6.1 Getting Started
5) Satellite Scan
Through this function, the receiver searches for all the available channels and saves them
in memory.
Auto Scan <Figure 6.1.8>
To select more than one satellite, press the RED button when the selection bar is
positioned on the satellite.
Press on the names of the satellites that you want to scan under 'Satellite List'.
Press the EXIT button to close the 'Satellite List'.
Press / and set the 'Search Type' and 'Network Search' parameters.
- Search Type : Decide for which channels to search (All channels/ Free channels
only/ TV channels only).
- Network Search : Set ON to find more transponders (frequencies) through a Network
Information Table (NIT) scan. That is, when the broadcaster is
sending a NIT through a given transponder, the receiver will also
scan for transponders listed in the NIT and not otherwise
recognized. (this can happen when a transponder is new)
Press under 'SCAN' to scan the selected satellites. <Figure 6.1.9>
<Figure 6.1.8> <Figure 6.1.9>
18
6.1 Getting Started
Blind Scan <Figure 6.1.10>
Select the satellites you want to search by pressing the button on the remote.
Press / to set the "Frequency" and "Polarization" and "Scan Mode" options.
- Frequency : Select TP frequency
- Polarization : Select Vertical / Horizontal / All.
- Scan Mode : All / Free / TV
All : To search all the Free To Air and scrambled channels, TV & Radio channels.
Free : To search Free To Air channels only.
TV : To search TV channels only.
SCAN : Begin channel search of the selected satellites.
Manual Scan <Figure 6.1.11>
Select a transponder.
To change a transponder's information (Frequency, Symbol Rate), use the NUMERIC
buttons.
To add a new transponder, press the GREEN button.
To delete a transponder, press the YELLOW button with the cursor next to the
Frequency parameter.
To search a transponder, set its different parameters and press
<Figure 6.1.10>
.
<Figure 6.1.11>
19
