40
Full HD ATSC/Multi System LCD TV
Attention:
Please kindly refer to "TV Broadcasting system"(Page 28 of User's manual) for the choosing suitable
TV broadcasting system as per your living area when you use this unit firstly. TV Color system is
automatically searched regardless of your living area.
Note:
Main power switch is located on rear cabinet.
ALT40BDF(TV)
