Modular Temperature Controller
EJ1
In-panel Temperature Controller with Flexible Modular
Design and Wide Integration with Host Devices
• The compact modular structure enables construction of temperature
systems optimally suited to the application.
• Connection can be made to a Programmable Controller without any
programming required, reducing the number of steps required in ladder
programming design.
• One fully multi-input Unit includes a thermocouple, platinum-resistance
thermometer, and analog input for easy selection and reduced inventory
requirements.
• Connect directly to the G3ZA Multi-channel Power Controller using optimum
cycle control for high-accuracy regulation with minimal noise.
• Up to 16 Temperature Controllers can be connected to a single DeviceNet
Communications Unit.
• All of the parameters for the Temperature Controllers connected to the
DeviceNet Communications Unit can be uploaded or downloaded in one
operation.
Ordering Information
■ Temperature Controller
Standard Control Models
Name
Power
No. of
Control
supply
control
outputs
voltage
points
1 and 2
Basic Unit
24 VDC
2
Voltage
(temperature
supplied
output:
control)
from the
2 points (for
(See note 1.)
End Unit
SSR drive)
4
(See note 2.)
2
Current
output:
2 points
HFU
None
None
(See note 1.)
End Unit
24 VDC
(See note 1.)
Note:
1. An End Unit is always required for connection to a Basic Unit or an HFU. An HFU cannot operate without a Basic Unit. External communications cannot be performed when using a
Basic Unit only.
2. For heating/cooling control applications, control outputs 3 and 4 on the 2-point models are used for the cooling or heating control outputs.
On the 4-point models, heating/cooling control is performed for the two input points.
3. When using the heater burnout alarm, purchase a Current Transformer (E54-CT1 or E54-CT3) separately.
Functional Upgrades
Refer to page 17 for details.
Upgrade functions are marked with "V1.1".
Refer to the following manual for precautionary information and other information necessary to use the EJ1:
EJ1 Modular Temperature Controller User's Manual (Cat. No. H142)
Control
Auxiliary
Functions
outputs
output
Heater
3 and 4
burnout
alarm
Transistor
None
2
output: 2 points
(See
(sinking)
note 3.)
Voltage output:
None
2 points (for
SSR drive)
(See note 2.)
Transistor
output: 2 points
(sinking)
None
Transistor output:
4 points (sinking)
None
Transistor output:
2 points (sinking)
Supports DeviceNet Communications.
Refer to the Safety Precautions on page 20.
Communications
Input type
functions
Event
inputs
2
G3ZA connection
Thermocouple,
port: RS-485
platinum
resistance
From End Unit:
thermometer,
Port A or port B:
None
analog voltage,
RS-485
and analog
current
selectable for
each channel.
2
4
Port C: RS-485 or
No input
RS-232C
selectable.
From End Unit:
Port A: RS-485
Port C: RS-422
From End Unit:
Port A: RS-485
None
DeviceNet
communications
None
Port A or B: RS-485
Connector: Port A
Modular Temperature Controller
Terminal
Model
M3 terminal
EJ1N-TC2A-QNHB
Screw-less clamp EJ1N-TC2B-QNHB
M3 terminal
EJ1N-TC4A-QQ
Screw-less clamp EJ1N-TC4B-QQ
M3 terminal
EJ1N-TC2A-CNB
Screw-less clamp EJ1N-TC2B-CNB
M3 terminal
EJ1N-HFUA-NFLK
Screw-less clamp
EJ1N-HFUB-NFLK
M3 terminal
EJ1N-HFUA-NFL2
Screw-less clamp
EJ1N-HFUB-NFL2
Screw-less clamp
EJ1N-HFUB-DRT
M3 terminal
EJ1C-EDUA-NFLK
Detachable
EJ1C-EDUC-NFLK
connector
EJ1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EJ1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Omron EJ1

  • Page 1 Refer to page 17 for details. Upgrade functions are marked with “V1.1”. Refer to the following manual for precautionary information and other information necessary to use the EJ1: EJ1 Modular Temperature Controller User’s Manual (Cat. No. H142) Modular Temperature Controller...
  • Page 2 ■ Accessories (Order Separately) Current Transformer (CT) CX-Thermo Support Software Ver. 4.0 Diameter Model Model 5.8 dia. E54-CT1 EST2-2C-MV4 12.0 dia. E54-CT3 USB-Serial Conversion Cable G3ZA Connecting Cable Model Cable length Model E58-CIFQ1 EJ1C-CBLA050 Rail Mounting Equipment Name Model Mounting Rail PFP-100N PFP-50N Specifications...
  • Page 3 ■ Characteristics Indication accuracy Thermocouple input/platinum resistance thermometer input: (±0.5% of indication value (PV) or ±1°C, whichever is greater) ±1 digit max. (See note 1.) Analog input: ±0.5% FS ±1 digit max. CT input: ±5% FS ±1 digit max. Hysteresis 0.1 to 999.9 EU (in units of 0.1 EU) (See note 2.) Proportional band (P) 0.1 to 999.9 EU (in units of 0.1 EU) (See note 2.)
  • Page 4 ■ Communications Specifications Item Port B Port A Terminal/ Port A Connector G3ZA Connection Port (See note 1.) (See note 1.) (See note 2.) Transmission path RS-485 (multipoint) connection Communications RS-485 (two-wire, half duplex) method Synchronization Start-stop synchronization method Communications CompoWay/F, Modbus (See note 4.) CompoWay/F protocol...
  • Page 5 ■ Input Ranges Sensor inputs are fully multi-input. Therefore, platinum resistance thermometer, thermocouple, infrared thermosensor, and analog input can be selected. Inputs can be set for each channel using multi-inputs. Input type Platinum resistance thermometer Name Pt100 JPt100 Tem- 2300 pera- 1800 ture...
  • Page 6 Communications method RS-485/RS-422 (two-wire, half duplex), RS-232C Synchronization method Start-stop synchronization Communications protocol • OMRON PLC protocol (Connectable PLCs: SYSMAC CS/CJ/CP1H Series) • AnA/AnU CPU common commands (Connectable PLCs: MELSEC-An/AnS/FX Series) V1.1 • MC protocol (form 5) (Connectable PLCs: MELSEC-Q/QnA/QnAS Series) Baud rate 9.6, 19.2, 38.4, 57.6, or 115.2 kbps...
  • Page 7 CRC error detection DeviceNet power supply Power supplied from DeviceNet communications connector Applicable Temperature Controllers EJ1 Series (excluding the EJ1G) TC4: EJ1N-TC4A-QQ and EJ1N-TC4B-QQ TC2: EJ1N-TC2A-QNHB, EJ1N-TC2B-QNHB, EJ1N-TC2A-CNB, and EJ1N-TC2B-CNB Maximum number of Temperature Controllers that 16 Units (model numbers with TC4: 64 channels max., model numbers with TC2: 32 channels can be connected (See note.)
  • Page 8 End Unit/EJ1C-EDU ■ Ratings Power supply voltage 24 VDC Operating voltage range 85% to 110% of rated voltage Auxiliary output Outputs (See note.) Transistor outputs Max. operating voltage: 30 VDC, Max. load current: 50 mA Operating: − 10°C to 55°C Ambient temperature range −...
  • Page 9: Unit Configuration Example

    EJ1N-TC2 EJ1C-EDU Port A (connector): USB connection can be made CX-Thermo for setting COM1 COM2 EJ1-TC4 COM3 with the E58-CIFQ1 (sold separately). Port B: RS-485 (CompoWay/F) Host devices ■ Multiple Units without an EJ1N-HFU Building Systems Communicating with the Host Device, such as a PLC, PT, or Computer, via RS-485 (CompoWay/F Protocol) •...
  • Page 10 • G3ZA outputs can be used. • Distributed placement is possible by using multiple EJ1C-EDU End Units. • To connect more than one HFU, specific PLC and EJ1 models must be used. Refer to Connecting EJ1 Controllers 1:N to a PLC on page 13.
  • Page 11 Note: End Units are not included in the number of Units that can be connected. Up to 64 Basic Units can be connected using distributed placement. Using EJ1@-TC4 models: 4 channels × 64 Units = 256 channels COM1 EJ1-TC4 COM2 COM3 Using EJ1@-TC2 models: 2 channels ×...
  • Page 12 Functional insulation is applied between the power supply, input, output, and communications terminal sections. If reinforced double insulation is required, use power supplies that comply with IEC60664 for reinforced double insulation for the EJ1's external power supply and for power supplies connected to the EJ1.
  • Page 13 Note: 1. Refer to the Mitsubishi Electric PLC documentation for information on MELSEC PLCs. 2. Direct connections to the EJ1 are possible only with RS-232C or RS-422. 3. More than one EJ1 Controller to one PLC is not possible even with RS-422 communications. Refer to Connecting EJ1 Controllers 1:N to a PLC, below, for product combinations that support 1:N connections 4.
  • Page 14 − Note: 1. To connect to the G3ZA, separately purchase a G3ZA Connecting Cable (EJ1C-CBLA050) and connect it to the G3ZA connection port (CN1) on the EJ1. 2. To connect to a computer using the port A connector, use a separately sold E58-CIFQ1 USB-Serial Conversion Cable. The Temperature Controller can be connected to a computer using USB.
  • Page 15: Nomenclature And Specification Settings

    ■ Specification Settings Switch Operation SW2 Settings • Check that the EJ1 is turned OFF before operating the switches. EJ1N-TC2/TC4 Settings are read only when power is turned ON. • Set the switches with a small flat-blade screwdriver. Do not set the Meaning switches midway between settings.
  • Page 16 • The SW1 switches are set to 00, SW2 is set to 0, and SW3 pins are all set to OFF in the default settings. 4 (EDS) Use the OMRON Configurator. Note: The setting of pin 3 on SW3 can be changed while the power is Use universal Configurator. (EDS files...
  • Page 17 • Modbus communications can be used on port B. • Software version 2 of G3ZA Multi-channel Power Controller can be used. Note: Software version 2 of G3ZA Multi-channel Power Controller can also be used with EJ1 version 1.0. HFUs (EJ1N-HFU@-NFL@) •...
  • Page 18: Basic Units

    Dimensions Note: All units are in millimeters unless otherwise indicated. ■ Temperature Controller Basic Units 109 (Models with screw terminal blocks) EJ1N-TC 104.85 (Models with screw-less clamp terminal blocks) HFUs COM1 COM1 EJ1N- COM2 EJ1N- COM2 COM3 COM3 EJ1N-HFU@-NFL@ 27.0 35.4 95.4 27.6...
  • Page 19: End Plate

    ■ Options Current Transformer (Sold Separately) E54-CT1 5.8 dia. 10.5 Two, 3.5 dia. E54-CT3 2.36 dia. 12 dia. Two, M3 (depth: 4) E54-CT3 Accessory • Armature Connection Example Armature Approx. 3 dia. Plug Lead • Plug Approx. 6 dia. (22) Rail Mounting Equipment (Order Separately) DIN Rail ±0.15...
  • Page 20: Safety Precautions

    IEC 60664 for the EJ1 external turning ON the power. power supply or the power supply connected to the EJ1. 10.It takes 30 minutes from the time the Temperature Controller is If non-compliant power supplies are used, electric shock turned ON until the current temperature is displayed.
  • Page 21: Installation

    3. Attach the cover seal to the connector opening on the Unit on the same. left end of the EJ1. 3. Mount the Temperature Controller so that it is horizontally level. 4. If the measurement accuracy is low, check to see if input shift has been set correctly.
  • Page 22 (cable length: 5 m) Refer to the “G3ZA Instruction Manual” for wiring methods. Refer to the following manual for precautionary information and other information necessary to use the EJ1: EJ1 Modular Temperature Controller User’s Manual (Cat. No. H142) Modular Temperature Controller...
  • Page 23 I/O Devices ■ Examples of EJ1-series Temperature Controllers/Output Devices Input device/sensor Temperature controller Load Heater Voltage output Load INPUT LOAD power terminal supply (for driving SSR) Can be directly connected. G3PF (SSRs with built-in CTs) Number of SSRs That Can...
  • Page 24: Ordering Information

    CX-Thermo Support Software Ver. 4.0 EST2-2C-MV4 Monitoring/Setting Support Software for E5CN/CN-H, E5AN/AN-H, E5EN/EN-H, E5ZN, E5@R/@R-T, and EJ1 Temperature Controllers Enabling Faster Parameter Setup, Device Adjustment, and Maintenance • Enables editing and batch-downloading parameters from a personal computer, reducing the work required to set parameters.
  • Page 25 Cable for Support Software Enables Connection Even with Temperature Controllers Not Equipped with Communications • Easily set Temperature Controller parameters by connecting the computer's USB port and an EJ1, or a new-model E5CN, E5AN, or E5EN. Ordering Information Model E58-CIFQ1 Note: Older models of the E5CN, E5AN, and E5EN are not supported.
  • Page 26: Warranty And Application Considerations

    CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE...
