AUSTRALIAN MONITOR AMSLIMG Instruction Manual

Gooseneck microphone

Download this manual

Thank you for purchasing this quality Australian Monitor product.

The AMSLIMG gooseneck microphone provides a cost-effective microphone solution

suitable for presentations. The cardioid electret condenser capsule provides high

sensitivity pickup, while the included isolation shock mount ensures mechanical and

room rumble noise is kept to a minimum.

This gooseneck microphone is highly recommended for conference rooms,

board rooms, meeting rooms, houses of worship, school halls and many

Need help?

Do you have a question about the AMSLIMG and is the answer not in the manual?

Page 1 Gooseneck Microphone Thank you for purchasing this quality Australian Monitor product. The AMSLIMG gooseneck microphone provides a cost-effective microphone solution suitable for presentations. The cardioid electret condenser capsule provides high sensitivity pickup, while the included isolation shock mount ensures mechanical and room rumble noise is kept to a minimum.
Page 2 Insert the shock mount into the hole again and fasten down the shock mount with the 3 screws provided. Installing AMSLIMG into the Shock Mount To install the AMSLIMG into the Shock Mount unscrew the bottom plastic screw collar. Slide the AMSLIMG body into the Shock Mount.
Page 3 Ø8mm [0.31in] Ø6mm [0.24in] TYPICAL POLAR PATTERNS Ø7.3mm [0.29in] ( ªø«× 162±3mm) TYPICAL FREQUENCY RESPONSE Ø8mm [0.31in] Specifications Transducer Type Electret condenser Ø 6mm Polar Pattern Cardioid Frequency Response 50Hz – 16Khz Sensitivity 11.2 mV/Pa -39 dBV Ø20mm [0.79in] Electrical Impedance 200 Ω...
Page 4 IMPORTANT SAFETY INFORMATION 1. Read these instructions. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 2. Keep these instructions. 14. Refer all servicing to qualiﬁed service personnel. Servicing is 3. Heed all warnings. required when the apparatus has been damaged in any way, 4.
