Installation into a 500 series rack
• Please read the manual that comes with the 500 series rack. You should gain all
information necessary for the installation process.
• Your 500 series rack should be switched off and the power cable should not be
connected.
• Insert the HPm module into two adjacent free slots of your rack. Make sure the con-
nectors of the HPm is precisely aligned with the rack connectors.
• Press the HPm module carefully into the rack connectors and tighten the screws.
• Connect the HPm module with your audio environment using the connections from
your 500 series rack.
• Insert the power cable to the 500 series rack and switch it on.
Note:
The HPm can easily be inserted between the DAW and a monitor controller because
the input signals of the HPm are slaved through to the outputs of the 500 series rack.
HPm
Installation
Content
7
