How to Connect

When Connecting the Receiver to a TV with RF connectors
1 Connect the TV antenna to TV ANT IN
2 Connect the Video and Audio of the TV to Video and Audio: connect the red and white
connectors to Audio R and Audio L, and the yellow connector to Video
3 Connect your satellite dish
12
3.5", 2.5" SATA HDD Assembly Instruction
1. Turn off AC power.
2. Open the HDD SLOT cover.
3. Remove HDD Bracket .
Push no.1 and pull no 2.
4. Screw & assemble HDD and HDD
Bracket.
5. Assemble HDD Bracket at the HDD
SLOT.
Note : For PVR Mode, Please go to
Page 50
3.5inch HDD
2.5inch HDD
& SCREW
& SCREW
13
