46'' Full HD Multi System LCD TV
ALT4620M
OPERATION MANUAL
* Attention
Please kindly refer to "TV Broadcasting system" (page12 of user's manual) for choosing
suitable TV broadcasting system as per your living area when you use this unit firstly. TV color
system is automatically searched regardless of your living area.
Read this manual carefully before operation.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avol ALT4620M
Summary of Contents for Avol ALT4620M
-
Page 1: Operation Manual
46'' Full HD Multi System LCD TV ALT4620M OPERATION MANUAL * Attention Please kindly refer to "TV Broadcasting system" (page12 of user's manual) for choosing suitable TV broadcasting system as per your living area when you use this unit firstly. TV color system is automatically searched regardless of your living area. - Page 3 INSTRUCTION MANUAL DEAR CUSTOMER: Congratulations on your purchase of the LCD color television! This manual will help you use the many exciting and useful features to make your LCD TV viewing more enjoyable than ever before. Before operating, please read all these safety and operating instructions completely and then retain this manual for future reference.
- Page 4 11. Entering of objects and liquids --- Never insert an object into the product through vents or openings. High voltage flows in the product, and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill water or liquid on the product. 12.
- Page 5 20. Do not place heavy foreign objects, liquid container on the product. Do not place naked flame sources, such as lighted candles, should be placed on the apparatus, or else it may cause fire hazard or electric shock. 21. Clean only with dry cloth --- Unplug this product from the wall outlet before cleaning.
-
Page 6: Using The Remote Control
USING THE REMOTE CONTROL Use the remote control by pointing it towards the remote sensor window of the set. Objects between the remote control and sensor window may prevent proper operation. NOTE: The illustration is for your reference only, the remote sensor may locate differently with different model. -
Page 7: Cable Installation
CABLE INSTALLATION Before the installation and use, please read carefully the relevant content in “Notice for Maintenance and Safety”. 1. Take the LCD TV from the wrapping package and put it in a drafty and flat place. NOTE: When you plug or unplug the LCD TV, computer or other equipments, you must make sure that the AC power has been already shut down;... -
Page 8: Name Of Components
NAME OF COMPONENTS Definition and function presentation of LCD TV Main power switch The definition and function presentation of the buttons of the product: Name Function Description Enter or leave the standby mode, same as on the remote control. 〖 〗 〖... - Page 9 QUICK START GUIDE Connection Turn off and unplug all components before making connections. Do not turn on the TV until connection setup is completed. Input High or Standard Video Connection Audio Connection Connector Definition Quality Composite video connector Audio L/R 480P S-VIDEO Use this connector in place of...
-
Page 10: Remote Control
REMOTE CONTROL The buttons of the original remote control are as following: Definition of the buttons on remote control: 1. POWER: Enter or quit the standby mode. 2. INFO: Show info of current program. :Requests index page when index link is valid. : Mute or restore sound. - Page 11 TV OPERATION Turning on and off the TV 1. Turning on 1. Connect the AC input cable then turn on the AC switch of the TV. At this time the TV will enter standby mode. 2. In standby mode, press the button on remote control to turn on the TV.
- Page 12 Channel Selection Press CH+/CH- on the remote control to increase or decrease the channel numbers. Also, the channel can be selected by pressing the number buttons. Additionally, when TV is in AV, S-VIDEO, YPBPR, HDMI or PC mode, the TV will work in TV mode and play the corresponding channel if any number button is pressed.
- Page 13 Advanced Provide the picture with dynamic noise reduction treatment, checking the high frequency noise of the picture, there are Off, Low, Mid and High, four modes of noise reduction. “Off ” means to close the noise reduction. Adjusts the contrast to keep it at the best level according to the brightness of the screen.
- Page 14 Setup Menu In TV mode Press MENU button on the remote control to select the SETUP menu. Shown as below: Channel Display the current channel number, you can switch between the channels through the button ◄/► . Color System To select the Colour System. Sound System To select the Sound System.
- Page 15 Frequency Display the current channel frequency. Press ◄/► to setup the automatic frequency tracking. Program Edit 1. Use the ▲/▼ button to select a channel. 2. Press the RED / GREEN / YELLOW / BLUE button to edit the channel. Fav.
- Page 16 Timer Menu Press MENU button on the remote control to select the TIMER menu. Shown as below: Current Time ( hour:minute ) Set the current time by pressing ◄/► to change the time parameter, or you can directly input the time through the number buttons.
- Page 17 Transparency Select menu transparency according to different background pictures. Panel Lock When the Panel Lock is set as "On", all of the buttons on the TV are loc ked and lose their function ( to release Pane l Lock, please press〖CH+〗or〖CH-〗button for more than 5 seconds), when you select this item as "Off ", the buttons on the TV are in normal mode.
- Page 18 MEDIA Operation o Access/Quit USB Mode button to call up the signal source selection menu. Use the ▲/▼ to highlight Press the SOURCE MEDIA1/MEDIA2, and the EN TER button to access the MEDIA mode. You may also use the signal source selection menu to exit from the MEDIA mode.
- Page 19 File Playback Play/ Pause Start playing the selected file of a folder or pause. Stop the playing files. Fast Reverse/Fast Forward Fast Reverse: There a re 2/4/8/16 levels of rewind speed. Fast Forward: There are 2/4/8/16 levels of fast forward speed. Previous/Next You can select the desired files manually in normal condition.
-
Page 20: Troubleshooting
TROUBLE SHOOTING When you meet the following common problems, you might diagnose and get the solutions without contacting with the technicians. Symptoms Possible Reason Solutions 1.The po wer cord is not plug ged in 1.Plug the p ower cord in No picture , no sound, an d no... -
Page 21: Specification Of Product
SPECIFICATION OF PRODUCT Item Specification Color System PAL, NTSC, SECAM Sound System D/K, I, B/G, M VGA mode supported VGA/SVGA/XGA/WXGA (60Hz) COMPONENT mode supported 480i, 480p, 576i, 576p, 720p, 1080i,1080p Including VGA mode and signal with high definition, namely, HDMI mode supported VGA/SVGA/XGA (60Hz), 480i, 480p, 576i, 576p, 720p,1080i, 1080p Audio Output Consumption... -
Page 22: Limited Warranty
WARRANTY PERIOD MODEL# LABOR PARTS ALT4620M 90 Days 1 Year No other express warranty is applicable to this product. The duration of any implied warranties, including the implied warranty of merchantablility, is limited to the duration of the express warranty herein.
