Matrix 2016 5x Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2 0 1 6 5 x c o n s o l e
s e R V I c e M A n U A l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2016 5x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix 2016 5x

Summary of Contents for Matrix 2016 5x

  • Page 1 2 0 1 6 5 x c o n s o l e s e R V I c e M A n U A l...

  • Page 2: Table Of Contents

    TAble of conTenTs cHAPTeR 1: seRIAl nUMbeR locATIon ............1 cHAPTeR 2: IMPoRTAnT sAfeTy InsTRUcTIons Electrical Requirements ..................... 2 cHAPTeR 3: PReVenTATIVe MAInTenAnce Recommended Cleaning Tips ..................3 Check for Damaged Parts ..................3 cHAPTeR 4: console oVeRlAy AnD WoRKoUT DescRIPTIon Console Description ....................

  • Page 3: Chapter 1: Serial Number Location

    cHAPTeR 1: seRIAl nUMbeR locATIon 1.1 seRIAl nUMbeR locATIon console serial number location...

  • Page 4: Electrical Requirements

    110 V UnITs All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of a 100-125 V, 60 Hz and a 15 A “Dedicated Circuit”, with a non-looped (isolated) neutral/ground for power. This outlet should be a NEMA 5-15R and have the same configuration as the plug.

  • Page 5: Chapter 3: Preventative Maintenance

    3.2 cHecK foR DAMAgeD PARTs Do noT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems. MAInTAIn lAbels AnD nAMePlATes. Do not remove labels for any reason. They contain important information. If unreadable or missing, contact Matrix Fitness Systems for a replacement.

  • Page 6: Chapter 4: Console Overlay And Workout Description

    cHAPTeR 4: console oVeRlAy AnD WoRKoUT DescRIPTIon 4.1 console DescRIPTIon e.g. A5x console sHoWn 5x console DescRIPTIon WoRKoUT Keys: Simple program view and selection buttons. go: One Touch Start. enTeR: To confirm each program setting. UP/DoWn InclIne (A5x only): Easy information and incline selection.

  • Page 7: Workout Setup Steps - Training Workouts

    4.1 console DescRIPTIon - conTInUeD T5x console DescRIPTIon The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.

  • Page 8: Workout Setup Steps - Manual

    cHAPTeR 4: console oVeRlAy AnD WoRKoUT DescRIPTIon 4.2 WoRKoUT seTUP sTePs - MAnUAl 4.3 WoRKoUT seTUP sTePs - TRAInIng WoRKoUTs - conTInUeD rollinG Hills - Press to immediately begin a workout. Workout, resistance - The Rolling Hills program is a level based program that automatically adjusts the resistance level to simulate level, and time will automatically go to default settings.

  • Page 9: Workout Setup Steps - Fitness Test

    cHAPTeR 4: console oVeRlAy AnD WoRKoUT DescRIPTIon 4.4 WoRKoUT seTUP sTePs - fITness TesT Fitness test -The Cooper Fitness Test measures cardiovascular fitness and proves an estimated sub-maximal VO2 result. It is based on power output according to ACSM standards and was developed by the Cooper Institute© (www.cooperinstitute.org). User RPMs must remain between 60-80 RPM during the test.

  • Page 10: Workout Setup Steps - Target Heart Rate

    4.7 WoRKoUT seTUP sTePs - sPRInT 8 tarGet Heart rate -- below for Hureat5x only - The Matrix heart rate comes with standard digital contact heart rate sensors and are POLAR telemetry sPrint 8 - The 20-minute Sprint 8 workout program is a compatible.

  • Page 11: Workout Setup Steps - 5K Run

    4) This will run the Auto Calibration. If the calibration passes, it will say calibration OK and automatically cycle to the Auto Calibration screen. Press and hold the STOP key to return to the normal start screen. 5) If the calibration does not pass, contact Matrix Customer Technical Support at 866-693-4863 ext 3.

  • Page 12: Chapter 5: Manager Mode

    cHAPTeR 5: MAnAgeR MoDe 5.1 MAnAgeR MoDe oVeRVIeW 1) To enter Manager Mode, press number key "ENTER, 1, 0, 0, 1, ENTER" on the number keypad. Manager Mode will appear on the display. 2) To scroll through the list of options in Manager Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the dis- play.
  • Page 13 cHAPTeR 5: MAnAgeR MoDe 5.1 MAnAgeR MoDe oVeRVIeW 1) To enter Manager Mode, press number key "ENTER, 1, 0, 0, 1, ENTER" on the number keypad. Manager Mode will appear on the display. 2) To scroll through the list of options in Manager Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the dis- play.
  • Page 14 Item2 Default Value Values/Range Unit Notes Logo THURESAC Default Logo MATRIX This option allows the user to select the screen header from a list. THURESAC Import Logo Import logo from USB to console. THURESAC Erase Erase all logo data in EEPROM...
  • Page 15 cHAPTeR 5: MAnAgeR MoDe 5.1 MAnAgeR MoDe oVeRVIeW - conTInUeD Table 1 - Time Zone list Time Zone country code country code country code country code Asia/Kabul America/Chicago Asia/Jerusalem Pacific/Apia America/Anchorage America/Monterrey Asia/Seoul Asia/Bangkok Asia/Kuwait Asia/Shanghai Atlantic/South Georgia Asia/Singapore Asia/Muscat Africa/Nairobi America/Denver Africa/Harare...

  • Page 16: Chapter 6: Engineering Mode

    cHAPTeR 6: engIneeRIng MoDe 6.1 engIneeRIng MoDe oVeRVIeW 1) To enter Engineering Mode, press number key "ENTER, 2, 0, 0, 1, ENTER" on the number keypad. Engineer Mode will appear on the display. 2) To scroll through the list of options in Engineering Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the display.

  • Page 17: Chapter 7: Service Mode/Test Mode

    cHAPTeR 7: seRVIce MoDe/TesT MoDe 7.1 seRVIce MoDe oVeRVIeW 1) To enter Service Mode, press number key "ENTER, 3, 0, 0, 1, ENTER" on the number keypad. Engineer Mode will appear on the display. 2) To scroll through the list of options in Service Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the display.

  • Page 18: Test Mode Overview

    cHAPTeR 7: seRVIce MoDe/TesT MoDe 7.2 TesT MoDe oVeRVIeW 1) To enter Test Mode, press number key "ENTER, 5, 0, 0, 1, ENTER" on the number keypad. Engineer Mode will appear on the display. 2) To scroll through the list of options in Test Mode, use the UP and DOWN LEVEL keys. Each of the custom settings will show on the display. 3) To select a custom setting, press the ENTER key when the desired setting is shown.

  • Page 19: Chapter 8: Troubleshooting

    cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs HURes5x-05/A5x-06-c elecTRIcAl blocK DIAgRAM...
  • Page 20 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD c5x-03-c elecTRIcAl blocK DIAgRAM...
  • Page 21 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs T5x-08-c elecTRIcAl blocK DIAgRAM...
  • Page 22 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD c-sAfe+TV connecT WIRe (HUResAc5x-c) HAnD PUlse WIRe (HUResAc5x-c)
  • Page 23 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD PULse boARD seT (HUResAc5Tx-c)
  • Page 24 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD DIgITAl coMM WIRe (HUResAc5x-c) qUIcKly Key seT (HUResAc3x-c)
  • Page 25 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD Usb WIRe (HUResAc5x-c) HeART RATe PoWeR WIRe (HUResAc5x-c)
  • Page 26 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD PRogRAM KeyPAD (HUResA5x-c)
  • Page 27 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD PRogRAM KeyPAD (c5x-c)
  • Page 28 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD PoWeR WIRe (c5x-c) Ucb lITTle boARD WIRe (T5x-c)
  • Page 29 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD PRogRAM KeyPAD- T5x...
  • Page 30 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD HAnD PULse sensoR WIRe- T5x sAfeTy sWITcH WIRe- T5x...
  • Page 31 cHAPTeR 8: TRoUblesHooTIng 8.1 elecTRIcAl DIAgRAMs - conTInUeD Usb WIRe- T5x...

  • Page 32: Error Codes List

    cHAPTeR 8: TRoUblesHooTIng 8.2 eRRoR coDes lIsT CODE CLASS DESCRIPTION MACHINE SOLUTION It occurs when the calibration time is too long or the calibration distance is too short. Don’t fix the incline motor tube then turn on the power. 01A1 Incline calibration error If the console still shows 01A1, please replace incline motor.
  • Page 33 cHAPTeR 8: TRoUblesHooTIng 8.2 eRRoR coDes lIsT CODE CLASS DESCRIPTION MACHINE SOLUTION Please check the incline motor wire connection between the incline and LCB. Please check the incline motor VR if there’s data. If there’s no data, replace the incline. If there’s data, replace the LCB.
  • Page 34 cHAPTeR 8: TRoUblesHooTIng 8.2 eRRoR coDes lIsT - conTInUeD CODE CLASS DESCRIPTION MACHINE SOLUTION Check the connection of the safety key (emergency stop) switch. If the switch is always open or shorted out, replace the switch. 02B2 Safe key action response If the emergency stop does not resolve the issue, replace the UCB .
  • Page 35 cHAPTeR 8: TRoUblesHooTIng 8.2 eRRoR coDes lIsT - conTInUeD CODE CLASS DESCRIPTION MACHINE SOLUTION 03A5 Failed to load program Console Replace UCB 03A6 Failed to run program Console Replace UCB Change the correct machine type in the console and reboot 03A8 Machine type error ESHURACT...
  • Page 36 cHAPTeR 8: TRoUblesHooTIng 8.2 eRRoR coDe lIsT - conTInUeD CODE CLASS DESCRIPTION MACHINE SOLUTION Enter the Engineer mode disable B Level Error, by pass CLASS A and B error code Communication 0440 Timeout receive packet Check the connection of the console cable at both ends and per- Errors form continuity test.

  • Page 37: Chapter 9: Parts Replacement Guide

    cHAPTeR 9: PARTs RePlAceMenT gUIDe 9.1 console RePlAceMenT 1) Remove the 5 screws holding the console to the frame (Figure A). 2) Disconnect the console cable, ground cable and HR connections from the defective console and remove the console (Figure B). e.g.

  • Page 38: Console Keypad/Overlay Replacement

    cHAPTeR 9: PARTs RePlAceMenT gUIDe 9.2 console KeyPAD/oVeRlAy RePlAceMenT 1) Remove the console as outlined in Section 9.1. 2) Remove the 6 screws holding on the back cover of the console and remove it (Figure A). 3) Unplug the faulty keypad from the UCB - 2 ribbon cables for program (Figure B). fIgURe b fIgURe A 4) Use a razor to remove the faulty keypad / overlay from the console faceplate (Figure C).
  • Page 39 cHAPTeR 9: PARTs RePlAceMenT gUIDe 9.2 console KeyPAD/oVeRlAy RePlAceMenT - conTInUeD 8) Plug the ribbon cables into the UCB (Figures G). 9) Carefully line up the new keypad to the outline in the console faceplate (Figure H). fIgURe g fIgURe H 10) Peel the backing off of the new overlay (Figure I).

  • Page 40: Testing The Unit

    cHAPTeR 9: PARTs RePlAceMenT gUIDe 9.3 TesTIng THe UnIT once THe UnIT oR RePlAceMenT PART Is fUlly InsTAlleD AnD AsseMbleD AnD PRoPeRly PlAceD on THe flooR, Use THe folloWIng InsTRUcTIons To seTUP AnD TesT THe MAcHIne: --for H/U/R/e/s/A5x-c 1) Enter Manager Mode and input the serial number of the console and frame. Also set the Machine Type and verify that the Date and Time are correct.

  • Page 41: Chapter 10: Treadmill Specifications And Assembly Guide

    cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.1 WIfI InsTAllATIon HUResAcT5x WIfI Installation main comPonent list oF WiFi set (Part number #1000366472) Item Parts number Description Q’ty 1000385415 Control Board;;;HF-A11-0;V2.049;;; 1000385417 Control Board;;;V5.0;V2.049;;HF-A11-0; WIFI Aerial;;;;;NB098-2400- 1000385418 300PEX;;HF-A1 1000385725 Foam Tap;;;41x11;;3M 4945; 0000086721 SCREW;RND;M2X0.5PX6L;;PH;;BZN;;...
  • Page 42 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.1 WIfI InsTAllATIon - conTInUeD 10.1.1 HUResAc5x WIfI Installation 1) Plug in the WiFi board (item #1.1 in the table) to the UCB and use the 2 screws (item #2 in the table) to fix it (Figure A). 2) Stick the foam tape (item #1.3 in the table) on the front cover (Figure B).
  • Page 43 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.1 WIfI InsTAllATIon - conTInUeD 10.1.2 T5x WIfI Installation 1) Plug in the WiFi board (item #1.1 in the table) to the UCB and use the 2 screws (item #2 in the table) to fix it (Figure A). 2) Stick the foam tape (item #1.3 in the table) on the front cover (Figure B).
  • Page 44 Step 2: Check your AP data and modifying SSID & Key (password) required by facility Access Point (AP) to 'wifi_set.cfg' files. Once this is completed, put the 'wifi_set.cfg' file to USB flash drive (the access should read \MATRIX\FW\ - Figure B).
  • Page 45 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.1 WIfI InsTAllATIon - conTInUeD 10.1.3 How to set up the “WIfI” function - continued 3. Install WiFi config software for WiFi connection - continued Step 6: Press the <- key on the number keypad to back. Use the Level UP and DOWN keys to select "Import Setting" (Figure G). Step 7: Press enter key to start wifi installation process (Figure H).
  • Page 46 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.1 WIfI InsTAllATIon - conTInUeD 10.1.3 How to set up the “WIfI” function - continued 4. Console WiFi function test - continued Step 3: Enter Manager mode-> Internet -> Signal Strength (Figure C). See if the wireless signal strength is OK (Figure D). Note: For wireless connection quality, the stable signal strength of wireless is necessary.

  • Page 47: Rfid Installation

    cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon 10.2.1 HUResAc5x RfID Installation note: For the Huresac5x rFiD installation first time, you must order and install WiFi set (part number #1000366472) and rFiD set (part number #1000364289) at the same time. the saP # for the WiFi + rFiD kit is 1000390566.
  • Page 48 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.1 HUResAc5x RfID Installation (continued) 1. Stick the foam tape (item #5 in the table) on the UCB as marked in yellow (Figure A). fIgURe A 2. Stick the absorber (item #4 in the table ) on the reader board as marked in yellow (Figure B). 3.
  • Page 49 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.1 HUResAc5x RfID Installation (continued) 6. Connect the Signal connected wire to J8 of UCB (Figure F). 7. Use tape (item #7 in the table) to fix the signal connecting wire to the front cover of the console (Figure G). fIgURe f fIgURe g...
  • Page 50 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.2 T5x RfID Installation note: For the t5x rFiD function used, you must order and install WiFi set (part number #1000366472) and rFiD set (part number #1000364291) at the same time. the saP # for the WiFi + rFiD kit is 1000390648. Including kit WIFI + RFID kit SAP no.
  • Page 51 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.2 T5x RfID Installation (continued) 1. Stick the foam tape (item #5 in the table) on the UCB as marked in yellow (Figure A). fIgURe A 2. Stick the absorber (item #4 in the table) on the reader board as marked in yellow (Figure B). 3.
  • Page 52 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.2 T5x RfID Installation (continued) 6. Connect the Signal connected wire to J8 of UCB (Figure F). 7. Use tape (item #7 in the table) to fix the signal connecting wire to the front cover of the console (Figure G). fIgURe f fIgURe g...
  • Page 53 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.3 How to set up the “RfID” function once the RfID set has been installed, the xID function must be enabled first then RfID can be used. 1. Enable "xID" function Step 1: Enter Service Mode by pressing “enter, 3, 0, 0, 1, enter”.
  • Page 54 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.2 RfID InsTAllATIon - conTInUeD 10.2.3 How to set up the “RfID” function (continued) 2. RFID hardware function test in Test mode and home screen In TEST mode: Step 1: Enter Test Mode by pressing ‘enter, 5, 0, 0, 1, enter’. Step 2: Select “RFID”...

  • Page 55: Huresa5X Mye Tv/Pctv Bracket Installation

    10.3 HUResA5x Mye TV/PcTV bRAcKeT InsTAllATIon InsTRUcTIons The Matrix 5x is capable of having a MYE Entertainment or Web Ready (PCTV) television installed using an integrated bracket. Follow the instructions below to install the TV and TV bracket, and the instructions located in the TV owner's manual to program the television.
  • Page 56 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.3 HUResA5x Mye TV/PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 6) Run the white end from the Y cable through the headphone jack hole in the console plastic, and plug it into the headphone jack sent with the TV bracket set (Figure G).
  • Page 57 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.3 HUResA5x Mye TV/PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 12) Peel off the protective film from the back of the entertainment overlay. Attach the overlay to the console entertainment keypad (Figure M). 13) Plug the ribbon cable into the pins on the UCB (Figure N). Make sure that the pins and ribbon cable are correctly aligned with no pins open on the UCB.
  • Page 58 19) Re-attach the console back to the front using the bottom 6 screws removed in Step 2. note: Be sure to route the wiring so that it is not pinched by the bracket or plastic when installing the top 2 screws (Figure U). The small cover with the Matrix logo that makes up the top of the rear console cover is no longer used with a TV bracket.
  • Page 59 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.3 HUResA5x Mye TV/PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 25) If installing a PCTV, plug the net wire into the back of the TV (Figure Z). note: The net wire is not used if installing a MYE TV, and should be hidden by the plastic covers.

  • Page 60: C5X Mye Tv Bracket Installation

    10.4 c5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons The Matrix ClimbMill is capable of having a MYE Entertainment or Web Ready (PCTV) television installed using an integrated bracket. Follow the instructions below to install the MYE TV and TV bracket, and the instructions located in the TV owner's manual to program the television.
  • Page 61 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.4 c5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 7) Run the white end from the Y cable through the headphone jack hole in the console plastic, and plug it into the headphone jack sent with the TV bracket set (Figure G).
  • Page 62 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.4 c5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 13) Peel off the protective film from the back of the entertainment overlay. Attach the overlay to the console entertainment keypad (Figure M). 14) Plug the ribbon cable into the open pins on the UCB (Figure N). Make sure that the pins and ribbon cable are correctly aligned with no pins open on the UCB.
  • Page 63 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.4 c5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 19) Route the TV controller wire, power wire, and coax cable through the bracket (Figure Q). There should now be a black adaptor (power wire), white RJ45 connector labeled TO TV (controller wire), and coax cable sticking out the top of the bracket. 20) Route the wiring coming out the bottom of the bracket through the ClimbMill frame.
  • Page 64 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.4 c5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 25) Plug the controller wire into the TV (Figure W). 26) Plug the TV power wire coming from the console mast into the 4 pin black connector on the console (Figure X). fIgURe W fIgURe x 27) Attach the adaptor sent with the TV bracket kit to the coax cable coming from the TV (Figure Y).
  • Page 65 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.4 c5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 32) Plug a coax cable with a signal strength of 10 Hz into the base of the unit (Figure CC). 33) Power up the ClimbMill and test for function as outlined in Section 9.20. 34) Enter into Manager Mode (see Section 5.1), and set the TV Source setting for TV (Figure DD) 35) Program the TV as outlined in the TV Owner's Manual.

  • Page 66: C5X Pctv Bracket Installation

    10.5 c5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons The Matrix ClimbMill is capable of having a MYE Entertainment or Web Ready (PCTV) television installed using an integrated bracket. Follow the instructions below to install the TV and TV bracket, and the instructions located in the TV owner's manual to program the television.
  • Page 67 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.5 c5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 6) Run the white end from the Y cable through the headphone jack hole in the console plastic, and plug it into the headphone jack sent with the TV bracket set (Figure G).
  • Page 68 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.5 c5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 12) Route the TV controller wire, net wire, power wire, and coax cable through the bracket (Figure M). There should now be a black adaptor (power wire), white RJ45 connector labeled TO TV (controller wire), yellow RJ45 connector (net wire) and coax cable sticking out the top of the bracket.
  • Page 69 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.5 c5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 18) Plug the controller wire into the PCTV port on the back of the TV (Figure S). 19) Plug the net wire into the NET port on the back of the TV if wired internet will be used (Figure T). fIgURe s fIgURe T 20) If the PCTV will use wireless internet, plug the dongle into the port on the back of the TV (Figure U).
  • Page 70 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.5 c5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 25) Connect the rest of the console cable connections to the console, and install the console using the 5 screws removed in Step 2. 26) Install a back cover onto the TV to cover the wire connections, secure with 4 screws (Figure Y). 27) Plug a coax cable with a signal strength of 10 Hz into the base of the unit (Figure Z).

  • Page 71: T5X Mye Tv Bracket Installation

    10.6 T5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons The Matrix Treadmill is capable of having a MYE Entertainment or Web Ready (PCTV) television installed using an integrated bracket. Follow the instructions below to install the MYE TV and TV bracket and Section 10.7 for installation of a PCTV with a bracket, then use the instructions located in the TV owner's manual to program the TV.
  • Page 72 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.6 T5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 6) Stick the keypad to the cutout in the console plastic and press down to completely adhere the keypad to the plastic (Figure G). 7) Peel the protective film from the back of the entertainment overlay (Figure H). fIgURe g fIgURe H 8) Stick the overlay to the cutout in the console plastic and press down to completely adhere the overlay to the plastic and keypad (Figure I).
  • Page 73 16) Install the console back cover using the 4 screws removed in Step 1 (Figure Q). NOTE: Make sure to route the wiring through the holes in the back cover so that none of the wiring is pinched. The MATRIX logo portion of the back cover will not be used with a TV bracket.
  • Page 74 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.6 T5x Mye TV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 18) Secure the MYE TV on the TV bracket with 4 screws (Figure S). 19) Make sure the tabs of the front plate slide behind the console faceplate to create a seamless look (Figure T). fIgURe s fIgURe T 20) A coax cable with a signal strength of 10 Hz should be run to the treadmill and plugged in next to the power cord.

  • Page 75: T5X Pctv Bracket Installation

    cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.7 T5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons 1) Remove the 4 screws holding the console back cover to the front and remove the console back cover (Figures A & B). fIgURe A fIgURe b 2) Slide the TV bracket between the console frame and the fan frame (Figure C). 3) Secure the TV bracket to the console using the 4 socket head screws sent with the bracket kit (Figure D).
  • Page 76 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.7 T5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 6) Plug the controller wire (this will have a white RJ45 connector on one end) into the UCB and CSafe board (Figure G). note: There is a wire in this location that will need to be removed to plug in the controller wire.
  • Page 77 15) Install the console back cover using the 4 screws removed in Step 1 (Figure Q). note: Make sure to route the wiring through the holes in the back cover so that none of the wiring is pinched (Figure R). The MATRIX logo portion of the back cover will not be used with a TV bracket.
  • Page 78 cHAPTeR 10: sPecIfIcATIons AnD AsseMbly gUIDe 10.7 T5x PcTV bRAcKeT InsTAllATIon InsTRUcTIons - conTInUeD 16) Install the TV back cover using 4 screws (Figure S). 17) Plug the PCTV power wire into the port on the front of the treadmill near the power switch (Figure T). fIgURe s fIgURe T 18) Plug a coax cable with a signal strength of 10 Hz into the front of the treadmill near the power cord (Figure U).

  • Page 79: Chapter 11: Software Upgrade Guide

    30 seconds to allow the machine to completely power down. 1. Create a file on the USB flash drive which will be used. The folders should be MATRIX\FW\UCB (create a folder called MATRIX, then a folder in MATRIX called FW, then a folder in FW called UCB - Figure A).

  • Page 80: Software Upgrade Instructions For Lcb

    30 seconds to allow the machine to completely power down. 1. Create a file on the USB flash drive which will be used. The folders should be MATRIX\FW\LCB (create a folder called MATRIX, then a folder in MATRIX called FW, then a folder in FW called LCB - Figure A).
  • Page 81 noTes...
