- Page 1 RollerMouse Pro3 User Guide...
-
Page 2: Box Contents
Box Contents RollerMouse Pro3 Two short keyboard risers Two long keyboard risers RollerMouse Pro3 user manual... - Page 3 RollerMouse Functions Rollerbar Cursor speed LED Cursor speed adjustment Copy Paste Left-click Right-click Scroll wheel “One Touch” double-click For additional mouse features and specific Mac settings, please download our driver at http://support.contourdesign.com RollerMouse Pro3 user manual...
- Page 4 Positive Tilt Balance Keyboard is designed specifically for the RollerMouse. The keyboard sits level with the rollerbar and can be easily adjusted to a positive, neutral, or negative tilt. Negative Tilt Neutral Tilt RollerMouse Pro3 user manual...
- Page 5 Fit the end of the riser into the slot on the back of Line up the short and long risers then the RollerMouse Pro3. press the two parts together until you hear them snap into place. RollerMouse Pro3 user manual...
-
Page 6: Connecting To A Computer
Connecting to a computer Click Force Tension Adjustment Plug the RollerMouse Pro3 USB cable into the computer’s USB port. For optimal control, you can adjust the amount of pressure required to perform Allow your computer a few seconds to automatically install. - Page 7 Using the rollerbar The rollerbar provides two functions: · Pressing down on the rollerbar performs a left click. · Moving the rollerbar from side to side and up and down performs cursor movement. RollerMouse Pro3 user manual...
- Page 8 Press the Cursor Speed button to cycle through cursor speeds. There are ten speed selections which range from slow (600 DPI) to fast (2400 DPI). Speed can be identified by the LED lights as shown. 2200 DPI RollerMouse Pro3 user manual...
-
Page 9: User Settings
User settings Different Mode Settings RollerMouse Pro3 has 3 modes. PC-mode, Mac-mode and Linux (HID-mode). The default setting on your RollerMouse, is PC-Mode. Use the following key commands to switch settings to best fit your operating system. • Press and hold the buttons simultaneously for two seconds to see the LED lights flash for the respective mode. - Page 10 Changing the ‘Double click’ button to ‘Middle’ function To change double click button to function as a middle click, hold buttons for two seconds until LED lights flash to confirm. Repeating this process will revert back to double click functionality. RollerMouse Pro3 user manual...
- Page 11 Contour Design Nordic A/S - Reorient or relocate the receiving antenna.
