Error Message Description

Messages
A.G.A. NOT OPER.
ADJUST THE GAP
BUFFER OVERFLOW
CHARACTER LOST
DATA SET OFF
INTERLOCK ERROR
CHECK INSERTION
NOPATH AVAILABLE
NO PATH AVAILABLE
PATH CHANGING
70
Indication
The automatic gap adjustment
(A.G.A) is not enabled.
An overflow condition occurs
in the buffer (if the serial
interface is selected).
The DSR Signal is not
connected to the printer and is
not ready for data transfer (if
the serial interface is
selected). This condition may
happen in a remote connection
(via modem) and the DSR
(DATA SET READY) signal is
missing.
Neither the rear tractor nor
the tractor cover are installed
on the printer.
An electromechanical failure
occurs in the lower or upper
tractor paper paths.
An electromechanical failure
occurs in the lower tractor
paper path. The printer
changes automatically to the
cut sheet paths (Manual or
ASF).
Solution
Press the ON LINE key to reset the error
condition. Adjust the print head gap to a
fixed distance. Select the print head gap
adjustment in the Program Menu.
•
Press the PROGRAM key when the
printer is disabled (READY indicator
unlit) to enter the Program Setup.
• Press the ↓ key until the USER MACRO
function is displayed. Press the → key
until the desired macro is displayed
(MACRO# x ).
• Press the → key to enter the macro
parameters.
• Press the ↓ key until the FIXED GAP
parameter is displayed.
• Press the → o ← keys to select the
fixed gap adjustment values. From
FIXED GAP 1 (simple fanfold) to
FIXED GAP 4 (multipart fanfold).
Turn the printer off and on again, or press
the PROGRAM and ON LINE key
successively and the buffer will be cleared.
Press the ONLINE key to reset the error
condition.
Install the rear tractor or the tractor cover
on the printer.
Call Service.
Call Service.
