3. Installing the
Install the Metasys ® N2 option to
Please install this option (MTS001Z) on the top of options when you install two options.
Do not install under the another option.
(1) Turn off input power of
Securing the option to the inverter
(2)
a) Insert a flat-blade screwdriver in each of the two holes at the upper part of the
b) Install the option in the inverter by fitting the tabs on the lower side the option into
c) Make sure the option is securely attached to the inverter. Then check whether the
d) Insert the tabs at the lower part of the front cover into the slots at the lower part of
e) Stuck the enclosed "LED name label" in the option LED display part of a front
a)
b)
LED name label
COM
ERR
MTS001Z
the CHARGE lamp on
front panel, release the panel mounting tab by pushing the screwdriver down and
remove the front panel cover.
the slots at the lower part of the inverter front panel.
plastic bosses on the inverter case have fitted in the holes at the upper and lower
parts of the option.
the inverter to attach the front cover to the inverter.
cover.
c)
e)
VF-PS1 as follows.
VF-PS1 and wait for at least 15 minutes and then check that
VF-PS1 is no longer lit.
- 8 -
