Nb2710 Status Indicators - NetModule NB2710 User Manual

Label Color
DI1
DI2
The color of the LED represents the signal quality for wireless links.
[1]
red means low
yellow means moderate
green means good or excellent
NB2710 User Manual 4.0
State Function
on Input port 1 is set.
off Input port 1 is not set.
on Input port 2 is set.
off Input port 2 is not set.
Table 3.1.: NB2710 Status Indicators
