LinkPoint 9000 Tips

LinkPoint 9000 Tips
The LinkPoint 9000 uses a rechargeable nickel cadmium battery as its main
power source. Please note that a new nickel cadmium battery's full performance
is achieved only after two complete charge and discharge cycles. After you
charge a battery for the first time, please use that battery completely before
recharging it. Then, use the battery completely before recharging it again. For
maximum performance, please continue to use battery fully before recharging in
the future.
To charge the LinkPoint 9000 battery:
1. Unpack the charging dock and place on a table or
counter top as shown in Figure 1.
2. Plug the adapter pin into the back of the unit as shown
in Figure 2. Plug the adapter cord into either a surge
protector or a wall power outlet.
3. Charge the battery by either:
♦ Placing the battery into the small charger slot on the
base as shown in Figure 4 (when battery is charged,
press the eject button to release battery); or
♦ Turn the terminal over and slide the uncharged battery
into the terminal. Snap the battery into place as shown
in Figure 5.
♦ Place the terminal on the large charger slot as shown in
Figure 6. Make sure terminal power is off or the unit will
not charge. Never operate terminal while it is on
charging dock, because it will shorten battery life!
4. No matter which method you choose, charge the battery
until the appropriate charge indicator light turns green
as shown in Figure 7.
Figure 1
Figure 2
Eject
Button
Figure 4
Figure 5
Figure 7
Figure 3
Figure 6
