SAFETY PRECAUTION

CAUTION:
The lightening flash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to "dangerous
voltage" and to prevent from a
risk of electric shock.
WARNING: The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall not be placed on the apparatus.
WARNING: Do not place naked flame sources, such as lighted candles on the apparatus;
otherwise, there is the danger of fire.
WARNING: The unit should be connected to a power supply only of the type descry bed in the
operating instructions or as marked on the unit. If you are not sure of the type of power supply (for
example: 120 or 230V) to your home, consult your local dealer or local power company.
WARNING: Do not open the cabinet or touch any parts in the inner mechanism. Consult your local
dealer for technical service if the opening is required.
WARNING: The mains plug is used as the disconnect device, the disconnect device shall remain
readily operable.
WARNING: Take attention to the environmental aspects of battery disposal. The battery of remote
control should not be exposed excessive heat such as sunshine, fire or the like.
WARNING: Maintenance man must use the appointed screw in the rear plate.
WARNING: Ensure a minimum distance of 5 cm around the apparatus for sufficient ventilation.
WARNING: Ensure that the ventilation is not impeded by covering the ventilation openings with
items such as newspapers, table-cloths, curtains, etc.
WARNING: Use the apparatus only in moderate climates (not in tropical climates).
Warning:
To reduce the risk of electric
shock, don't open the cabinet.
Refer servicing to qualified
personnel only.
The exclamation point within an
equilateral triangle is intended to
alert the user to important
operating and maintenance
(servicing).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-Tech One and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke-tech C-Tech One

  • Page 1: Safety Precaution

    SAFETY PRECAUTION CAUTION: The lightening flash with Warning: The exclamation point within an arrowhead symbol, within an To reduce the risk of electric equilateral triangle is intended to equilateral triangle, is intended shock, don't open the cabinet. alert the user to important to alert the user to "dangerous Refer servicing to qualified operating and maintenance...
  • Page 2 WARNING: Not allow to pull out the HDMI cable or AV cable when the box is running, otherwise, it may damage the video output. Note: Do not open the cabinet to avoid the unit direct exposure to radiation. Unit Cleaning: After the unit power is turned off, you can clean the cabinet, panel and remote control with a soft cloth lightly moistened with a mild detergent solution.
  • Page 3 This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
  • Page 4: Table Of Contents

    Contents Contents 1. Remote Control & Panel Description ................... 4 1.1 Front Panel Description ......................4 1.2 Rear Panel Description ......................5 1.3 Remote Control Description ....................6 2. Basic Operations ........................7 2.1 Switch on STB ........................7 2.2 Standby Mode ........................7 2.3 MUTE ...........................
  • Page 5 Contents 6.8 VIMEO..........................23 6.9 Online Video ........................24 6.10 Photo ..........................24 6.11 Google Map ........................24 6.12 Weather ..........................25 6.13 Radio ..........................25 6.14 Gmail ..........................25 6.15 IPTV ..........................26 6.16 ISO ............................26 6.17 Ebook ..........................26 7. Setting ............................. 27 7.1 Installation ...........................27 7.1.1 Antenna Setting ......................28 7.1.2 Satellite List .......................28 7.1.3 Transponder List......................30 7.1.4 Motor Setting ......................31...
  • Page 6 Contents 8.7 Standby Display ........................48 8.8 Network Setup ........................48 8.9 Multi Media ..........................49 8.10 PVR Config........................50 8.11 Card ..........................50 8.12 Version ..........................50 9. Troubleshooting ........................51 10. Technical Specification ....................... 53...
  • Page 7: Remote Control & Panel Description

    Remote Control & Panel Description 1. Remote Control & Panel Description 1.1 Front Panel Description POWER: Is used to switch between the working mode and the standby mode. Display: (4-Digit/7-Segment) Displays the received channel number while operating and time in standby mode. IR-Sensor: Detects the infrared signals from the remote control unit.
  • Page 8: Rear Panel Description

    Remote Control & Panel Description 1.2 Rear Panel Description IF IN: Satellite input. IF OUT: Satellite output for cascading to other devices Note: The operation of another receiver at the same time is only possible with limited channel selection. AUDIO R/L: HiFi outputs for stereo set.
  • Page 9: Remote Control Description

    Remote Control & Panel Description 1.3 Remote Control Description...
  • Page 10: Basic Operations

    Basic Operations 2. Basic Operations 2.1 Switch on STB Switch the [Device‟s Main Power] switch on. When the STB is first used it will display “Init Install” window. You will set OSD Language, Time Zone, Single Satellite Search and Multi Satellite Search. Press [▲/▼] keys to highlight the item, press [OK] or [►] key to edit the option, you can press [▲/▼...
  • Page 11: Timeshift

    Basic Operations The optional selection depend on the channel.. 2.7 TIMESHIFT In TV mode, press the [TIMESHIFT ] button will play back the recordings recorded, press the "stop" you will be asked to "Do you want to stop TIMESHIFT " menu. 2.8 USB In TV mode, press [USB] button to access directly to the “Applications”...
  • Page 12: Pvr List

    Basic Operations Basic Operations At the bottom of a Teletext page, enter a page number (range: 100~899) to go to corresponding page. Press [▲/▼] keys to turn to the previous or next pages. The pages that have no teletext contents will be auto skipped.
  • Page 13: Vol

    Basic Operations 2.19 CH▲/▼ to change previous/next channel, Move cursor up/down. 2.20 Vol◄/► Adjust volume, select highlighted menu, display sub-menu, return to previous menu 2.21 OK In TV mode press [OK] button to open the Channel List window. Press [CH▲/▼] to switch channel and confirm it with [OK] to switch to it. The colour buttons offer further functions to manage the channel list.
  • Page 14: Epg

    Basic Operations  Press [Blue] button to open the “Group” window like showed beside. 2.22 EPG To get the information of programs being played or to be played in coming days, press EPG key to enter the electronic program guide (EPG). The EPG information depend on the channel, if the channel have not EPG information, the relative field show “No Event Info”.
  • Page 15: Info

    Basic Operations Green function key: When the highlight is in Area 5, press this key to record the selected program. When the highlight is in Area 6, press this key to schedule to record the selected program (Scheduled Record). In addition, press INFO key to show the detailed information of the selected program. 2.
  • Page 16: Sat

    Basic Operations 2.27 SAT In TV mode, press [SAT] button to open satellite list and select there, then press [OK] to open “TV Channel List” menu, select channel of the current. In satellite list, press [CH▲/▼] to switch directly between satellites. 2.28 Channel Number In TV mode you can enter the channel number directly with your remote control unit and confirm the number with the OK button to change to the desired channel...
  • Page 17: Video

    Menu Operations 3. Video The Movie module is for playing video files stored on the USB (CARD) device. Press [OK]or [ ►] keys to play the selected video file Press [I◄◄/►►I] and [◄◄/►►] to play the previous or next video at the same directory 4.
  • Page 18: Picture

    Menu Operations 5. Picture The Picture module is for playing image files stored on the USB (CARD) device. Most popular image formats are all supported. In the Module Select Area, press [◄/►] keys to select the Photo type, then press [OK] or [▼] keys to enter the image file list area.
  • Page 19: Rec Manager

    Menu Operations 6.1 Rec Manager The Rec Manager module is for users to carry out record setting and view the programs recorded: If the USB (CARD) device has more than one partition, you should manually set the partition in which record files will be saved. ...
  • Page 20: Disk Manager

    Menu Operations During playback, the things you can do only include to press [◄◄/►►] keys to fast backward or forward play the file, and to press RECALL key to return to the record file list. Both file switching and repeat mode setting cannot be done. When the playback completes, the system will auto return to the record file list.
  • Page 21: News

    Menu Operations The left list is the Source list, the right list is the Destination list. Before moving or copying a file (folder), the things you should do include: selecting the file (folder) from the left list, then press the green function key to confirm your selection, and then entering the destination directory in the right list.
  • Page 22: Dlna

    Menu Operations 6.5 DLNA DLNA function: the full name is “Digital Living Network Alliance”, which is a new network application in Sunplus. It offers a communication and media play between your STB and your mobile, laptop, Ipad…and support 2 functions: DMP: Digital Media Player.
  • Page 23 Menu Operations Step3, A: Android Phone Open the DLNA S/w in the phone, and keep it in opening state. (Keep the permission for outside visiting), B: iOS phone, Open theArkMC lite, and keep it in opening state. (Keep the permission for outside visiting), Step4, Setup STB, Open DMP function STB: Main menu ...
  • Page 24 Menu Operations Step 1 and Step2 is same as DMP testing. Step3: Main menu  Application  DLNA  DMR, you can see a window as below, keep it. Step4, A: iPhone: Open the DLNA Tool in the phone,will see the pictures as below, This step is asking you choose the media resource, get into it ...
  • Page 25 Menu Operations  The picture as below, it‟s a media list in the iPhone, choose a file and play it, B : Android Phone: Open the DLNA Tool in the phone,will see the pictures as below, This step is asking you choose the media resource, get into it  the next step is choose Media player.
  • Page 26: Dailymotion

    Menu Operations 6.6 Dailymotion Dailymotion is a video-sharing website on which users can upload, watch and share videos. 6.7 KartinaTV Kartina TV is Russian Internet Television via Internet. The figure as below: 6.8 VIMEO Vimeo is a respectful community of creative people who are passionate about sharing the videos they make.
  • Page 27: Online Video

    Menu Operations 6.9 Online Video This option access the Online Video. 6.10 Photo The Photo module is for playing image files stored on the USB (CARD) device. Most popular image formats are all supported. In the Module Select Area, press [◄/►] keys to select the Photo type, then press [OK] or [▼] keys to enter the image file list area.
  • Page 28: Weather

    Menu Operations map; press the blue function key to save the current map; [▲/▼] & [◄/►] keys to move the focus in the map to view different locations. 6.12 Weather The Weather module provides weather forecast information for users. To enter this module, select the Weather item in the Network menu by pressing [◄/►] keys and then press [OK] key.
  • Page 29: Iptv

    Menu Operations 6.15 IPTV This function is free Internet TV 6.16 ISO ISO can play some files, such as CD or something like that. 6.17 Ebook The EBook module is for reading electronic books. TXT format is available. Turning pages: Press PAGE+/- keys to turn page up and down. ...
  • Page 30: Setting

    Menu Operations 7. Setting The Main Menu has six items: Installation, Channel, System Setting, Tool, Media, and Net Work, which include all setting items of the system. Press [MENU] key to display the Main Menu, see the figure below: 7.1 Installation Press [▲/▼] keys in the Main Menu to highlight the Installation item and then press [OK] or [►] keys.
  • Page 31: Antenna Setting

    Menu Operations 7.1.1 Antenna Setting In the Installation menu press [▲/▼] keys to highlight the Antenna Setting sub-menu and then press [OK] or [ ►] keys to enter the Antenna Setting. In the Antenna Setting page, you can press [▲/▼] keys to highlight a scan criteria and then press [OK] or [ ►] key to enter corresponding editing state.
  • Page 32 Menu Operations The Satellite List (see figure above) shows all the satellites the system has stored. Users can press color function keys on the remote controller to edit the list, [red function] key: add a satellite Press [red function] key, set the position and longitude of satellite, the default satellite name is new satellite, you can press [red function] key again to rename it.
  • Page 33: Transponder List

    Menu Operations 7.1.3 Transponder List In the Installation menu, press [▲/▼] keys to highlight the Transponder List item And then press [OK] or [►] keys to enter the Transponder List page. See the figure below. The Transponder List stores the transponders of current satellite of current system. Each transponder may have multiple frequencies.
  • Page 34: Motor Setting

    Menu Operations [Green function] key: edit a Transponder [Yellow function] key: delete a Transponder Scan channel by Transponder Press [▲/▼] keys to highlight the Transponder which you want to scan channel, Press [blue] key, the scan window display, select correct scan criteria, press [ok] button, the system will begin to scan channel of this Transponder, 7.1.4 Motor Setting Through the Motor Setting page you can control the polar axis motor to adjust the direction of...
  • Page 35: Limit Setup

    Menu Operations 7.1.5 Limit Setup There are three sub items: Limit Setup: Polar axis move limit setting. Continuing Move: Enable polar axis continuous move. Move Step: Enable polar axis step move. After setting, you can press [◄/►] keys to move the polar axis east or west step by step.
  • Page 36: Channel Manager

    Menu Operations 7.2.1 Channel Manager The system provides powerful channel management function. You can through the Channel Manager menu to manage your channels such as deleting, locking, sorting, skipping or renaming. To enter the Channel Manager Menu, in the Channel menu press [▲/▼] keys to select the Channel Manager Item and then press [OK] key.
  • Page 37: Channel Editor

    Menu Operations [Blue function] key: Edit channel Press [▲/▼] keys to select the channel and then press the blue function key to enter the channel name edit page.See the figure below: After editing, press [ok] key to confirm.  Press Menu key to exit the Channel Manager menu. ...
  • Page 38: Favorite List

    Menu Operations  To add a new channel, press red color function key to enter the add channel page. See the figure below.  To edit a channel, press ▲/▼ keys to select the channel, then press the green function key to enter the channel edit page.
  • Page 39: Channel Setup

    Menu Operations Rename the name of Favorite List Select the Favorite List you want to rename by number 1-8 on RCU, press [red function] key to rename it 7.2.4 Channel Setup This item is to set the default channel after the system boots. By default, after the system boots, the channel that is being played before the previous turning off will be auto played.
  • Page 40: Audio

    Menu Operations 7.3 Audio Press[▲/▼] key to highlight the Audio menu, press [ok] or [ ►] to enter sub-menu. 7.3.1 1Preferred Audio The Preferred Audio Subtitle is used to set the default audio language. When a program has audios of multiple languages, the system will auto search the matched audio to play according to the settings here.
  • Page 41: Hard Hearing

    Menu Operations 7.3.3 Hard Hearing The Hard Hearing item provides a kind of subtitle display service special for hearing impairment users, available when the streaming includes this service. 7.3.4 Volume Set The Volume Set item provides System and Program two choices. 7.3.5 HDMI Audio The HDMI audio item is to set the output format of audios.
  • Page 42: Spdif

    Menu Operations 7.3.6 SPDIF The SPDIF item is to set the output format of digital audios. After highlighting this item, press [OK] key to pop out an option list: The list has three options: PCM, Bitstream and Mute. 7.4 Video Press [▲/▼] key to highlight the system setting main menu and press [ok] or [►] to enter sub-menu.
  • Page 43: Video Output

    Menu Operations The list has two options: 16: 9, Full Screen. 7.4.2 Video Output The Video Output item is to set the format of video output. 7.4.3 Video Resolution The Video Resolution item is to set the resolution (up to 1080p_60 (Full HD)) and refresh rate of video output.
  • Page 44: Contrast

    Menu Operations 7.4.4 Contrast The Contrast item determines the contrast level of the system. After highlighting the Contrast item, press [OK] key to enter its setting interface: 7.4.5 Brightness The Brightness item is to adjust the brightness level of the system. After highlighting the Brightness item, press [OK] key to enter its setting interface, see the figure below: Press [◄/►] keys to adjust the brightness level from 0 to 24.
  • Page 45: Hue

    Menu Operations 7.4.7 HUE The HUE item is to adjust the hue level of the system from -30 to 30. After highlighting this item, press [OK] key to enter its setting interface: 7.4.8 SHARPNESS The Sharpness item is to adjust the Sharpness level of the system. After highlighting the Brightness item, press [OK] key to enter its setting interface: In addition, in this interface press [▲/▼] keys can switch among Contrast, Brightness, Saturation, Hue and Sharpness.
  • Page 46: Osd Transparency

    Menu Operations 7.5.1 OSD Transparency Through the OSD Transparency sub-menu you can adjust the transparency of OSD display in the Main Menu. To change the OSD transparency, press [▲/▼] keys to highlight the OSD Transparency item and then press [ok] or [ ►] keys to pull down a transparency list. The list has seven transparency levels from 0% to 60%.The bigger the level value is ,the higher the transparency is, After selecting a transparency ,press [OK] key to confirm.
  • Page 47: 2Preferred Audio

    Menu Operations To change preferred subtitle languages, press [▲/▼] keys to highlight the Preferred Subtitle sub-menu and then press [ok] or [ ► ] keys to pull down a language list. In this list, you can press [▲/▼] keys to select a desired language and then press [OK] key to confirm. 7.5.3 2Preferred Audio The 2Preferred Audio Subtitle is used to set the default audio language.
  • Page 48: System

    Menu Operations 8. System Press[▲/▼] key to highlight the system main menu, press [ok] or [ ►] to enter sub-menu. 8.1 Date Time Setup the date time setting of system Date Time Mode Auto: both the Date and Time items will be set automatically (cannot be set by hand),you can set up time Zone and Day light saving item Manual: users can set the Date and Time items by hand, but Time Zone and Day light saving item cannot be set.
  • Page 49: Child Lock

    Menu Operations Program Name indicates the scheduled program. Data and Time indicate the scheduled time. Mode indicates the frequency of schedule: Once, Daily, Weekly or Monthly. Type indicates the behaviors after the scheduled time is reached. 8.3 Child Lock The Child Lock sub-menu is to set a program lock in order to protect children from watching some improper programs to their ages.
  • Page 50: Upgrade

    Menu Operations In this dialog, enter the correct old password first and then give a new password twice. Thus the password is changed completely. 8.4 Upgrade Carry out system software upgrade. At present the system supports three methods to upgrade the system software: USB Upgrade, Net Upgrade.
  • Page 51: Auto Standby

    Menu Operations 8.6 Auto Standby The Auto Standby item is to set the system enter the standby mode when the period is expired, you can chose “off”,”1hr”,”2 hr ”,”3 hr”. 8.7 Standby Display The Auto Standby item sets whether the system will enter the standby mode if there is no any operation for a certain time period.
  • Page 52: Multi Media

    Menu Operations If Network is connected, it should get the correct IP address and display the “ Network Connect success” 8.9 Multi Media The Multimedia item is only for the Multimedia Mode. Main parameter included:  MovieRepeat: Set repeat mode for movie playback. Three options: Dir, One, OFF. MusicRepeat: Set repeat mode for music playback.
  • Page 53: Pvr Config

    Menu Operations 8.10 PVR Config Through the PVR Config item you can do some settings on Timeshift and Record functions. PVR File Format: Set the format of record files , TS or PS. File Size: Set the size of a single record file. Four Options:1G,2G,3G or 4G.. Timeshift: Set a method to start the timeshift function.
  • Page 54: Troubleshooting

    Troubleshooting 9. Troubleshooting There may be various reasons behind receiver problems. Check the receiver according to the procedures described below. If you can‟t solve your problem even after following the troubleshooting procedures, please contact the dealer, Do not open the receiver cover, it may cause a dangerous situation.
  • Page 55 Troubleshooting 5) The remote controller does not operate --The batteries of the remote controller are not inserted or exhausted Check whether the batteries are inserted correctly in your remote controller. Check and replace the batteries of the remote controller 6) Poor picture quality / Less channels in scanning -- Signal loss cable Change the antenna power in antenna menu...
  • Page 56: Technical Specification

    Technical Specification 10. Technical Specification VIDEO Decoding MPEG-4 & MPEG-2 & MEPG-1 compatible Bit rate Max 15Mbps Output PAL/NTSC Aspect ratio 4:3, 16:9, Auto Active pixel SD: 720x480 @ 30fps; 720x576 @ 25fps HD: 480p, 576p, 720i, 720p, 1080i,1080p Output connector RCA, HDMI AUDIO Decoding...
