Scanmaster 2 MKII
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
01) If the device does not operate properly, unplug the device.
02) Check power from the wall, all cables, etc.
03) If all of the above appears to be O.K., plug the unit in again.
04) If nothing happens after 30 seconds, unplug the device.
05) Return the device to your Showtec dealer.
Product Specifications
192 DMX channels
8 dimming faders & total
Speed fader & Fade Time fader
30 banks of 8 programmable scenes
12 programmable chases, each chase can record up to 99 steps
Fade Time setting & Pan/Tilt setting
Manual Override button allows you to grab any fixture on the fly
Built-in microphone or line input for audio triggering
MIDI control upon banks, chases and blackout
External step control & Fog machine control
7-segment LED display
Joystick module
Jog wheel module
USB connector for DJ work, light and data backup
Power supply: DC 9-15V 500mA
Power connector: Power adapter (included)
Dimensions: 483 x 133 x 85 mm (LxWxH)
Weight: 3,2 kg
Design and product specifications are subject to change without prior notice.
Website:
www.Showtec.info
Email:
service@highlite.nl
Ordercode: 50333
15
