Summary of Contents for Viglen VIG820S

  • Page 1 Vig820S Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
  • Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters. We have made every effort to guarantee that each computer leaving our factory complies fully with the correct standards.
  • Page 3 International Business Machines Corporation. Core i3/i5/i7 Pentium® are registered trademarks of Intel® Corporation. All other trademarks are acknowledged. Genie, Vig, Viglen, and Omnino are trademarks of Viglen Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.
  • Page 4: Table Of Contents

    Chapter 3: Solving Problems Resetting the System Troubleshooting Procedures Problems & Suggestions Chapter 4: System BIOS What is the BIOS? The Power-On Sequence Managing and Updating BIOS BIOS Setup Windows 8/8.1 BIOS Setting Chapter 5: Suggestions V1.0 Vig820S Motherboard Manual...
  • Page 5: Chapter 1: Motherboard Overview

    Chapter 1: Motherboard Overview Introduction This manual describes the Viglen Vig820S motherboard inside your computer. The motherboard is the most important part of your computer. It contains the CPU, memory and graphics circuitry that make the computer work in the correct manner.
  • Page 6: Feature Summary

    1x Realtek GbE LAN chip (10/100/1000 Mbits/s)  1x Intel GbE LAN chip (10/100/1000 Mbits/s) Rear I/O Ports  1 x 12V-19V Power Port  1x HDMI  2x Gigabit LAN  1x Microphone  1x Headphone/Speaker  4x USB 3.0 Ports V1.0 Vig820S Motherboard Manual...
  • Page 7  1x Flat Panel Display Switch Header  1x WIFI activity Indicator LED Header  1x Clear CMOS Jumper Expansion Capabilities  1x mini PCIE full card slot  1x mini PCIE half card slot BIOS  AMI EFI BIOS V1.0 Vig820S Motherboard Manual...
  • Page 8 If non-SPD memory is installed, the BIOS will attempt to correctly configure the memory settings, but performance and reliability may be impacted or the SO-DIMMs may not function under the determined frequency. V1.0 Vig820S Motherboard Manual...
  • Page 9 8 full range channels at 24-bit/96kHz audio of lossless audio formats such as Dolby TrueHD or DTS HD Master Audio. The maximum supported resolution is 4096x2160. The HDMI port is compliant with the HDMI 1.3 specification. V1.0 Vig820S Motherboard Manual...
  • Page 10: Audio Subsystem

    Figure 1: Audio Connectors  Line-Out (Green) - Line Out, is a connector for speakers or headphones.  Mic (Pink) - Mic, is a connector for microphones. V1.0 Vig820S Motherboard Manual...
  • Page 11: Lan Subsystem

    Link Green LAN activity is occurring. LAN link is established. Blinking LAN activity is occurring. Data Green/yellow 10 Mb/s data rate is selected. rate 100 Mb/s data rate is selected. 1000 Mb/s data rate is selected. V1.0 Vig820S Motherboard Manual...
  • Page 12 POST. When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one. V1.0 Vig820S Motherboard Manual...
  • Page 13 If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer. V1.0 Vig820S Motherboard Manual...
  • Page 14: System Board Components

    Intel ME jumper Display panel connector Front panel audio connector Embedded DisplayPort (30-pin eDP) Internal stereo speaker header LVDS connector (30-pin LVDS) Custom header Flat panel display brightness connector RTC Battery header Display panel backlight power selector V1.0 Vig820S Motherboard Manual...
  • Page 15: Back Panel Connectors

    These audio connectors are used for audio devices (MIC-IN, LINE-OUT). Note: The back panel audio line out connectors is designed to power headphones or amplified speakers only. Poor audio quality occurs if passive (non-amplified) speakers are connected to this output. V1.0 Vig820S Motherboard Manual...
  • Page 16: Chapter 2: System Board Options

    Chapter 2: System Board Options The Vig820S motherboard is capable of accepting Intel® Core i3, i5, i7 processors and Intel Pentium processors. RAM can be upgraded to a maximum of 16GB using DDR3 1333MHz or 1600MHz Non ECC Unbuffered memory.
  • Page 17: Before You Begin

    BEFORE YOU BEGIN Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.
  • Page 18: System Board Jumper Settings

    RAM onboard has a power supply from an external battery to keep the data of the system configuration. The CMOS RAM allows the system to automatically boot OS every time it is turned on. Figure 5: Clear CMOS jumper V1.0 Vig820S Motherboard Manual...
  • Page 19: Motherboard Connectors

    50 ms to signal the power supply to switch on or off. (The time Power Switch Header requirement is due to internal debounce circuitry on the board.) At least two seconds must pass before the power supply will recognize another on/off signal. V1.0 Vig820S Motherboard Manual...
  • Page 20 DC connector is compatible with a 7.4 mm/OD (outer diameter) and 5.1 mm/ID (inner diameter) plug, where the inner contact is +19 (±10%) V DC and the shell is GND. The maximum current rating is 12 A. V1.0 Vig820S Motherboard Manual...
  • Page 21 Signal Name Signal Name [Port 1] Left channel Ground [Port 1] Right channel PRESENCE# (Dongle present) [Port 2] Right channel [Port 1] SENSE_RETURN SENSE_SEND (Jack detection) Key (no pin) [Port 2] Left channel [Port 2] SENSE_RETURN V1.0 Vig820S Motherboard Manual...
  • Page 22 USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Figure 9: Front USB connectors Front USB Connector: USB20_5 Figure 10: Front USB connector - single    V1.0 Vig820S Motherboard Manual...
  • Page 23 CPU fan control. Figure 11: Fan Power connectors Table 5: System FAN header, CPU FAN header 4-Wire support 3-Wire support +12V power +12V power FAN_FB FAN_PWM Control V1.0 Vig820S Motherboard Manual...
  • Page 24 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Figure 12: Serial ATA Connector NOTE: Please do not fold the serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission. V1.0 Vig820S Motherboard Manual...
  • Page 25: Upgrading The Cpu

    2. Rotate the socket lever to lift the load plate away from the socket (Figure 14, A). Make sure that the load plate is in the fully open position (Figure 14, B) while being careful not to damage adjacent components. Do not touch the socket contacts. Figure 14: Lift the load plate V1.0 Vig820S Motherboard Manual...
  • Page 26 B) and that the notches on the processor align with the posts on the socket (Figure 16, C). Lower the processor straight down without tilting or sliding it in the socket (Figure 16, A). Figure 16: Install the processor V1.0 Vig820S Motherboard Manual...
  • Page 27 (Figure 17, C, and D). The socket cover (Figure 17, B) will pop off as shown. Figure 17: Secure the load plate in place 6. Pick up the socket cover and remove it from the desktop board. V1.0 Vig820S Motherboard Manual...
  • Page 28 Make sure the four hooks are in the proper position before you install the cooler. If the heatsink is held in by screws, position heatsink correctly and screw into place. Figure 18: Connecting the processor fan heat sink power cable to the processor fan header V1.0 Vig820S Motherboard Manual...
  • Page 29: Installing & Removing Memory Modules

    5. When the SO-DIMM is seated, push down until the retaining arms at either ends of the socket snap into place. Make sure the clips are firmly in place. 6. Replace the computer cover. Figure 19: Memory Installation V1.0 Vig820S Motherboard Manual...
  • Page 30 Hold the SO-DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the SO- DIMM sockets. Figure 20: Removing Memory Modules V1.0 Vig820S Motherboard Manual...
  • Page 31: Replacing The Clock/Cmos Ram Battery

    CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. To replace the battery, carry out the following: 1.
  • Page 32: Chapter 3: Solving Problems

    The second part lists error code messages that might be displayed. Please remember that if you cannot solve the problem by yourself then you should contact Viglen Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 01727 201 850 Fax:...
  • Page 33: Troubleshooting Procedures

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. V1.0 Vig820S Motherboard Manual...
  • Page 34: Problems & Suggestions

    Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed. Make sure a video board is installed, enabled, and the jumpers are positioned correctly. Reboot the system. V1.0 Vig820S Motherboard Manual...
  • Page 35 System halts before This indicates a fatal system error that requires immediate service attention. Note the screen display and write down any beep code completing POST emitted. Provide this information to your dealer service department / Technical Support. V1.0 Vig820S Motherboard Manual...
  • Page 36: Chapter 4: System Bios

    (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by American Megatrends Inc, an industrial leader in the field of BIOS software.
  • Page 37: Managing And Updating Bios

    4.3 Managing and Updating BIOS There are up three methods of updating BIOS to the latest Viglen approved version. The number of options made available for any particular board may vary depending on BIOS Support, drive support and BIOS update file size. You only need to use one.
  • Page 38 Load Optimized Defaults item under the Exit menu. . IMPORTANT!!!!! During the update process DO NOT shut down the PC or interrupt the process, this could cause damage to the motherboard. Figure 22: EZ Flash BIOS update screen V1.0 Vig820S Motherboard Manual...
  • Page 39 4. The system requires you to enter BIOS Setup to recover BIOS settings. To ensure system compatibility and stability, we recommend that you press <F5> to load default BIOS values. DO NOT shut down or reset the system while updating the BIOS! Doing so can cause boot system failure! V1.0 Vig820S Motherboard Manual...
  • Page 40: Bios Setup

    OFF and On or pressing the RESET button. You may also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.  Control Keys Figure 23: BIOS control keys After entering the BIOS, the first screen you will see is the Main Menu – EZ Mode V1.0 Vig820S Motherboard Manual...
  • Page 41 Figure 24: BIOS Main Menu – EZ Mode • The boot device options vary depending on the devices you installed to the system. • The Boot Menu (F8) button is available only when the boot device is installed to the system. V1.0 Vig820S Motherboard Manual...
  • Page 42 BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. Figure 25: BIOS Main Menu – Advanced Mode BIOS Main Menu selection The menu bar on top of the screen has the following main items: V1.0 Vig820S Motherboard Manual...
  • Page 43 The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items 4.5 My Favourites MyFavorites is your personal space where you can easily save and access your favourite BIOS items. Figure 26: My Favourites Menu V1.0 Vig820S Motherboard Manual...
  • Page 44: Main Menu

    4.6.1 System Language [English] Allows you to choose the BIOS language version from the options. 4.6.2 System Date [Day xx/xx/xxxx] Allows you to set the system date. 4.6.3 System Time [xx:xx:xx] Allows you to set the system time. V1.0 Vig820S Motherboard Manual...
  • Page 45 To clear the user password, follow the same steps as in changing a user password, but press<Enter> when prompted to create/confirm the password. After you clear the password, the User Password item on top of the screen shows Not Installed. V1.0 Vig820S Motherboard Manual...
  • Page 46: Ai Tweaker Menu

    The configuration options for this section vary depending on the CPU and DIMM model installed on the motherboard. Figure 28: Ai Tweaker Menu Scroll down to display the following items: Figure 29: Tweaker Menu V1.0 Vig820S Motherboard Manual...
  • Page 47 (X.M.P.) Technology, choose this item to set the profiles supported by your memory modules for optimizing the system performance. 4.7.2 ASUS MultiCore Enhancement [Auto] [Auto] Default set to [Auto] for maximum performance under XMP/Manual/Userdefinedmemory frequency mode. [Disabled] Allows you to set to default core ratio settings V1.0 Vig820S Motherboard Manual...
  • Page 48 Allows you to set the memory operating frequency. Configuration options: [DDR3-800MHz][DDR3- 1066MHz][DDR3-1333MHz][DDR3-1600MHz][DDR3-1866MHz][DDR3-2133MHz]~[DDR3-3200MHz] 4.7.8 CPU Graphics Max. Ratio [Auto] Allows you to set the CPU Graphics maximum ratio. The maximum ratio is 60x. Use <+>/<-> to adjust the value. V1.0 Vig820S Motherboard Manual...
  • Page 49: Dram Timing Control

    Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock] RTL IOL control DRAM RTL initial Value [Auto] Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock] DRAM RTL (CHA) [Auto] Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock] V1.0 Vig820S Motherboard Manual...
  • Page 50 [Enabled] Enables the MRC fast boot. [Disable] Disables the MRC fast boot. DRAM CLK Period [Auto] Configuration options: [Auto] [1] – [14] Channel A DIMM Control [Enable Bot...] Configuration options: [Enable Both DIMMS] [Disable DIMM0] [Disable DIMM1] [Disable Both DIMMS] V1.0 Vig820S Motherboard Manual...
  • Page 51: Cpu Power Management

    The following first three items appear only when you set the Turbo Mode to [Enabled]. Turbo Mode Parameters Long Duration Package Power Limit [Auto] Allows you to limit the turbo ratio’s long duration package power. Use the <+> and <-> keys to adjust the value. V1.0 Vig820S Motherboard Manual...
  • Page 52 Use the <+> and <-> keys to adjust the value. Power Saving Level 2 Threshhold [Auto] Allows you to set the power saving level 2 threshhold. Use the <+> and <-> keys to adjust the value. V1.0 Vig820S Motherboard Manual...
  • Page 53 This item appears only when you set the CPU Cache Voltage to [Adaptive Mode] and allows you to set the total adaptive mode CPU cache voltage. The values range from 0.001V to 1.920V with a 0.001V interval. V1.0 Vig820S Motherboard Manual...
  • Page 54 Allows you to set the DRAM Voltage. The values range from 1.500V to 1.650V with a 0.050V interval. According to Intel CPU specifications, DIMMs with voltage requirement over 1.65V may damage the CPU permanently. We recommend that you install the DIMMs with the voltage requirement below 1.65V. V1.0 Vig820S Motherboard Manual...
  • Page 55 Allows you to set the DRAM DATA REF Voltage on CHB. The values range from 0.3950V to 0.6300V with a 0.0050V interval 4.7.28 CPU Spread Spectrum [Auto] [Auto] Automatic configuration. [Disabled] Enhances the BCLK overclocking ability. [Enabled] Sets to [Enabled] for EMI control. V1.0 Vig820S Motherboard Manual...
  • Page 56: Trusted Computing

    The items shown in submenu may be different due to the CPU you installed. Intel® Adaptive Thermal Monitor [Enabled] [Enabled] Enables the overheated CPU to throttle its clock speed to cool down. [Disabled] Disables the CPU thermal monitor function. V1.0 Vig820S Motherboard Manual...
  • Page 57 Allows you to set the processor cores to run faster than the marked frequency in a specific condition. Configuration options: [Enabled] [Disabled] Turbo Mode is only available on selected CPU models only. CPU C states [Auto] [Auto] Automatic configuration. [Enabled] Enables the CPU C states. [Disabled] Disables the CPU C states. V1.0 Vig820S Motherboard Manual...
  • Page 58: Pch Configuration

    Allows you to set the wake-up time. The values range from 0 (immediately) to 120. Active Page Threshold Support [Enabled] The system automatically set itself to sleep when the partition size is not enough for Rapid Start Technology to work. Configuration options: [Enabled] [Disabled] V1.0 Vig820S Motherboard Manual...
  • Page 59 CPU Audio Devices [Enabled] Allows you to enable or disable CPU SA Audio devices. Configuration options: [Enabled] [Disabled] DVI Port Audio [Disabled] Allows you to enable or disable the DVI port. Configuration options: [Enabled] [Disabled] Graphics Configuration V1.0 Vig820S Motherboard Manual...
  • Page 60: Amt Configuration

    Allow you to enable or disable the Intel® Active Management Technology (AMT) in the BIOS extension. Configuration options: [Enabled] [Disabled] • iAMT H/W is always enabled. This option just controls the BIOS extension execution. If enabled, this requires additional firmware in the SPI device. V1.0 Vig820S Motherboard Manual...
  • Page 61: Usb Configuration

    [Disabled]. USB_3~6, 9~12 [Enabled] Allows you to enable or disable an individual USB port. Refer to the section 1.2.3 Motherboard layout in this user manual for the locations of the USB ports. Configuration options: [Enabled] [Disabled]. V1.0 Vig820S Motherboard Manual...
  • Page 62: Platform Misc Configuration

    Disables the controller. Intel PXE OPROM [Disabled] This item appears only when you set the previous item to [Enabled] and allows you to enable or disable the PXE OptionRom of the Intel LAN controller. Configuration options: [Enabled][Disabled] V1.0 Vig820S Motherboard Manual...
  • Page 63 Power On By PS/2 Mouse [Disabled] [Disabled] Disables the Power On by a PS/2 mouse. [Enabled] Enables the Power On by a PS/2 mouse. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. V1.0 Vig820S Motherboard Manual...
  • Page 64: Network Stack

    This item allows user to disable or enable the Ipv4 PXE Boot support. Configuration options: [Disable Link] [Enabled] Ipv6 PXE Support [Enabled] This item allows user to disable or enable the Ipv6 PXE Boot support. Configuration options: [Disable Link] [Enabled] V1.0 Vig820S Motherboard Manual...
  • Page 65: Monitor Menu

    4.9 Monitor Menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. Figure 32: Monitor Menu Scroll down to display the following items: Figure 33: Monitor Menu V1.0 Vig820S Motherboard Manual...
  • Page 66 Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values range from 20% to 100%. When the CPU temperature is under the lower limit, the CPU fan will operate at the minimum duty cycle. V1.0 Vig820S Motherboard Manual...
  • Page 67 Sets to [Turbo] to achieve maximum chassis fan speed. [Manual] Sets to [Manual] to assign detailed fan speed control parameters. 4.9.6 Anti-Surge Support This item allows you to enable or disable the Anti-Surge function. Configuration options: [Disabled] [Enabled] V1.0 Vig820S Motherboard Manual...
  • Page 68: Boot Menu

    4.10 Boot Menu The Boot menu items allow you to change the system boot options. Figure 34: Boot Menu Scroll down to display the following items: Figure 357: Boot Menu V1.0 Vig820S Motherboard Manual...
  • Page 69 Post Report [5 sec] This item appears only when you set Boot Logo Display to [Disabled]. This item allows you to select a desired post report waiting time. Configuration options: [1 sec] ~ [10 sec] [Until Press ESC]. V1.0 Vig820S Motherboard Manual...
  • Page 70 Boot from Storage Devices [Legacy OpR...] Allows you to select the type of storage devices that you want to launch. Configuration options: [Both, Legacy OpROM first] [Both, UEFI first] [Legacy OpROM first] [UEFI driver first] [Ignore] V1.0 Vig820S Motherboard Manual...
  • Page 71: Secure Boot

    Append KEK from file Allows you to load the additional KEK from a storage device for an additional db and dbx loaded management. The KEK file must be formatted as a UEFI variable structure with time-based authenticated variable. V1.0 Vig820S Motherboard Manual...
  • Page 72: Boot Option Priorities

    • To select the boot device during system start up, press <F8> when Viglen Logo appears. • To access Windows OS in Safe Mode, do any of the following: •...
  • Page 73: Tool Menu

    Allows you to load/save CMOS profile from/to USB drive. 4.11.3 ASUS SPD Information DIMM Slot Number [DIMM_A1] Displays the Serial Presence Detect (SPD) information of the DIMM module installed on the selected slot. Configuration options: [DIMM_A1] [DIMM_A2] [DIMM_B1] [DIMM_B2] V1.0 Vig820S Motherboard Manual...
  • Page 74: Exit Menu

    This option allows you to enter the EZ Mode screen. Launch EFI Shell from filesystem device This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available devices that have a file system. V1.0 Vig820S Motherboard Manual...
  • Page 75: Windows 8/8.1 Bios Setting

    4.13 BIOS settings for Windows 7 and Windows 8/8.1 O/S 4.13.1 Windows UEFI mode for Windows 8/8.1 Vig820S system configured with Windows 8/8.1 will have following default BIOS settings. If you wish to downgrade to Windows 7 then BIOS must be configured to Non-UEFI mode.
  • Page 76 5. Navigate to Secure Boot from within the Boot sub menu. 6. Change OS Type to Windows UEFI. Figure 40: Secure Boot Menu 7. Select Key Management. 8. Select Install default Secure Boot keys and select Yes to proceed. V1.0 Vig820S Motherboard Manual...
  • Page 77 If you need to check changes have been saved go back into BIOS after reboot and navigate into Secure Boot settings. Check that Secure Boot state is enabled and Platform Key (PK) state is Loaded Figure 42: key management – Key loaded V1.0 Vig820S Motherboard Manual...
  • Page 78 Boot from Network Devices [Legacy OPROM] Boot from Storage Devices [Legacy OPROM] Boot from PCI-E/PCI Expansion Devices [Legacy OPROM] Figure 43: Windows 7 BIOS settings Boot\Secure Boot Menu OS Type [Other Figure 44: Windows 7 BIOS settings V1.0 Vig820S Motherboard Manual...
  • Page 79 In Windows, open the Control Panel, open Network Connections, and right click the connection and clickProperties. Click TCP/IP and click Properties. • Virtual Local Area Network (VLAN) settings. If a VLAN is set up, the VLAN ID will be needed. V1.0 Vig820S Motherboard Manual...
  • Page 80 Administrator passwords must be between 8 and 32 characters long, have at least one upper case character, one lower case character, one number, and a special character (for example: !, @, #, $, %, ^, &, *). V1.0 Vig820S Motherboard Manual...
  • Page 81 CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. Figure 48: Clear CMOS jumper V1.0 Vig820S Motherboard Manual...
  • Page 82: Chapter 5: Suggestions

    Viglen is interested in continuing to improve the quality and information provided in their manuals. Viglen has listed some questions that you may like to answer and return to Viglen. This will help Viglen help to keep and improve the standard of their manuals.
  • Page 83 Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept. Viglen Ltd. 7 Handley Page Way Colney Street St Albans Hertfordshire AL2 2DQ V1.0 Vig820S Motherboard Manual...
  • Page 84 Notes V1.0 Vig820S Motherboard Manual...
