Getting Started

Before you can use your pendant microphone, you need to do the following:

Install the IR receiver module

Install and connect the IR dome sensor
Attach the neck strap
Insert the batteries
Adjust the sound
Install the IR Receiver Module
Follow the steps below to install the IR receiver module. Make sure you have read all of the
safety instructions before beginning the installation.
Note: The Connection & Control Box must be mounted to the wall prior to installation.
See your Connection & Control Box guide for more information.
1.
Turn off the power to the Connection & Control Box, then disconnect the plug from
the outlet.
2.
Remove the two screws from the cover on the side of the Connection & Control Box,
then remove the cover.
3.
Insert the IR receiver module into the slot, then reattach the two screws.
4.
Connect the plug to the outlet, then turn on the power to the Connection & Control
Box.
5.
Verify that the light on the receiver module is lit (red).
Note: If the light on the IR receiver module is not lit, the IR receiver module is not
properly seated.
6
Getting Started
