24" Full HD ATSC/Multi System LCD TV & DVD Combo
Model No.: ALTD2490AD
Attention:
Please kindly refer to "TV Broadcasting system"(Page 20 of User's manual) for the choosing suitable
TV broadcasting system as per your living area when you use this unit firstly. TV Color system is
automatically searched regardless of your living area.
Advertisement
Table of Contents
Related Manuals for Avol ALTD2490AD
Summary of Contents for Avol ALTD2490AD
- Page 1 24" Full HD ATSC/Multi System LCD TV & DVD Combo Model No.: ALTD2490AD Attention: Please kindly refer to “TV Broadcasting system”(Page 20 of User’s manual) for the choosing suitable TV broadcasting system as per your living area when you use this unit firstly. TV Color system is...
-
Page 3: Table Of Contents
Contents Contents Caution Safety Information Unit and Accessories Product Feature Introduction 1. Front View 2. Rear View 3. Remote Control Connection 9-12 Basic Operation OSD Menu 14-20 1. Picture menu 2. Audio menu 3. Time menu 4. Setup menu 5. Lock menu 6. -
Page 4: Caution
Caution Caution Correct disposal of this Product... -
Page 5: Safety Information
Safety Information Safety Information Electrical safety Physical safety... -
Page 6: Unit And Accessories
Unit and Accessories and Product Feature Unit and Accessories TV set 220V Power Socket User's manual Remote control Mains Cable Mains adaptor Batteries: 2xAA Product Feature - Inputs: RF, VIDEO, VGA, YPbPr, HDMI, S-VIDEO - Audio Input: AV Audio R/L, PC Audio - Support TV mode: NTSC-M, ATSC, PAL, Secam - B/G, D/K, I. -
Page 7: Introduction
Introduction Introduction 1. Front View Please insert a 12cm disc according to the silk Play the next track or chapter Play the previous track or chapter Eject the disc Play the disc playing Pause the disc playing Stop the disc playing Remote Control window LED Indicator POWER (Keep clear) -
Page 8: Rear View
Introduction 2. Rear View Headphone out Audio in VIDEO S-VIDEO PC-IN HDMI POWER RF2(for Europe): Connect antenna or cable 75 Ohm coaxial to receive TV signal. RF1(for USA): Connect antenna or cable 75 Ohm coaxial to receive TV signal. 3. Headphone: Connect to a headphone. 4. -
Page 9: Remote Control
Introduction 3. Remote Control The remote control is using Infra-Red(IR). Point it towards the front of the LCD TV. The remote control may not work correctly if it is operated out of range or out of angle. POWER(red button): Turn the TV on/standby. TV/AV: Press to display the input source menu. -
Page 10: Introduction
Introduction Buttons for DVD functions SETUP: DVD system setup. ZOOM: SUBTITLES: Installing Batteries 3. Close the cover. to the left and right of the IR receive at the front of the LCD TV. -
Page 11: Connection
Connection Connection Power Cord Connection Headphone out Audio in VIDEO S-VIDEO PC-IN HDMI POWER - Connect to the power supply correctly as shown with the Mains cable and Mains adaptor. - When you connect the power, the TV set comes into standby mode and the LED indicator (Page 5) lights Blue. - Page 12 Connection AV Input Connection Note: All cables shown are not included with the TV. Headphone out Audio in VIDEO S-VIDEO PC-IN HDMI POWER RCA Video Cable RCA Audio Cable DVD or VCR - Connect the VIDEO and AUDIO output jacks on the DVD or VCR to the AV IN jacks on the TV set with a RCA cable.
- Page 13 Connection HDMI Connection Note: All cables shown are not included with the TV. Headphone out Audio in PC-IN DVD or VCR - Connect the HDMI jack on the DVD to the HDMI jack on the TV set with a HDMI cable. - Turn on the DVD, and select “HDMI”...
- Page 14 Connection PC Connection Note: All cables shown are not included with the TV. Headphone out Audio in VIDEO S-VIDEO PC-IN HDMI POWER - If using a sound card, adjust the PC sound as required. - Set the video resolution of your PC to 1024x768,60Hz on its original monitor.
-
Page 15: Basic Operation
Basic Operation Basic Operation Power on/off 1. Connect to the power supply with a power code and an adaptor(page 9). 2.-To turn on the TV Press POWER button on the TV or remote control. -To turn off the TV Press POWER button on the TV or remote control. Input Source select INPUT SOURCE Press TV/AV button on the TV set or remote control... -
Page 16: Osd Menu
OSD Menu OSD Menu 1. Picture menu Description Picture mode: Select between Standard, Dynamic, Mild, Sports and User. You may select the picture mode directly by pressing the PMODE button on the remote control. Contrast: Control the difference between the bright and dark regions of the screen picture. Brightness: Adjust brightness of the picture. -
Page 17: Audio Menu
OSD Menu 2. Audio menu Flat Description Sound Mode: Select your desired picture mode as follow: Flat, Music, Movie, Sports and User You may select the sound mode directly by pressing the SMODE button on the remote control. Bass: Low frequencies intensity. Treble: High frequencies intensity. -
Page 18: Time Menu
OSD Menu 3. Time menu Description Sleep timer: You may set the automatic shutdown timer choosing from 5 to 240 minutes, or deactivate this function. Time zone: Alaska, Hawaii, Eastern, Central and Mountain. Daylight Saving Time: Select between On and Off. Clock: User can not change time manually during DTV mode, for time is from signal source directly. -
Page 19: Setup Menu
OSD Menu 4. Setup menu PC SETUP Closed Caption Description Menu Language: Transparency: Zoom Mode: Noise reduction: PC SETUP: Closed Caption: CC on Mute. Basic Selection: Advanced Selection: Service 6. Option: XVS: Restore Default:... -
Page 20: Lock Menu
OSD Menu 5. Lock menu Description Change password: Lock: don’t work. Canada: Reset RRT:... -
Page 21: Channel Menu
OSD Menu 6. Channel menu Description Nation System: Allow you to select nation system. Air/Cable: Allow you to select antenna between Air and Cable. If you selet “Cable”, the following items(Favorite, Show/Hide, Channel NO, Channel Label and DTV Signal) are unable to use. Auto Scan: Enter the Auto Scan menu to start auto scan. -
Page 22: Osd Menu
OSD Menu Show/Hide: Allow you to show or hide the channels. button to highlight the desired item, then press OK button to show or hide the highlighted channel. Channel Label: Allow you to setup a label for the channel. Press button to select the position of the table, and press button to select the words. -
Page 23: Dvd Operation
DVD Operation DVD Basic Operation Place a disc Insert a disc according to the silk. Do not touch the playing surface. automatically draw the disc into the player. Play Using the Display Feature 2. Loading and playing DVDs (two pages) of optional angles) or Off". -
Page 24: Disc Care
DVD Operation Subtitles Zoom In the Video Image 2. The Zoom Function allows you to enlarge the video image. Digital Audio Disc 2. The player will search the disc directory automatically and display the contents on screen. Disc Care About Disc Terms Title Chapter discs may not have a recording chapter. -
Page 25: Dvd System Setup
DVD Operation DVD System Setup change them again. General Steps of Setup Menu 1. Pause or Stop the player. Press SETUP 2. Press the 3. Press to select the desired feature and again press 4. Press to select the desired feature and then press "OK" to select the new setting. SETUP"... - Page 26 DVD Operation "0000". Using the RATING "play all" selection. 2. LANGUAGE SETUP - OSD LANGUAGE: The OSD will display in the language you choose. - AUDIO LANG: that language. - SUBTITLE LANG: this OFF. - MENU LANG: 3. AUDIO SETUP scroll and adjust the tone.
-
Page 27: Simple Troubleshooting
Simple Troubleshooting Simple Troubleshooting If the display fails or performance dramatically deteriorates check the Display in accordance with the following instructions.Remember to check the peripherals topinpiont the source of the failure. If the display still fails to perform as expected,connect your helpline for assistance. No power - Check all connections to the TV. - Page 28 LCD Panel Panel Size 24 inch(diagonal) Resolution 1920x1080 Brightness 300cd/m Contrast 1000:1 Input Connector Video Audio(L/R) PC Audio HDMI S-Video YPbPr Output Connector Headphone Power Source DC 12V Power Consumption...
