LinkPoint AIO Quick Reference Manual

LinkPoint AIO Nashville EBT
Quick Reference Guide
Application: CONFIG 690 01.08.00
FUNCTION DISPLAY MESSAGE
EBT FOOD 1. SWIPE CARD FOR SALE
STAMP SALE
2.
3.
4. EBT
5. FOOD CASH VCHR
6. SALE RET BAL
7. EB FS
8. EB FS
9. EB FS
11. EB FS
12. EB FS
13. EB FS
14. EB FS
15. EB FS
16. AP XXXXX SEQ XXX
FUNCTION DISPLAY MESSAGE
EBT FOOD
1. SWIPE CARD FOR SALE
STAMP
RETURN
2.
3.
4. EBT
5. FOOD CASH VCHR
6. SALE RET BAL
7. EB FS
8. EB FS
9. EB FS
11. EB FS
12. EB FS
13. EB FS
14. EB FS
15. EB FS
16. AP XXXXX SEQ XXX
XXXX 0405
EBT DEBIT
EBT or EBT/DEBIT
ENTER PASSWORD
DEBIT
SALE
ENTER ACCOUNT #
SALE
ENTER AMOUNT
SALE
WAITING FOR PIN...
PIN PAD DISPLAY
10. $XX.XX
PIN=
SALE
ENTER INVOICE #
SALE
ENTER CLERK ID #
SALE
DIALING...
SALE
PRINTING...
SALE
TEAR NOW, PRESS ENTER
EBT DEBIT
EBT or EBT/DEBIT
ENTER PASSWORD
DEBIT
RETURN
ENTER ACCOUNT #
RETURN
ENTER AMOUNT
RETURN
WAITING FOR PIN...
PIN PAD DISPLAY
10. $XX.XX
PIN=
RETURN
ENTER INVOICE #
RETURN
ENTER CLERK ID #
RETURN
DIALING...
RETURN
PRINTING...
RETURN
TEAR NOW, PRESS ENTER
For additional information, please visit our Web site at:
www.linkpoint.com
OPERATOR ACTION
1. Either swipe the EBT card or press the
[ATM/DEBIT] key.
2. If card was swiped, press the middle [ ] key.
3. If prompted, key in the appropriate password,
press [ENTER].
4. Press the left [ ] key.
5. Press the left [ ] key.
6. Press the left [ ] key.
7. Either swipe the EBT card or key in the card
number, press [ENTER].
8. Key in transaction amount, press [ENTER].
9. Please wait...
PIN PAD ACTION
10. Customer keys in PIN and presses [ENTER]
on the PIN pad.
11. Key in invoice number, press [ENTER].
12. Key in the employee ID, press [ENTER].
13. Please wait...
14. Please wait for merchant receipt copy to print.
Tear off the receipt copy.
15. Either press [ENTER] to print a customer
receipt copy or wait for copy to print.
16. Press [CLEAR] to exit.
OPERATOR ACTION
1. Either swipe the EBT card or press the
[ATM/DEBIT] key.
2. If card was swiped, press the middle [ ] key.
3. If prompted, key in the appropriate password,
press [ENTER].
4. Press the left [ ] key.
5. Press the left [ ] key.
6. Press the middle [ ] key.
7. Either swipe the EBT card or key in the card
number, press [ENTER].
8. Key in transaction amount, press [ENTER].
9. Please wait...
PIN PAD ACTION
10. Customer keys in PIN and presses [ENTER]
on the PIN pad.
11. Key in invoice number, press [ENTER].
12. Key in the employee ID, press [ENTER].
13. Please wait...
14. Please wait for merchant receipt copy to print.
Tear off the receipt copy.
15. Either press [ENTER] to print a customer
receipt copy or wait for copy to print.
16. Press [CLEAR] to exit.
©
2005 LinkPoint International, Inc.
