E2S D2xS1 Instruction And Service Manual page 2

Maximum Surface Temperature for Dust Applications:
90ºC
3.2 Class / Zone ratings US
The D2xS1 alarm horn complies with the following standards:
ANSI/UL 60079-0-2013
ANSI/UL60079-15-2013
ISA60079-31-2013
The D2X Alarm horn is rated as follows:
Class I, Zone 2 AEx nA IIC T4 Gc (Ta -40ºC to +50°C)
Zone 22 AEx tc IIIC T90°C Dc (Ta -40ºC to +50°C)
Installation must be carried out in compliance with the National
Electric Code.
3.3 Class / Zone ratings Canada
The D2xS1 alarm horn complies with the following standards:
CAN/CSA C22.2 No. 60079-0:11
CAN/CSA C22.2 No. 60079-15:12
CAN/CSA C22.2 No. 60079-31:12
The D2XS1 Alarm horn is rated as follows:
Ex nA IIC T4 Gc X (Ta -40ºC to +50°C)
Ex tc IIIC T90°C Dc (Ta -40ºC to +50°C)
Class II Div 2 EFG T5 (Ta -40ºC to +50°C)
Installation must be carried out in compliance with the
Canadian Electric Code
3.4 Class / Division Ratings for US and Canada
The D2xS1 alarm horn complies with the following standards:-
ANSI/ISA 12.12.01-2013
CSA C22.2 No. 213-M1987
CSA C22.2 No. 157-92:2006
The D2XS1 Alarm horn is rated as follows:
Class I Div 2 ABCD T3C
Class I Div 2 ABCD T4
Class I Div 2 ABCD T4A
Class II Div 2 FG T5
Class II Div 2 FG T6
Class III Div 1 & 2
Installation must be carried out in compliance with the National
Electric Code / Canadian Electric Code
3.5 Ambient Temperature Range:
-40ºC to +70ºC (Class I Div 2 only)
-40ºC to +50ºC
3.6 Ingress Protection Ratings
The product is rated for ingress Protection as follows:
IP rating per EN60529:
Type rating per UL50E / NEMA250:
To maintain the ingress protection rating, the two off M20 cable
entries must be fitted with suitably rated, certified cable entry
and/or blanking devices during installation.
__________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D189-00-001-IS
Ta -40ºC to +70ºC
Ta -40ºC to +65ºC
Ta -40ºC to +50ºC
Ta -40ºC to +50ºC
Ta -40ºC to +45ºC
Ta -40ºC to +50ºC
IP66
4 / 4X / 3R / 13
Issue: 9 01-06-16
3.7 Electrical Ratings
Nominal
Part No.
Voltage
D2xS1DC024 24Vdc
D2xS1DC048 48Vdc
D2xS1AC115 115Vac
D2xS1AC230 230Vac
3.8 Fire Alarm Ratings
The following models are approved for use as audible signal
appliances for fire alarm use – public mode and produce a
sound pressure level above 75dB(A) at 10 feet:
D2xS1DC024
For public mode fire alarm use the temporal pattern tone No.
12 as per the tone table provided in these instructions must be
selected. This tone produces a sound pressure level of 103.6
dB(A) at 10 feet.
4) Special Conditions for Safe Use
Special Condition for safe Use as stated on the Type
Examination Certificate DEMKO 14 ATEX 4786493904X / CoC
IECEx ULD 14.0004X:
End user shall adhere to the manufacturer's installation and
instruction when performing housekeeping to avoid the
potential for hazardous electrostatic charger during cleaning,
by using a damp cloth.
The D2xC1 is not to be mounted with the horn facing upwards
The equipment shall only be used in end use with appropriately
certified cable entry devices and blanking plugs
4.1 Installation
The product must only be installed by suitably qualified
personnel in accordance with the latest issues of the relevant
standards.
The installation of the units must also be in accordance with
any local codes that may apply and should only be carried out
by a competent electrical engineer who has the necessary
training.
The alarm horn is not to be mounted with the horn facing
upwards.
The equipment has not been assessed as a safety-related
device (as referred to by Directive 94/9/EC Annex II, clause
1.5).
The cable entry temperature may exceed +70ºC / the cable
branching point may exceed 80ºC. Therefore suitable heat
resisting cables and cable glands must be used, with a rated
service temperature of at least 90ºC.
To maintain the ingress protection rating and mode of
protection, the M20 x 1.5 cable entries must be fitted with
suitably rated, certified cable glands and/or suitably rated,
certified blanking devices during installation. If a high IP
sales@e-2-s.com
www.e-2-s.com
Sheet 2 of 7
Nominal Voltage Max
Current Range Current
313mA
313mA 10-30Vdc
@ 24Vdc
218mA
181mA 38-58Vdc
@ 48Vdc
115Vac
91mA @
89mA +/-10%
126.5Vac
60Hz
230Vac
72mA @
52mA +/-10%
253Vac
50Hz
Tel: +44 (0)208 743 8880
Fax: +44 (0)208 740 4200
