Summary of Contents for Antari DarkFX Spot 510 IP

  • Page 1: User Manual

    DarkFX Spot 510 IP User Manual English © 2016 Antari Lighting and Effects Ltd.
  • Page 3 Make sure there are no flammable materials close to the fixture while operating. ․ If the fixture fails to work, unplug the fixture and stop operation immediately. Contact ․ your local Antari dealer for advise.
  • Page 4 1 x User Manual Product Dimension Installation The DarkFX Spot 510 IP fixture should be connected to DarkFX Drive 4 driver. Refer to DarkFX Drive 4 user manual for full details of mains power requirements and DMX operation. See below diagram for wiring:...
  • Page 5 DarkFX Spot 510 IP is wired to output terminal of DarkFX Drive 4. Each output terminal can connect one DarkFX Spot 510 IP fixture. Physical Installation Important Use supplied mounting bracket or rigging clamp to install fixture. ․ Make sure installation location, fastening connecting, and rigging hardware can hold at ․...
  • Page 6 Adjustable Mounting Bracket Adjust mounting bracket by loosening gear screw, set the fixture to desire angle and tighten the gear screw to finish adjustment. Illustration below demonstrates how to adjust mounting bracket. Mounting Use screws for surface mounting or clamps for truss mounting. For surface mounting For truss mounting...
  • Page 7 Service and Maintenance Important! Smoke fluid residue, dust and any excessive particle residue will degrade product performance, cause overheating and damage fixture. Damages caused by inadequate cleaning or maintenance are not covered by product warranty. Cleaning ․ Unplug fixture from DarkFX Drive 4 before starting. ․...
  • Page 8 C08SPT510...

This manual is also suitable for:

Darkfx strip 510
