Table Of Contents - Immergas VICTRIX ZEUS 26 2 ERP Instruction And Recommendation Booklet

INDEX
INSTALLER
1 Boiler installation ....................................... 5
1.1 Installation recommendations. ................. 5
1.2 Main dimensions. ...................................... 6
1.3 Anti-freeze protection. ............................... 6
1.4 Gas connection. .......................................... 7
1.5 Hydraulic connection. ................................ 7
1.6 Electrical connection. ................................ 7
1.7 Remote controls and room
chrono-thermostats (Optional). ............... 8
1.8 External temperature probe
(Optional). ................................................... 8
1.9 Immergas flue systems. ............................. 9
1.10 Tables of resistance factors
and equivalent lengths. .............................. 9
1.11 Outdoor installation
in a partially protected area. ....................11
1.12 Concentric horizontal kit installation. ...12
1.13 Concentric vertical kit installation. ........13
1.14 Separator kit installation. .........................14
1.15 Adaptor C9 kit installation. ....................15
1.16 Ducting of flues or technical slots. .........16
1.17 Configuration type B, open
chamber and fan assisted for indoors. ...16
1.18 Flue gas exhaust to flue/chimney. ...........16
1.19 Flues, chimneys, chimney
pots and terminals. ...................................17
1.20 System filling. ............................................17
1.21 Condensate trap filling. ............................17
1.22 Gas system start-up. .................................17
1.23 Boiler start up (ignition). .........................17
1.24 Domestic hot water storage tank unit. ...17
1.25 Kits available on request. .........................17
1.26 Circulation pump......................................18
1.27 Boiler components. ...................................20
USER
page
2 Use and maintenance instructions .........21
2.1 Cleaning and maintenance. .....................21
2.2 General warnings. .....................................21
2.3 Control panel.............................................21
2.4 Ignition of the boiler. ................................22
2.5 Troubleshooting. .......................................22
2.6 Boiler shutdown ........................................23
2.7 Restoring central heating
system pressure. ............................................ 23
2.8 System draining. ......................................23
2.9 Storage tank draining. ..............................23
2.10 Anti-freeze protection. .............................23
2.11 Case cleaning. ............................................23
2.12 Decommissioning. ....................................23
MAINTENANCE TECHNICIAN
page
3
3.1 Plumbing diagram. ...................................24
3.2 Wiring diagram. ........................................25
3.3 Troubleshooting. .......................................25
3.4 Converting the boiler
3.5 Calibration phase. .....................................26
3.6 Nominal heat output calibration. ...........26
3.7 Adjustment of the air-gas ratio. ..............27
3.8 Checks following conversion
3.9 Pump operating mode. ............................27
3.10 Domestic hot water mode
3.11 Solar panels
3.12 ''Chimney sweep'' function. .....................27
3.13 Pump anti-lock function. ........................27
3.14 Three-way anti-block function. ..............27
3.15 Permanent reduction of
3.16 Radiators antifreeze function. .................27
3.17 Flow temperature value
3.18 Yearly appliance check
3.19 Casing removal. ........................................29
3.20 Variable heat output. ................................30
3.21 Combustion parameters. ........................30
3.22 Technical data. ..........................................31
3.23 Key for data plate. .....................................32
3.24 Technical parameters for mixed boilers
3.25 Product data sheet (in compliance
3.26 Parameters for filling in
4
Boiler start-up (initial check) ..................24
to other types of gas. .................................26
to another type of gas. ..............................27
selector switch ............................................. 27
coupling function. ....................................27
timing function. ........................................27
in central heating mode. ..........................27
and maintenance. ......................................28
(in compliance with Regulation
813/2013). ..................................................33
with Regulation 811/2013). .....................33
the assembly sheet. ...................................34
page
