Vig645M
Motherboard
Manual
.
.
C O M P U T E R S
N E T W O R K S
S O L U T I O N S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vig645M and is the answer not in the manual?

Questions and answers

Summary of Contents for Viglen Vig645M

  • Page 1 Vig645M Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
  • Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters. We have made every effort to guarantee that each computer leaving our factory complies fully with the correct standards.
  • Page 3 International Business Machines Corporation. Core i3/i5/i7 and Pentium® are registered trademarks of Intel® Corporation. All other trademarks are acknowledged. Genie, Vig, Viglen, and Omnino are trademarks of Viglen Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.
  • Page 4: Table Of Contents

    Chapter 3: Solving Problems Resetting the System Troubleshooting Procedures Problems & Suggestions Chapter 4: System BIOS What is the BIOS? The Power-On Sequence BIOS Upgrades Using AWDFLASH to Update the BIOS BIOS Setup Chapter 5: Suggestions V1.0 Vig645M Motherboard Manual...
  • Page 5: Chapter 1: Motherboard Overview

    Audio via 3 flexible audio jacks and integrated 10/100/1000 network connection, as well as 4 USB 2.0 ports to enrich your multimedia creation experience. The Vig645M supports Intel Core i3, i5, i7 processors and Intel Pentium processors as well as being Microsoft Windows 7 Premium WHQL certified.
  • Page 6: Feature Summary

    ALC887 HD (High Definition) Audio compatible audio subsystem  Flexible 8-channel audio with jack sensing  S/PDIF audio header  Front panel header  Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Realtek ® RTL8111E Gigabit Ethernet Controller V1.0 Vig645M Motherboard Manual...
  • Page 7  1x Clear CMOS jumper  1x SPDIF-out connector  1x TPM module connector Expansion Capabilities  1x PCI Express 2.0 x1 slot  1x 32bit v2.3 PCI bus add-in card connectors, supports 3.3V/5V PCI bus interface V1.0 Vig645M Motherboard Manual...
  • Page 8 DIMM channels are equal. Technology and device width can vary from one channel to the other but the installed memory capacity for each channel must be equal. If different DIMM speeds are used between channels, the slowest memory timing will be used. V1.0 Vig645M Motherboard Manual...
  • Page 9 8 full range channels at 24-bit/96kHz audio of lossless audio formats such as Dolby TrueHD or DTS HD Master Audio. The maximum supported resolution is 1920 x 1200 at 60 Hz refresh (WUXGA). The HDMI port is compliant with the HDMI 1.3 specification. V1.0 Vig645M Motherboard Manual...
  • Page 10  Line-In (Blue) - Line In, is used for external CD player, tape-player or other audio devices.  Line-Out (Green) - Line Out, is a connector for speakers or headphones.  Mic (Pink) - Mic, is a connector for microphones. V1.0 Vig645M Motherboard Manual...
  • Page 11 RJ-45 LAN Connector LEDs The two LEDs are built into the RJ-45 LAN connector located on the back panel. These LEDs indicate the status of the LAN as shown in Table 1. Figure 2: LAN Connector LED Locations V1.0 Vig645M Motherboard Manual...
  • Page 12 The Legacy I/O Controller provides the following features:  One serial port header  One parallel port header (with Extended Capabilities Port (ECP) and Enhanced Parallel Port (EPP) support  PS/2-style keyboard/mouse interface on the back panel V1.0 Vig645M Motherboard Manual...
  • Page 13 PCI/PCI Express auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a Conventional PCI or PCI Express add-in card. V1.0 Vig645M Motherboard Manual...
  • Page 14 If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer. V1.0 Vig645M Motherboard Manual...
  • Page 15: System Board Components

    4-pin Power Socket Connector Front Panel Header CPU Socket PCI-E Slot CPU Fan Header Clear CMOS Jumper DIMM Sockets S/PDIF-Out Connector 24-pin Power Socket Connector Audio Header SATA Ports USB Headers System Fan 1 Connector Back Panel TPM Header V1.0 Vig645M Motherboard Manual...
  • Page 16: Back Panel Connectors

     LAN Port - The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN). You can connect a network cable to it.  Audio Ports - These audio connectors are used for audio devices. V1.0 Vig645M Motherboard Manual...
  • Page 17: Chapter 2: System Board Options

    Chapter 2: System Board Options The Vig645M motherboard is capable of accepting Intel® Core i3, i5, i7 processors and Intel Pentium processors. RAM can be upgraded to a maximum of 16GB using DDR3 1066 or 1333MHz RAM DIMMs Non ECC Unbuffered memory.
  • Page 18: Overview Of Jumper Settings

    Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.
  • Page 19: System Board Jumper Settings

    The CMOS RAM allows the system to automatically boot OS every time it is turned on. Figure 5: Clear CMOS jumper V1.0 Vig645M Motherboard Manual...
  • Page 20: Motherboard Connectors

    50 ms to signal the power supply to switch on or off. (The time Power Switch Header requirement is due to internal debounce circuitry on the board.) At least two seconds must pass before the power supply will recognize another on/off signal. V1.0 Vig645M Motherboard Manual...
  • Page 21  If a high power (75W or greater) add-in card is installed in the PCI Express connector, that card must be connected directly to the power supply. Failure to do so may cause damage to the motherboard and the add-in card. V1.0 Vig645M Motherboard Manual...
  • Page 22  Front USB Connector: JUSB1, JUSB2 This connector, compliant with Intel® I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Figure 10: Front USB connectors V1.0 Vig645M Motherboard Manual...
  • Page 23 Figure 11: S/PDIF-Out connector TPM Module connector: JTPM1 This connector connects to a TPM (Trusted Platform Module) module (optional). Please refer to the TPM security platform manual for more details and usages. Figure 12: TPM Module connector V1.0 Vig645M Motherboard Manual...
  • Page 24 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Figure 14: Serial ATA Connector NOTE: Please do not fold the serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission. V1.0 Vig645M Motherboard Manual...
  • Page 25 Express x16 slot supports up 4.0 GB/s transfer rate and the PCI Express x1 slot supports up to 250 MB/s Figure 15: PCI Express Slots Note: When adding or removing expansion cards, make sure that you unplug the power supply first. V1.0 Vig645M Motherboard Manual...
  • Page 26: Upgrading The Cpu

    2. Rotate the socket lever to lift the load plate away from the socket (Figure 22, A). Make sure that the load plate is in the fully open position (Figure 22, B) while being careful not to damage adjacent components. Do not touch the socket contacts. Figure 17: Lift the load plate V1.0 Vig645M Motherboard Manual...
  • Page 27 B) and that the notches on the processor align with the posts on the socket (Figure 23, C). Lower the processor straight down without tilting or sliding it in the socket (Figure 23, A). Figure 19: Install the processor V1.0 Vig645M Motherboard Manual...
  • Page 28 (Figure 25, C, and D). The socket cover (Figure 25, B) will pop off as shown. Figure 20: Secure the load plate in place 6. Pick up the socket cover and remove it from the desktop board. V1.0 Vig645M Motherboard Manual...
  • Page 29 Figure 21: Connecting the processor fan heat sink power cable to the processor fan header  Removing the Processor For instructions on how to remove the processor fan heat sink and processor, refer to the processor installation manual. V1.0 Vig645M Motherboard Manual...
  • Page 30: Installing & Removing Memory Modules

    6. When the DIMM is seated, push down on the top edge of the DIMM until the retaining clips at the ends of the socket snap into place. Make sure the clips are firmly in place. 7. Replace the computer cover. Figure 22: Memory Installation V1.0 Vig645M Motherboard Manual...
  • Page 31 Hold the DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets. Figure 23: Removing Memory Modules V1.0 Vig645M Motherboard Manual...
  • Page 32: Replacing The Clock/Cmos Ram Battery

    CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. To replace the battery, carry out the following: 1.
  • Page 33: Chapter 3: Solving Problems

    The second part lists error code messages that might be displayed. Please remember that if you cannot solve the problem by yourself then you should contact Viglen Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 01727 201 850 Fax:...
  • Page 34: Troubleshooting Procedures

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. V1.0 Vig645M Motherboard Manual...
  • Page 35: Problems & Suggestions

    Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed. Make sure a video board is installed, enabled, and the jumpers are positioned correctly. Reboot the system. V1.0 Vig645M Motherboard Manual...
  • Page 36 System halts before This indicates a fatal system error that requires immediate service completing POST attention. Note the screen display and write down any beep code emitted. Provide this information to your dealer service department / Technical Support. V1.0 Vig645M Motherboard Manual...
  • Page 37: Chapter 4: System Bios

    (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by Phoenix Award BIOS, an industrial leader in the field of BIOS software.
  • Page 38: Bios Upgrades

    AFUDE234.EXE utility or in Windows using the AEFUWIN utility that is available from the Viglen FTP site. This utility does BIOS upgrades as follows:  Updates the flash BIOS from a file on a disk or within the location of the utility.
  • Page 39: Bios Setup

    The main menu lists the setup functions you can make changes to. You can use the arrow keys ( ↑↓ ) to select the item. The on-line description of the highlighted setup function is displayed at the bottom of the screen. V1.0 Vig645M Motherboard Manual...
  • Page 40 PC health status.  Overclocking - Use this menu to specify your settings for frequency/voltage control and overclocking.  Mflash - Use this menu to read/ flash the BIOS from storage drive (FAT/ FAT32 format only). V1.0 Vig645M Motherboard Manual...
  • Page 41 3. Save & Exit Setup: Use the arrow keys (←, →, ↑, ↓) to select the [Save Changes & Reset] in [Save & Exit] menu, and press <Enter>. A pop-up message will appear, please select [Yes] and press<Enter> to save the configurations and exit BIOS setup utility. Figure 29: Save & Exit Setup V1.0 Vig645M Motherboard Manual...
  • Page 42: Chapter 5: Suggestions

    Viglen is interested in continuing to improve the quality and information provided in their manuals. Viglen has listed some questions that you may like to answer and return to Viglen. This will help Viglen help to keep and improve the standard of their manuals.
  • Page 43 Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept. Viglen Ltd. 7 Handley Page Way Colney Street St Albans Hertfordshire AL2 2DQ V1.0 Vig645M Motherboard Manual...
  • Page 44 Notes V1.0 Vig645M Motherboard Manual...
