VHF 315 SERIES
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VHF 315 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garmin VHF 315 Series

Summary of Contents for Garmin VHF 315 Series

  • Page 1 VHF 315 SERIES Owner’s Manual...
  • Page 2 © 2018 Garmin Ltd. or its subsidiaries All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to www.garmin.com...

  • Page 3: Table Of Contents

    Table of Contents Distress Calls........10 Sending an Undesignated Distress Call............. 11 Introduction........1 Sending a Designated Distress Handset Overview........2 Call............. 11 Home Screen...........3 Waiting For and Receiving and System Status Icons......4 Acknowledgment for a Distress Call............. 11 Basic Operation........4 Stopping Automatic Retransmission Turning On and Off the Device....
  • Page 4 Changing a Channel Name....23 Restoring Factory Settings....23 Appendix........23 Alarms and Messages......23 Channel Lists........23 Channel Prefixes....... 23 VHF 315 Series Specifications.... 24 NMEA.............24 NMEA 0183 IN Sentences Supported.......... 24 NMEA 0183 OUT Sentences Supported.......... 24 NMEA 2000 PGN Information..25 Cleaning the Outer Casing....

  • Page 5: Introduction

    Introduction WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Introduction...

  • Page 6: Handset Overview

    Handset Overview Item Key Description Hold to broadcast. Lift the door and press to send a DSC distress call with a programmed MMSI DISTRESS number (Entering Your MMSI Number, page 10). Press the key that corresponds to the on-screen item to select the item. On the home screen, rotate to change the channel.

  • Page 7: Home Screen

    Home Screen Radio system status, settings, and alerts International, Canadian, or USA frequency band Latitude Longitude Time Speed over ground (SOG) or course over ground (COG) Soft-key functions change depending on your current activity Working channel The latitude, longitude, and time appear when the radio has a GPS signal acquired. You can enter data manually when the radio does not have a GPS signal. The SOG and COG appear when the radio has a GPS signal acquired, and the option is enabled in the menu (Number Settings, page 22).

  • Page 8: System Status Icons

    System Status Icons Icon Status Receiving an incoming signal Transmitting Transmitting at 25 W Transmitting at 1 W Saved channel Local receiver mode, often used in areas with radio frequency interference (harbors) ATIS enabled Position tracking enabled Auto channel changing disabled Incoming or missed DSC call Weather alerts enabled GPS signal acquired...

  • Page 9: Adjusting The Squelch Level

    Adjusting the Squelch Level You can adjust the sensitivity level of the squelch to filter out background noise. When you increase the squelch level, you hear fewer weak background signals when you are receiving. 1 Select VOL/SQ. SQUELCH appears on the screen. 2 Turn the dial counter-clockwise until you hear audio.

  • Page 10: Saving A Channel

    Saving a Channel You can save any channel except the weather (WX) channels. You can save an unlimited number of channels. 1 Select SCAN. 2 Turn the ENTER dial until you find a channel you want to save. 3 Select SAV CH. appears above a saved channel.

  • Page 11: Selecting A Different Second-Priority Channel

    Selecting a Different Second-Priority Channel You can select a channel other than channel 9 as your second-priority channel. 1 Select MENU > CHANNEL > 2ND PRIORITY. 2 Turn the ENTER dial to the preferred channel. 3 Select OK. Switching to Priority Channels You can quickly switch between your current working channel and a priority channel.

  • Page 12: Bypassing The Low Transmission Power Setting

    Using the Hailer Function Before you can use the hailer function, you must install a hailer horn (optional). For more information, see the VHF 315 Series Installation Instructions. A hailer horn allows you to make on-boat or ship-to-shore announcements, and allows two-way communications between connected radios.

  • Page 13: Adjusting The Sound Frequency Of The Foghorn

    Adjusting the Sound Frequency of the Foghorn You can increase or decrease the sound frequency of the foghorn. The pitch of the tone rises with an increase in frequency, and falls with a decrease in frequency. The minimum setting is 200 Hz, and the maximum setting is 850 Hz.

  • Page 14: Digital Selective Calling

    Entering Your MMSI Number NOTICE You can enter your MMSI number only once. If you must change your MMSI number after entering it, you must take your radio to your Garmin dealer for reprogramming. ® The Mobile Marine Safety Identity (MMSI) number is a nine-digit code that acts as a DSC self-identification number, and it is required to use the DSC capabilities of your radio.

  • Page 15: Sending An Undesignated Distress Call

    Sending an Undesignated Distress Call When you send an undesignated distress call, the nature of your emergency is not transmitted to the receiving stations. Sending an undesignated distress call is a faster procedure that can save you time during an emergency.

  • Page 16: Stopping Automatic Retransmission Of Distress Calls

    Stopping Automatic Retransmission of Distress Calls Select CANCEL. The radio remains tuned to channel 16. NOTE: Selecting CANCEL ends the automatic repetition of the call, but does not communicate to other stations that you no longer have an emergency. If you no longer have an emergency, you should revoke the distress call (Revoking a Distress Call, page 12).

  • Page 17: Placing Group Calls

    Position data received from stations that respond to position request calls is sent over the NMEA ® network. You can track the vessels on your Garmin chartplotter. 1 Select DSC > POS. REQUEST. 2 Select an option: • To enter the MMSI number manually, select MANUAL, enter the MMSI number, and select ACCEPT.

  • Page 18: Receiving Calls

    Receiving Calls Receiving Distress Calls and Distress Relay Calls When receiving a distress call or a distress relay call, DISTRESS or DISTR RELAY, and information about the call, such as MMSI number and the nature of the distress, appear on the radio screen. A distress call is sent from a vessel in need of assistance, and a distress relay call is sent from either another vessel or a station on behalf of a vessel in need of assistance.

  • Page 19: Receiving Position Requests

    When you enable position tracking, the radio uses interval-based position requests to track up to three vessels. Your radio transmits received position data over the NMEA network, and you can track the vessels using your Garmin chartplotter (Configuring DSC NMEA Transmissions, page 21).

  • Page 20: Viewing And Deactivating Vessels On The Position Tracking List

    Position-Tracking Polling Interval Sequence Regulations allow transmission of one position-request call every five minutes. When tracking more than one vessel, the radio alternates calling each vessel in the list at five-minute intervals. If a vessel does not respond to five consecutive position-request calls, the radio removes the vessel from the position-tracking list. You can use this table to better understand how the time interval is applied to the vessels in the position- tracking list.

  • Page 21: Call Log

    Call Log When the radio receives a DSC call, it records the date and time, calling station, and type of call in the call log. The radio also records the latitude and longitude of the calling station if that data is transmitted with the call. DSC calls are logged as distress, position, or other calls.

  • Page 22: Saving A Vessel Or Station To The Directory From The Call Log

    Saving a Vessel or Station to the Directory from the Call Log 1 Select DSC > CALL LOG. 2 Select a call-log category. 3 Select the MMSI number you want to save. 4 Select SAVE. 5 Enter or edit the name for the saved vessel or station (optional) (Entering Text, page Deleting a Call Log Entry 1 Select DSC.

  • Page 23: Editing A Group

    Editing a Group 1 Select DSC > GROUP > EDIT ENTRY. 2 Select a group. 3 Edit the group MMSI number, the name, or both (Entering Text, page 4 Select ACCEPT. Deleting a Group 1 Select DSC > GROUP > DELETE. 2 Select a group.

  • Page 24: Automatic Transmitter Identification System

    Garmin dealer for reprogramming. NOTE: You can access the ATIS settings on the radio after the ATIS feature is activated by your Garmin dealer. 1 Select MENU > ATIS > MY ATIS ID.

  • Page 25: Nmea 0183 And Nmea 2000

    When you connect the radio to the same NMEA 2000 network as a Garmin chartplotter, and you initiate a man- overboard distress call from the radio, the chartplotter prompts you to navigate to the man-overboard location.

  • Page 26: System Settings

    System Settings Select MENU > SYSTEM. DISPLAY: Sets the backlight and contrast levels. BEEPER: Sets the volume or disables the beeper tone that sounds when you press a key or turn a dial. AUTO POWER-ON: Sets the radio to turn on automatically when it receives power. LANGUAGE: Sets the language for the radio.

  • Page 27: Changing A Channel Name

    Changing a Channel Name Channel names appear on the home screen using nine characters. If a channel name is longer than nine characters, the full name scrolls across the top of the screen, then switches to the short name. You can change the name of a channel to reflect a local meaning.

  • Page 28: Vhf 315 Series Specifications

    Recommended minimum specific GNSS data NMEA 0183 OUT Sentences Supported Sentence Definition DSC information Expanded DSC The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating. Appendix...

  • Page 29: Nmea 2000 Pgn Information

    NMEA 2000 PGN Information Transmit Description 059392 ISO acknowledgment 060928 ISO address claim 126208 NMEA request/command/ack 126464 PGN list 126996 Product information 129799 Radio frequency/mode/power 129808 DSC call information Receive Description 059392 ISO acknowledgment 059904 ISO request 060928 ISO address claim 126208 NMEA request/command/ack 129026...

  • Page 30: Index

    Index safety call 13 settings 5, 22 squelch 5 alarms 23 system information 4 automatic transmitter identification system settings 22 system 20 text, entering 9 backlight 22 time beeper 22 setting 22 zone 22 watch 6 call log 17, 18 channels 5, 23 16/9 7 units of measure 22 16+ 7 urgency call 13 Canada 13 International 13 monitoring 6 VHF radio power 7 individual routine call 5...
  • Page 32 April 2021 GUID-2427D940-C342-48E4-ACB0-3B1CC0ABDD5F v3...
