Paper Perforation
When printing on fanfold paper this function allows to move the print head
aside the paper when the paper perforation passes between the mylar and
the print bar, to avoid paper jams. If the use of single sheets is selected, this
item is not displayed.
STRONG IMPACT
↑
PERFOR. SAFE NO
PERFOR. SAFE YES
↓
AUTOGAP 0
PERFOR. SAFE NO
PERFOR. SAFE YES
Adjusting the Distance of the Print Head
PERFOR. SAFE NO
↑
AUTOGAP -5
AUTOGAP ...
AUTOGAP +3
MANUAL GAP
FIXED GAP 0.3
FIXED GAP ...
FIXED GAP 9.3
↓
TUNING.HORIZ 0
AUTOGAP xxx
Selecting one of these values sensing the paper thickness.
Negative values reduce the distance between the print
head and the paper. Default value AUTOGAP 0.
MANUAL GAP
Selecting this item, the print head must be adjusted
manually.
FIXED GAP xxx
Selecting one of these values the printer adjusts the print
head gap to a fixed distance.
A78408098-005
→ or ←
→ or ←
The function is disabled. The print head remains in
its position, when the perforation of the paper
passes.
The function is enabled. The print head is moved
aside, when the perforation passes.
→ or ←
→ or ←
→ or ←
→ or ←
→ or ←
→ or ←
→ or ←
Configuring the Printer
