BODY / STEERING / SUSPENSION
6. Remove the four bolts that secure the brake disc
(C) to the rear disc hub and remove the brake disc.
NOTE: It is not necessary to remove the brake disc
at this time, only remove it if needed.
C
7. Loosen and remove the axle nut (D) with a 1 3/4"
Wrench (PN 2870772).
8. Remove the retaining ring (E) and caliper
mounting bracket (F).
F
5.14
9. Remove the O--ring (G) from the axle assembly.
10. Remove the four bolts that secure the sprocket.
D
11. Slide the sprocket off the axle, if needed. NOTE:
Only remove sprocket if replacing with new
sprocket.
12. Loosen the concentric clamp bolts (H). Slide the
axle through the rear axle housing on the sprocket
side.
E
Bolts
E
G
