- Page 1 Model Two/M Model Three/M Model Two/MH Model Three/MH ACOUSTAT Modular Hybrid Speaker Systems OWNER'S MANUAL ASS EM BLY I NSTR U CTlON...
-
Page 2: Table Of Contents
... . . Removel of Interface for Models Two/M & ThreeIM .... -
Page 3: Introduction
Please complete and return the enclosed purchase registration card within ten days of purchase of your new speakers. Thi s card does not determine your eligibilityfor waranty but will allow Acoustat to inform you of updates and other product news that would be of interest to speaker owners. Any additional information you provide will aid the Acoustat Corporation in continuing to bring music lovers everywhere the finest audio components available today. - Page 4 5. CAREFULLY turn the speaker over, so that the back side is facing up. Remove one the MK-121 Interface units from its carton and set aside the hardware needed Place the lnterface unit on the floor at the base of the speaker. with the opening of the unit facing the back of the speaker. You will notice three groups of wires extending through the rubber grommet on the speaker's firewall plate (lower rear area).
-
Page 5: For Models Two/M H Three/M
Refer to "Recommended Set-Up and Speaker Placement" for room placement suggestions. When you have determined where the speaker will beplaced. plug the interface unit into a live wall outlet. The system should remain plugged in ALL times for proper performance. NOTE The current draw of the MK-121 Interface unitis very low: about five watts Set the High Frequency balance pot on the interface at approximately the one o'clock position for your initial listening tests. - Page 6 8. lnstall a small flat washer on each long screw. Insert one of these assemblies through the bottom right hole on the base (the hole on the side of the base with the Acoustat nameplate), Align this screw with the right-most hole on the bottom of the speaker's frame. Using a flat blade screwdriver, screw L O O S E L Y intoframe.
- Page 7 9. Now, C A R E F U L L V stand the speaker back to an upright position, and then, lean the system forward until the topedgeof speakerrestsonceagainon thefloor. Select the two casters and two largeflat washers from the hardware kit. Note that each caster has a nut on its threaded stem. Install the flat washer over the caster's stem and screw the caster/washer assembly into the wood block on the bottom of the woofer box not yet tighten the lock-nut to secure caster.
-
Page 8: Recommended Set-Up And Speaker Placement
RECOMMENDED SET-UP AND SPEAKER PLACEMENT DISTANCE FROM WALL Leave at least three feet from the speakers to the rear wall. T o determine this distance. measure from the center of the back of the speaker r to the rear walll, This measurement should betakenona perpendicular to the speaker. -
Page 9: Electric Feedback
IN POSITION A THE SPEAKERS WOULD HAM TO BE ANGLED IN SLIGHTLY. PHASi N G Acoustat speakers are designed topreserve thecorrect absolute phase throughout the system, including the final coupling of the signal to the air. Thi s ensures that both vocalists and instruments will sound natural possible. -
Page 10: For Models Two/Mh & Three/Mh
U s e a cleaner such as K2R for small concentrated spots. REMOVAL INTERFACE F O R MODELS TWO/M & THREE/M WARNING ALWAYS U N P L U G THE L I N ECORD B E F O R E REMOVNG... -
Page 11: Specifications
SPECIFICATIONS MODEL TWO/M- Frequency Response: 35-20 KHz +/- 2 dB ; Sound Pressure Level: 108 dB 18’ in a 14 x22 " room. (Program Material Peaks); Minimum Power Requirements 100 Watts Per Channel; Nomlnal Impedance: Ohms Power Consumption: 5 (120v. - Page 13 Acoustat southwest Terrace Lauderdale, 3101 First Fort Florida 33315 Phone: (305) 462-6700 Free Toll (800) 327-3136...
