Points to Check before Use

3.1 Accessories

The accessories below are included with this receiver:
User's manual : 1
Batteries (AAA type) : 2
3.2 The Satellite dish
Your dish should be properly installed and azimuth and elevation must be precisely set up.
This unit supports DiSEqC 1.2 and can work with a compatible antenna positioner.
Ask your dealer for information.
Remote control : 1
HDMI cable : 1
If any of the above-listed
accessories is missing, contact
your sales representative.
6

Controls/Functions

4.1 Front Panel

3 1
5
Standby/Power on Indications Lamp : Flashes red light in "Standby" mode and shows no
1
light in "Power ON" mode.
Power : Switches the receiver between "Standby" and "Power ON" modes.
2
Menu : To enter or exit the main menu.
3
Select : To show the Channel List in non-menu mode and select on item or confirm in
4
menu mode.
: To change the volume level in non-menu mode and modify a setting in
5 - 6 VOL
menu mode.
: To switch channels or change the cursor position on the application
7 - 8 CH
screen.
2.5" & 3.5" S-ATA HDD(Max. 1TB)
9
7 4
8 2 6
9
7
