About Swift A200
2.4.

Panels

FRONT PANEL
1
1. OLED display that shows connection status and self-check information.
2. Micro-B USB port used to connect the device to a computer.
REAR PANEL
1
1. DC power inlet.
2. Audio In and Audio Out for an analog two-way radio (not supported).
3. Micro-Fit 3mm pitch connector for 12VDC supply and/or external hardware.
4. LAN port.
5. USB port for a MOTOTRBO radio.
TRBOnet Swift A200 — User Manual
2
3 4
2
5
4
