Job Management
This page can be used to set up scripts, triggers and jobs. It is usually a good idea to create a
trigger first which is made up by the following parameters:
Parameter
Name
Type
Condition
Timespec
Event
You can now add your personal script to the system by applying the following parameters:
Parameter
Name
Description
Arguments
NB2710 User Manual 4.0
Figure 5.38.: SDK Jobs
SDK Trigger Parameters
A meaningful name to identify the trigger
The type of the trigger, either time-based or event-based
Specifies the time condition for time-based triggers (e.g. hourly)
The time specification which, together with the condition, specifies
the time(s) when the trigger should be pulled
The system event upon which the trigger should be pulled
SDK Script Parameters
A meaningful name to identify the script
An optional description of the script
An optional set of arguments passed to the script (supports quoting)
105
