Technical Data

10 Translation of original Operating Instructions, english, KNF 121211-121345 01/10
5. Technical Data

5.1. Pumps

All pumps are secured against overheating with thermal
switches and are equipped with a mains fuse.
Pump materials (for all pump types) *
Pump head
Diaphragm
Valve
Tab. 3
Refer to the type plate for the pump's electrical configuration.
N 810 FT.18
Pneumatic performance
Max. permissible operating
pressure [bar g]
Ultimate vacuum [mbar abs.]
Delivery rate at atm. pressure
[l/min]*
Pneumatic connection
Hose connection [mm]
Ambient and media temperature
Permissible
ambient temperature
Permissible media temperatu-
re
Other parameters
Weight [kg]
Dimensions: L x H x W [mm]
Maximum permissible ambient
relative humidity
Maximum altitude of site
[m above sea level]
Electrical Data
Voltage [V]
Frequency [Hz]
Maximum current consump-
tion [A]
Power consumption pump [W]
Maximum permitted mains
voltage fluctuation
Fuse pump
(2x) T [A]
Protection class motor
Tab. 4
LABOPORT Pumps and Systems
PTFE
PTFE coated
FFPM
*according to DIN ISO 1629 and 1043.1
1.0
≤ 100
max. 10
ID 10
+ 5 °C to + 40 °C
+ 5 °C to + 40 °C
5.9
256 x 187 x 146
80 % for temperatures up to
31 °C, decreasing linearly to
50 % at 40 °C
2000
100 115
50/60 60
1.4 1.3
110 110
+/- 10 % +/- 10 %
2.5 2.5
IP44
* Liters in standard state (1,013 mbar)
230
50
0.6
100
+/- 10 %
1.25
