Viglen vig830s User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Vig830S
Motherboard
Manual
.
.
C O M P U T E R S
N E T W O R K S
S O L U T I O N S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the vig830s and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viglen vig830s

Summary of Contents for Viglen vig830s

  • Page 1 Vig830S Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
  • Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters. We have made every effort to guarantee that each computer leaving our factory complies fully with the correct standards.
  • Page 3 International Business Machines Corporation. Core i3/i5/i7 Pentium® are registered trademarks of Intel® Corporation. All other trademarks are acknowledged. Genie, Vig, Viglen, and Omnino are trademarks of XMA Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.

  • Page 4: Table Of Contents

    Problems & Suggestions Chapter 4: System BIOS What is the BIOS? The Power-On Sequence Managing and updating BIOS BIOS Setup Program BIOS settings for Windows 7 and Windows 8 O/S Intel® Active Management Technology (AMT) Chapter 5: Suggestions V1.0 Vig830S Motherboard Manual...

  • Page 5: Chapter 1: Motherboard Overview

    10/100/1000 network connection, as well as 4 USB 2.0 and 2 USB 3.0 ports to enrich your multimedia creation experience. The Vig830s Motherboard supports 6th generation Intel Core i3, i5, and i7 processors, as well as being Microsoft Windows 7, 8.1 and Windows 10 WHQL certified.

  • Page 6: Feature Summary

    Support Intel® InTruTM 3D, Quick Sync Video, Intel® Clear Video HD Technology, and Intel® InsiderTM Audio  Realtek® ALC887-VD 8-Channel High Definition Audio CODEC o Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, Anti-pop Function  Intel® I219LM Gigabit Ethernet Controller V1.0 Vig830S Motherboard Manual...
  • Page 7  1 x D-Sub port  1 x HDMI port  1 x DisplayPort  1 x LAN (RJ-45) port  2 x USB 2.0/1.1 ports  6 x USB 3.0/2.0 ports  3 x Audio jacks V1.0 Vig830S Motherboard Manual...
  • Page 8 (DIMM) sockets. A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. Figure 2: Vig830S DDR4 DIMM Sockets You may install 2GB, 4GB, and 8GB and 16GB unbuffered non‑ ECC DDR4 DIMMs into the DIMM sockets.
  • Page 9 This mode is used when only a single DIMM is installed or the memory capacities are unequal. Technology and device width can vary from one channel to the other. If different DIMM speeds are used between channels, the slowest memory timing will be used. V1.0 Vig830S Motherboard Manual...
  • Page 10 16GB/s in each direction, simultaneously, when operating in x16 mode.  Supports PCI Express GEN2 frequency of 2.5 GHz resulting in 5.0 Gb/s each direction (500 MB/s) per lane. Maximum theoretical bandwidth on interface is 8GB/s in each direction, simultaneously, when operating in x16 mode. V1.0 Vig830S Motherboard Manual...

  • Page 11: Audio Subsystem

    Additional features of the LAN subsystem include: • CSMA/CD protocol engine • LAN connect interface between the PCH and the LAN controller • Conventional PCI bus power management • ACPI technology support • LAN wake capabilities • ACPI technology support V1.0 Vig830S Motherboard Manual...
  • Page 12 Computer systems that have an unshielded cable attached to a USB port may not meet FCC Class B requirements, even if no device or a low-speed (sub-channel) USB device is attached to the cable. Use shielded cable that meets the requirements for high-speed (fully rated) devices. V1.0 Vig830S Motherboard Manual...
  • Page 13 RAID capability of the PCH. Expansion Slots The motherboard provides the following expansion capability:  2 x PCI Express 3.0/2.0 x16 (1@ x4 mode)  1 x PCI Express 3.0/2.0 x1 slot  1 x PCI Table 3: IRQ assignment V1.0 Vig830S Motherboard Manual...
  • Page 14 BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a Conventional PCI or PCI Express add-in card. V1.0 Vig830S Motherboard Manual...
  • Page 15 If only the administrator password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer. V1.0 Vig830S Motherboard Manual...

  • Page 16: System Board Components

    USB 3.0 connector (20-1 pin USB3_12, Front panel audio connector (10-1 pin AAFP) USB3_910) Intel® Q170 Serial ATA 6.0Gb/s connector (7-pin Mono out header (2-pin MONO_OUT) SATA6G_1~6 [gray]) Speaker connector (4-pin SPEAKER) LPT connector (26-1 pin LPT) V1.0 Vig830S Motherboard Manual...

  • Page 17: Back Panel Connectors

    HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content. PS/2 keyboard port (purple). This port is for a PS/2 keyboard. V1.0 Vig830S Motherboard Manual...

  • Page 18: Chapter 2: System Board Options

    The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. CAUTION! The Viglen Vig800S motherboard and associated components are sensitive electronic devices. A small static shock from your body can cause expensive damage to your equipment.

  • Page 19: Before You Begin/ Steps To Prevent Static Discharge

    BEFORE YOU BEGIN Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.

  • Page 20: System Board Jumper Settings

    You do not need to clear the RTC when the system hangs due to overclocking. For system failure due to overclocking, use the CPU Parameter Recall (C.P.R.) feature. Shut down and reboot the system, then the BIOS automatically resets parameter settings to default values. V1.0 Vig830S Motherboard Manual...

  • Page 21: Motherboard Connectors

    This connector allows you to connect an ATX 12V 24-pin power supply. To connect the ATX 24-pin power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. Then push down the power supply firmly into the connector. Figure 10: ATX Power Connectors V1.0 Vig830S Motherboard Manual...
  • Page 22 Figure 11: Serial Port Connectors  System panel connector (10-1 pin F_PANEL): These connectors are for electrical connection to the front panel switches and LEDs. Figure 12: Front Panel Connectors V1.0 Vig830S Motherboard Manual...
  • Page 23  Speaker connector (4-pin SPEAKER) The 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. Viglen chassis does not support speaker. Figure 13: Speaker V1.0 Vig830S Motherboard Manual...
  • Page 24 By default, the pin labeled “Chassis Signal” and “Ground” are shorted with a jumper cap. Remove the jumper caps only when you intend to use the chassis intrusion detection feature. Figure 15: Chassis intrusion connector V1.0 Vig830S Motherboard Manual...
  • Page 25 Figure 16: CPU and chassis fan connectors  Intel® Q170 Serial ATA 6.0Gb/s connector (7-pin SATA6G_1~6 [gray]) This connector connects to Serial ATA 6.0 Gb/s hard disk drives via Serial ATA 6.0 Gb/s signal cables. Figure 17: SATA connector V1.0 Vig830S Motherboard Manual...
  • Page 26 These connectors are for USB 2.0 ports. Connect the USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specifications and supports up to 480Mbps connection speed. Figure 19: Front USB2.0 connector V1.0 Vig830S Motherboard Manual...
  • Page 27 This internal mono out header allows connection to an internal, low power speaker for basic system sound capability. The subsystem is capable of driving a speaker load of 4 Ohms at 2 Watts (rms).  Figure 21: MONO_OUT connector V1.0 Vig830S Motherboard Manual...
  • Page 28  Speaker connector (4-pin SPEAKER) The 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you hear system beeps and warnings. Figure 22: Speaker Connector V1.0 Vig830S Motherboard Manual...

  • Page 29: Pci Slots

    When adding or removing expansion cards, always turn off the power supply and unplug the power supply power cable from the power outlet. Read the expansion card’s documentation to check for any necessary additional hardware or software changes. V1.0 Vig830S Motherboard Manual...

  • Page 30: Upgrading The Cpu

    2. Rotate the socket lever to lift the load plate away from the socket (Figure 23, A). Make sure that the load plate is in the fully open position (Figure 23, B) while being careful not to damage adjacent components. Do not touch the socket contacts. Figure 25: Lift the load plate V1.0 Vig830S Motherboard Manual...
  • Page 31 B) and that the notches on the processor align with the posts on the socket (Figure 25, C). Lower the processor straight down without tilting or sliding it in the socket (Figure 25, A). Figure 27: Install the processor V1.0 Vig830S Motherboard Manual...
  • Page 32 (Figure 26, C, and D). The socket cover (Figure 26, B) will pop off as shown. Figure 28: Secure the load plate in place 6. Pick up the socket cover and remove it from the desktop board. V1.0 Vig830S Motherboard Manual...
  • Page 33 Figure 27). A fan with a 4-pin connector as shown in Figure 27 is recommended. 1. Make sure the four hooks are in the proper position before you install the cooler. Figure 29: Connecting the processor fan V1.0 Vig830S Motherboard Manual...

  • Page 34: Installing & Removing Memory Modules

    6. When the DIMM is seated, push down on the top edge of the DIMM until the retaining clips at the ends of the socket snap into place. Make sure the clips are firmly in place. 7. Replace the computer cover. Figure 30: Memory Installation V1.0 Vig830S Motherboard Manual...
  • Page 35 Hold the DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets. Figure 31: Removing Memory Modules V1.0 Vig830S Motherboard Manual...

  • Page 36: Replacing The Clock/Cmos Ram Battery

    CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. To replace the battery, carry out the following: 1.

  • Page 37: Chapter 3: Solving Problems

    The second part lists error code messages that might be displayed. Please remember that if you cannot solve the problem by yourself then you should contact Viglen Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 01727 201 850 Fax:...

  • Page 38: Troubleshooting Procedures

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. V1.0 Vig830S Motherboard Manual...

  • Page 39: Problems & Suggestions

    Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed. Make sure a video board is installed, enabled, and the jumpers are positioned correctly. Reboot the system. V1.0 Vig830S Motherboard Manual...
  • Page 40 System halts before This indicates a fatal system error that requires immediate service completing POST attention. Note the screen display and write down any beep code emitted. Provide this information to your dealer service department / Technical Support. V1.0 Vig830S Motherboard Manual...

  • Page 41: Chapter 4: System Bios

    (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by American Megatrends Inc, an industrial leader in the field of BIOS software.

  • Page 42: Managing And Updating Bios

    4.3 Managing and updating BIOS There are up three methods of updating BIOS to the latest Viglen approved version. The number of options made available for any particular board may vary depending on BIOS Support, drive support and BIOS update file size. You only need to use one.
  • Page 43 Load Optimized Defaults item under the Exit menu. . IMPORTANT!!!!! During the update process DO NOT shut down the PC or interrupt the process, this could cause damage to the motherboard. Figure 33: EZ Flash BIOS update screen V1.0 Vig830S Motherboard Manual...
  • Page 44 4. The system requires you to enter BIOS Setup to recover BIOS settings. To ensure system compatibility and stability, we recommend that you press <F5> to load default BIOS values. DO NOT shut down or reset the system while updating the BIOS! Doing so can cause boot system failure! V1.0 Vig830S Motherboard Manual...

  • Page 45: Bios Setup Program

    OFF and On or pressing the RESET button. You may also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.  Control Keys Figure 34: BIOS control keys After entering the BIOS, the first screen you will see is the Main Menu – EZ Mode V1.0 Vig830S Motherboard Manual...
  • Page 46 Figure 35: BIOS Main Menu – EZ Mode • The boot device options vary depending on the devices you installed to the system. • The Boot Menu (F8) button is available only when the boot device is installed to the system. V1.0 Vig830S Motherboard Manual...
  • Page 47 BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. Figure 36: BIOS Main Menu – Advanced Mode BIOS Main Menu selection The menu bar on top of the screen has the following main items: V1.0 Vig830S Motherboard Manual...
  • Page 48 The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items 4.5 My Favourites MyFavorites is your personal space where you can easily save and access your favourite BIOS items. Figure 37: My Favourites Menu V1.0 Vig830S Motherboard Manual...

  • Page 49: Main Menu

    4.6.1 System Language [English] Allows you to choose the BIOS language version from the options. 4.6.2 System Date [Day xx/xx/xxxx] Allows you to set the system date. 4.6.3 System Time [xx:xx:xx] Allows you to set the system time. V1.0 Vig830S Motherboard Manual...
  • Page 50 To clear the user password, follow the same steps as in changing a user password, but press<Enter> when prompted to create/confirm the password. After you clear the password, the User Password item on top of the screen shows Not Installed. V1.0 Vig830S Motherboard Manual...
  • Page 51 1. Press <F11> on your keyboard or click from the BIOS screen to open EZ Tuning Wizard screen. 2. Click RAID then click Next. • Ensure that your HDDs have no existing RAID volumes. • Ensure to connect your HDDs to Intel® SATA connectors. V1.0 Vig830S Motherboard Manual...
  • Page 52 Figure 41- Storage Function Selection a. For Easy Backup, select from Easy Backup (RAID1) or Easy Backup (RAID10) then click Next. Figure 42- RAID Type You can only select Easy Backup (RAID 10) if you connect four (4) HDDs. V1.0 Vig830S Motherboard Manual...
  • Page 53 Figure 43 – RAID Type 5. After selecting the type of RAID, click Yes to continue the RAID setup. 6. After the RAID setup is done, click Yes to exit the setup then click OK to reset your system. V1.0 Vig830S Motherboard Manual...

  • Page 54: Ai Tweaker Menu

    Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field values can cause the system to malfunction. The configuration options for this section vary depending on the CPU and DIMM model installed on the motherboard. Figure 44: Ai Tweaker Menu V1.0 Vig830S Motherboard Manual...

  • Page 55: Trusted Computing

    The items in this menu show the CPU-related information that the BIOS automatically detects. The items shown in submenu may be different due to the CPU you installed. Intel® Adaptive Thermal Monitor [Enabled] [Enabled] Enables the overheated CPU to throttle its clock speed to cool down. V1.0 Vig830S Motherboard Manual...
  • Page 56 Allows you to set the processor cores to run faster than the marked frequency in a specific condition. Configuration options: [Enabled] [Disabled] Turbo Mode is only available on selected CPU models only. CPU C states [Auto] [Auto] Automatic configuration. [Enabled] Enables the CPU C states. [Disabled] Disables the CPU C states. V1.0 Vig830S Motherboard Manual...

  • Page 57: Pch Configuration

    Entry After [x] Allows you to set the wake-up time. The values range from 0 (immediately) to 120. Active Page Threshold Support [Enabled] The system automatically set itself to sleep when the partition size is not enough for V1.0 Vig830S Motherboard Manual...

  • Page 58: Sata Configuration

    Disables this function. CPU Audio Devices [Enabled] Allows you to enable or disable CPU SA Audio devices. Configuration options: [Enabled] [Disabled] DVI Port Audio [Disabled] Allows you to enable or disable the DVI port. Configuration options: [Enabled] [Disabled] V1.0 Vig830S Motherboard Manual...
  • Page 59 The items in this menu allow you to change the Intel® Active Management Technology (AMT) feature. Intel® AMT [Enabled] Allow you to enable or disable the Intel® Active Management Technology (AMT) in the BIOS extension. Configuration options: [Enabled] [Disabled] V1.0 Vig830S Motherboard Manual...

  • Page 60: Usb Configuration

    [Disabled]. USB_3~6, 9~12 [Enabled] Allows you to enable or disable an individual USB port. Refer to the section 1.2.3 Motherboard layout in this user manual for the locations of the USB ports. Configuration options: [Enabled] [Disabled]. V1.0 Vig830S Motherboard Manual...

  • Page 61: V1.0 Vig830S Motherboard Manual

    Disables the controller. Intel PXE OPROM [Disabled] This item appears only when you set the previous item to [Enabled] and allows you to enable or disable the PXE OptionRom of the Intel LAN controller. Configuration options: [Enabled][Disabled] V1.0 Vig830S Motherboard Manual...
  • Page 62 Power On By PS/2 Mouse [Disabled] [Disabled] Disables the Power On by a PS/2 mouse. [Enabled] Enables the Power On by a PS/2 mouse. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. V1.0 Vig830S Motherboard Manual...

  • Page 63: Network Stack

    This item allows user to disable or enable the Ipv4 PXE Boot support. Configuration options: [Disable Link] [Enabled] Ipv6 PXE Support [Enabled] This item allows user to disable or enable the Ipv6 PXE Boot support. Configuration options: [Disable Link] [Enabled] V1.0 Vig830S Motherboard Manual...

  • Page 64: Monitor Menu

    4. 9 Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. Figure 46- Monitor Menu V1.0 Vig830S Motherboard Manual...

  • Page 65: Boot Menu

    4.10 Boot menu The Boot menu items allow you to change the system boot options. Figure 47: Boot Menu V1.0 Vig830S Motherboard Manual...

  • Page 66: Tools Menu

    4.11 Tools menu The Tools menu items allow you to configure options for special functions. Select an item then press <Enter> to display the submenu. Figure 48: Tool menu V1.0 Vig830S Motherboard Manual...

  • Page 67: Exit Menu

    This option allows you to enter the EZ Mode screen. Launch EFI Shell from filesystem device This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available devices that have a file system. V1.0 Vig830S Motherboard Manual...

  • Page 68: Bios Settings For Windows 7 And Windows 8 O/S

    4.13 BIOS settings for Windows 7 and Windows 8/8.1 O/S 4.13.1 Windows UEFI mode for Windows 8/8.1 Vig830s system configured with Windows 8/8.1 will have following default BIOS settings. If you wish to downgrade to Windows 7 then BIOS must be configured to Non-UEFI mode.
  • Page 69 5. Navigate to Secure Boot from within the Boot sub menu. 6. Change OS Type to Windows UEFI. Figure 52: Secure Boot Menu 7. Select Key Management. 8. Select Install default Secure Boot keys and select Yes to proceed. V1.0 Vig830S Motherboard Manual...
  • Page 70 If you need to check changes have been saved go back into BIOS after reboot and navigate into Secure Boot settings. Check that Secure Boot state is enabled and Platform Key (PK) state is Loaded Figure 54: key management – Key loaded V1.0 Vig830S Motherboard Manual...
  • Page 71 Boot from Network Devices [Legacy OPROM] Boot from Storage Devices [Legacy OPROM] Boot from PCI-E/PCI Expansion Devices [Legacy OPROM] Figure 55: Windows 7 BIOS settings Boot\Secure Boot Menu OS Type [Other Figure 56: Windows 7 BIOS settings V1.0 Vig830S Motherboard Manual...

  • Page 72: Intel® Active Management Technology (Amt)

    In Windows, open the Control Panel, open Network Connections, and right click the connection and clickProperties. Click TCP/IP and click Properties. • Virtual Local Area Network (VLAN) settings. If a VLAN is set up, the VLAN ID will be needed. V1.0 Vig830S Motherboard Manual...
  • Page 73 Administrator passwords must be between 8 and 32 characters long, have at least one upper case character, one lower case character, one number, and a special character (for example: !, @, #, $, %, ^, &, *). V1.0 Vig830S Motherboard Manual...
  • Page 74 CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. Figure 60: Clear CMOS jumper V1.0 Vig830S Motherboard Manual...

  • Page 75: Chapter 5: Suggestions

    XMA has listed some questions that you may like to answer and return to Viglen. This will help Viglen help to keep and improve the standard of their manuals. 1. Is the information provided in this and other manuals clear enough? 2.
  • Page 76 Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept. XMA Ltd. 7 Handley Page Way Colney Street St Albans Hertfordshire AL2 2DQ V1.0 Vig830S Motherboard Manual...
  • Page 77 Notes V1.0 Vig830S Motherboard Manual...
