KNF Laboport N820 Operating Instruction page 9

LABOPORT Pumps and Systems
Translation of original Operating Instructions, english, KNF 121211-121345 01/10
Fig. 3: LABOPORT Systems
Module
Pump
Baseplate
2 separators
1 separator
High performance
condenser
Electrical supply unit
1 vacuum controller
2 vacuum controllers
Tab. 2
Each pump and all systems can be expanded modularly up to
a full system SCC... (see chapter 7.7, page 28).
System
SR... SH... SC...
X X
X X
X
X
X
System overview
SCC...
X X
X X
X X
X X
X X
X
X
