Installation Guide
5. The max load of relay is 3 A (resistive) or 1 A (induc-
tive, such as pump, motor). The relay will be dam-
aged if the load exceeds the limit.
6. Don't cover the thermostat, for instance by hanging
towels directly in front of it.
7. The room thermostat should be connected to the
corresponding loop actuator in individual room
temperature control.

5. Technical Specifications

Feature
Approval
Ambient temperature
IP Class
Max. load, inductive
Max. load, resistive
Power consumption
Power supply
Room temp. set range
Floor temp. set range
Shell material
4
BasicPlus WT-D & WT-P
2
Description
CE Marking, EN60730
-10 - 60° C
30
<1 A
<3 A
2 W
85-250 Vac, 50/60 Hz
5 - 35° C
20 - 45° C
ABS + PC
VICUJ212 Danfoss Heating Solutions
