Xray GTX8 Instruction Manual page 43

901303
SB M3x3
961022
S 2.2
303123
SHIM 3x6x2
362280
CON. SHIM 3x6x2
901306
SB M3x6
902312
SH M3x12
902316
SH M3x16
903414
SFH M4x14
903416
SFH M4x16
SILICONE
TUBING
8mm
Ensure that the servo is in neutral position
before attaching the servo horn
3x6mm
NOTE
ORIENTATION
3x12mm
M4
3x6mm
M3
4x14mm
12. FINAL ASSEMBLY
Servo screw
(NOT INCLUDED)
NOTE ORIENTATION
➊
➋
➌
DETAIL
NOTE
ORIENTATION
NOTE
ORIENTATION
8mm THREAD
4 . 3 m
m
8mm THREAD
3x6x2mm
10mm THREAD
CONICAL SHIM
3x6x2mm
Remove the screws from mounting plate and servo horn
Install the servo brace
Check free move
4x16mm
10mm THREAD
3x16mm
