Generac Power Systems 005564-0 Owner's Manual page 63

1 0G6042
2 0F0683
3 0G9295
4 0F2820
5 0A8241
6 0A8240
7 0G81990SS0R
8 0G8198
9 0G76860SS0R
10 022237
11 043097
12 0F6927
13 042914
14 043116
15 022097
16 051756
17 022145
18 022129
19 052647
20 022131
21 046526
22 0G74380ST03
23 0G74390ST03
(2) 24 057642
25 022473
(1) 26 0G7614
0H2608
0G8124
0H2615
27 0F1156
28 0F1157
29 0F1158A
30 0G5724
31 042909
32 027482
37 033437
OIL TEMP KIT P/N 0G8304
A 0F2776A
B 0E0502
C 0G4099
(1) D 0G0349
REF ENGINE 2.4L W/CAC TIER 3
REF ENGINE FOOT 2.4L JD STAMPING
1 FAN SPACER 2.4L G4 22" FAN SHT
1 FAN 22"DIA 10 BLADE C2&C3 CPL
1 ADAPTOR SAE4 TO SAE3
2 FLEX PLATE SAE10
1 HEAT SHIELD, EXH MAN 2.4L CAC
2 SPACER .34 X .62 X 2.375
1 HEAT SHIELD, TURBO
8 WASHER LOCK 3/8
8 SCREW SHC 3/8-16 X 1 G8.8NZ
4 SCREW SHC M8-1.25 X 80 C12.9
2 SCREW HHC M8-1.25 X 90 C8.8
1 SCREW HHC M6-1.0 X 12 C8.8
1 WASHER LOCK M6-1/4
4 SCREW HHC M10-1.5 X 20 C8.8
3 WASHER FLAT M8-5/16 ZINC
6 WASHER LOCK M8-5/16
12 SCREW SHC M10-1.5 X 25 C12.9
20 WASHER FLAT M10-3/8 ZINC (12 USED TO MOUNT TO STATOR)
28 WASHER LOCK M10 (12 USED TO MOUNT TO STATOR)
1 SPACER PLATE, BOTTOM ECU
1 SPACER PLATE, TOP ECU
12 SCREW HHC M10-1.5 X 40 C8.8
1 WASHER FLAT 1/4-M6 ZINC
1 HARN,3.0L G4 TIER3 ENGINE WIRE (USE WITH PROBE P/N 0E2507)
1 HARN ENG D3.0L G4 H-100 TIER 3 (USE WITH PROBE P/N 0H1827)
1 HARN ENG 3.0L G4 TIER 3 VZW (USE WITH PROBE P/N 0E2507)
1 HARN ENG D3.0L G4 TIER 3 VZW (USE WITH PROBE P/N 0H1827)
1 FUSE HOLDER BOLT-ON
1 FUSE 50A BOLT-ON
1 ASSY WIRE GLOW PLUG G4 W/PLUG
2 SCREW PHTT M3-0.5 X 10
1 SCREW HHC M8-1.25 X 30 C8.8
1 WASHER SHAKEPROOF EXT 5/16 STL
1 SPACER .41 X .75 X .56 STL/ZNC
1 BRACKET, SIGNAL CONDITIONER
1 TEMPERATURE SENDER, DELPHI
1 OIL TEMP PIPE TEE
1 HARN OIL TEMP SENDER OPTION
(1) NOT SHOWN
(2) TO MOUNT STATOR TO ADAPTOR (NOT SHOWN)
