Mitel SX-200 Installation And Manual
Dnic integration
using d/82u voice cards
elite, innline 2020 & innline express voice mail
pbx installation and testing guide
Hide thumbs
Also See for SX-200:
- Practices (1206 pages) ,
- Documentation (760 pages) ,
- Technician's handbook (426 pages)
Related Manuals for Mitel SX-200
Summary of Contents for Mitel SX-200
- Page 1 Elite, InnLine 2020 & InnLine Express Voice Mail PBX Installation and Testing Guide Mitel SX-200 DNIC Integration Using D/82U voice cards...
- Page 2 REQUIREMENTS: ♦ G1005 (LW15) F19 and above. ♦ If SX-200 ICP, System Option 98 (9109-532-012-NA) is required. ♦ A DNIC station (programmed as an SS430 set) for each voicemail port. ♦ An analog extension (or dedicated CO line) for the system’s modem.
- Page 3 Elite, InnLine 2020 & InnLine Express PBX Installation Guide 04/27/2005 Voicemail User COS Programming – Form 03 Enable the following COS options for all voice mail users: ¨ Enable Option 206 (CALL FORWARDING – BUSY) ¨ Enable Option 207 (CALL FORWARDING – DON’T ANSWER) ¨...
- Page 4 Elite, InnLine 2020 & InnLine Express PBX Installation Guide 04/27/2005 TERMINATIONS: All DNIC voicemail stations must be connected to 66 style punch-down blocks. These blocks must have a 25 pair female amp connector on the side. For every 8 DNIC voicemail stations, one 66 block with a female amp connector is required.
- Page 5 Elite, InnLine 2020 & InnLine Express PBX Installation Guide 04/27/2005 TESTING: Testing DNIC port sync with the D/82U card(s) On the back of each D/82U voice card, there is a green 2 digit LED display, directly above the 36- position mini D cable plug. When the system is on, the first card that has the first 8 DNIC ports connected to it should read 00 if the card can properly read each DNIC station.
- Page 6 To test message lamps, enter the SEND MESSAGE feature access code in both Dial String Prefix fields of the Indicator On and Indicator Off sections, found under the MWI tab of the Mitel SX-200 DNIC D/82 port type. In the example below, *2 is the SEND MESSAGE feature code, followed by a 1 for ON, or a 2 for OFF.
- Page 7 Elite, InnLine 2020 & InnLine Express PBX Installation Guide 04/27/2005 After confirming the correct SEND MESSAGE code, test a message lamp by going to System > Tenants > Tenant 1 > Mailboxes. Double click the Set MWI(s) icon. Enter a valid extension number and test turning the message lamp on and off. The following information will be displayed on the “Monitor”...
