- Page 1 INSTALLATION AND OPERATION MANUAL IMGC450 GOOSENECK MICROPHONE BOX CONTAINS: 1 x IMGC450 Gooseneck Microphone 1 x Isolated shock mount 3 x Self tapping screws for shock mount installation 1 x Windsock Instruction manual...
- Page 2 IMPORTANT SAFETY INFORMATION READ these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
- Page 3 Dimensions sponse. The cardioid polar pattern of the IMGC450 provides Polar Patterns / Frequency Response exceptional gain before feedback. Users will enjoy fuss-free setup with minimal EQ manipulation, ensuring maximum Specifications SPL for that all-important presentation.
- Page 4 3 screws provided. Installing IMGC450 into the Shock Mount To install the IMGC450 into the Shock Mount unscrew the bottom plastic screw collar. Slide the IMGC450 body into the Shock Mount. Re-install the bottom plastic screw collar until snug.
- Page 5 DIMENSIONS IMGC450 INSTALLATION AND OPERATION MANUAL...
- Page 6 POLAR PATTERNS AND FREQUENCY RESPONSE 250Hz 2000Hz 4000Hz 500Hz 1000Hz 8000Hz TYPICAL POLAR PATTERNS TYPICAL FREQUENCY RESPONSE IMGC450 INSTALLATION AND OPERATION MANUAL...
- Page 7 Balanced 3 pin XLR Male Pin 2 +, Pin 3 –, Pin 1 shield OPERATING TEMP -10°C – 50°C 95% humidity max. DIMENSIONS 450 mm Length NET WEIGHT 151g INCLUDED ACCESSORIES Isolation shock mount, windsock IMGC450 INSTALLATION AND OPERATION MANUAL...
- Page 8 ENGINEERED BY AUSTRALIAN MONITOR Address: Unit 1, 2 Daydream Street, Warriewood NSW 2102 Australia Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 86 003 231 187...
