Wiring Diagram - Stuart Turner Flomate iBoost CAT 5 Installation, Operation & Maintanance Instructions

5.21 Wiring of connection unit:
WARNING: This appliance must be earthed.
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow: Earth
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
connection unit proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal
in the connection unit which is marked with the letter E or by the earth
symbol:
The wire which is coloured blue must be connected to the terminal which is
marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.

5.22 Wiring Diagram:

FLOWSWITCH
REED (S3)
PRESSURE
SWITCH (S1)
KEYPAD
28481
5.23 Fuses: The following fuse size should be used:
or coloured green or green and yellow.
THERMOTRIP
MOTOR
N M
PCB
28480
S1 S2 S3 S3 S2 S1
COMM 1
PIN 1
0V
D1
0V
LED 1
R1
LED 2
R2
LED 3
R3
D2
SW 1
PIN 6
D3
SW1
Model
iBoost
Blue: Neutral
MAIN WINDING
CAPACITOR
START WINDING
RED YELLOW
BLUE
BROWN
N L
GREEN / YELLOW
6 4 2
5 3 1
D1
0V 0V D2 D3 SW
CABLE
20047
Fig. 10
Fuse Size (AMPS)
- 13 -
Brown: Live
N 230 VAC/1PH/50Hz
L
SUPPLY
E
10
Cont ...
