Quick setup guide

Radar sensor for continuous level
measurement of bulk solids
VEGAPULS 67
Profibus PA
Document ID: 51902

Advertisement

Table of Contents
loading

Related Manuals for Vega VEGAPULS 67

Summary of Contents for Vega VEGAPULS 67

  • Page 1: Quick Setup Guide

    Quick setup guide Radar sensor for continuous level measurement of bulk solids VEGAPULS 67 Profibus PA Document ID: 51902...

  • Page 2: Table Of Contents

    Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available in the download area of "www.vega.com". Operating instructions VEGAPULS 67 - Profibus PA: Document- ID 32940 Editing status of the quick setup guide: 2016-06-16...

  • Page 3: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS 67 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description".

  • Page 4: Ce Conformity

    For further information see www.namur.de. FCC/IC conformity (only for USA/Canada) The VEGAPULS 67 may only be used in closed vessels made of metal, concrete, or fibre-reinforced plastic. Note about this manual: This operating instructions manual is intended for use in a number of different countries.

  • Page 5: Environmental Instructions

    The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 67 • Profibus PA...

  • Page 6: Product Description

    Alternatively, you can access the data via your smartphone: • Download the smartphone app "VEGA Tools" from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or •...

  • Page 7: Mounting

    – Angle of inclination 180°, infinitely variable – Angle of inclination in three steps 0°, 90° and 180° • Double chamber housing – Angle of inclination 90°, infinitely variable – Angle of inclination in two steps 0° and 90° VEGAPULS 67 • Profibus PA...
  • Page 8 The compression flange allows mounting on a flange DN 80/ANSI 3", the adapter flange on flanges DN 100/ANSI 4" and DN 150/ANSI 6" You can find drawings of these mounting options in chapter "Dimen- sions". VEGAPULS 67 • Profibus PA...

  • Page 9: Mounting Instructions

    1. Distance from the vessel wall > 200 mm 200 mm (7.87") Fig. 5: Distance of the antenna to the vessel wall/socket configuration 2. Keep the socket short, round off the socket end For further information see chapter "Mounting". VEGAPULS 67 • Profibus PA...

  • Page 10: Connecting To Power Supply

    11. Tighten the compression nut of the cable entry gland. The seal ring must completely encircle the cable 12. Screw the housing lid back on The electrical connection is finished. VEGAPULS 67 • Profibus PA...

  • Page 11: Wiring Plan, Single Chamber Housing

    Voltage supply, signal output Wiring plan, double chamber housing The following illustrations apply to the non-Ex and also to the Ex-ia version. Wiring plan I 2 C Fig. 8: Wiring plan, double chamber housing Voltage supply, signal output VEGAPULS 67 • Profibus PA...

  • Page 12: Set Up With The Display And Adjustment Module Plicscom

    Fig. 9: Insert display and adjustment module Note: If you intend to retrofit the instrument with a display and adjustment module for continuous measured value indication, a higher lid with an inspection glass is required. VEGAPULS 67 • Profibus PA...

  • Page 13: Setup Steps

    Parameterization example The radar sensor measures the distance from the sensor to the product surface. For indication of the real level, an allocation of the measured distance to the percentage height must be carried out. VEGAPULS 67 • Profibus PA...
  • Page 14 False signal suppression Change now? Proceed as follows: 1. Move from the measured value display to the main menu by pushing [OK]. VEGAPULS 67 • Profibus PA...

  • Page 15: Menu Schematic

    Info Sensor address Min. adjustment Max. adjustment Medium 000.0 % 100.0 % Bulk solid 10.000 m(d) 0.000 m(d) 1.245 m(d) 6.789 m(d) Vessel form Linearisation curve Channel Damping Silo Linear PV lin. value Sensor-TAG Sensor VEGAPULS 67 • Profibus PA...
  • Page 16 PV-Out-Scale Simulation Reset Unit of measurement ▼ ▼ 0 % = 0.0 m³ Select reset? Start simulation m(d) 100 % = 100 m³ Language Copy sensor data 4.10 4.11 ▼ Copy sensor data? Enable? Deutsch VEGAPULS 67 • Profibus PA...
  • Page 17 5 Set up with the display and adjustment module PLICSCOM Info Basic adjustment Display Diagnostics Service ▶ Info Instrument type Date of manufacture Last change using PC Sensor characteristics 22. November 2010 Software version Display now? Serial number 3.80 22. November 2010 12345678 VEGAPULS 67 • Profibus PA...

  • Page 18: Supplement

    Ʋ Ex ia instrument 12 … 24 V DC Ʋ Ex-d instrument 20 … 32 V DC Power supply by DP/PA segment coupler Depending on the version M12 x 1, according to DIN 43650, Harting, 7/8" FF. VEGAPULS 67 • Profibus PA...
  • Page 19 6 Supplement Max. number of sensors non-Ex/Ex 32/10 VEGAPULS 67 • Profibus PA...

  • Page 20: Information
