Generac Power Systems 005564-0 Owner's Manual page 41

EXPLODED VIEW: EV BATT HOLD DOWN 24, 27 & 31
DRAWING #: 0G7790
ITEM PART#
1A 058665
058665A
B 058208
C 061119
061119A
2A 0A4010
B 0A4010
C 099049
3A 052858
B 052858
C 022129
4A 049820
B 049820
C 045771
5A 022145
B 022145
C 022145
6A 061902
B 061902
C 059568B
REVISION: K-1219-E
DATE: 11/11/14
QTY. DESCRIPTION
1 BATTERY 12VDC 90-AH 27F
1 BATTERY SERVICE DRY
1 BATTERY 12VDC 24F 525 CCA
1 BATTERY BCI GRP 31
1 31E BATTERY SERVICE DRY
2 SCREW HHC M8-1.25 X 60 C8.8 FT
2 SCREW HHC M8-1.25 X 60 C8.8 FT
2 J BOLT BATTERY TRAY
2 NUT LOCK FL M8-1.25
2 NUT LOCK FL M8-1.25
2 WASHER LOCK M8-5/16
2 NUT LOCK HEX M8-1.25 NYL INS
2 NUT LOCK HEX M8-1.25 NYL INS
2 NUT HEX M8-1.25 G8 CLEAR ZINC
4 WASHER FLAT 5/16-M8 ZINC
4 WASHER FLAT 5/16-M8 ZINC
2 WASHER FLAT 5/16-M8 ZINC
2 HOLD DOWN BATTERY (60-100KW)
2 HOLD DOWN BATTERY (60-100KW)
2 BATT HOLD DOWN BAR 368MM
GROUP C
Page 2 of 2
