD2 BDF - PICO TOP Speedcontrolunit software download Control unit P40 PD power switch Mains plug... -
Page 38: Wearing Parts
A detailed parts list for the complete machine is included with the accessories. In case of loss, the parts list can be downloaded from the internet address www.pfaff-industrial.com/pfaff/de/service/downloads As an alternative to the internet download the parts lists can also be ordered in book form under part no. - Page 39 Wearing parts 99-137 151-45 91-171 049-05 91-171 042-05 95-774 464-05 91-700 996-15 Unterklasse -900/.. 11-330 166-15 (2x) 11-317 001-15 91-168 498-15 91-265 407-01 91-700 249-15 95-721 193-91 11-174 089-15...
