Power amplifier module section
The built-in amplifier module, plus the several connections and controls, are situated at the rear of the
subwoofer. The controls and connections are defined below:
1. Volume control
2. Frequency control (crossover 20-200Hz)
3. Phase switch (0/180 degrees)
4. Input L XLR
5. Input R XLR
6. Input L 6.35mm jack
7. Input R 6.35mm jack
8. Output L XLR
9. Output R XLR
10. Clip limiter LED indicator
11. Power LED indicator
12. 115/230V switch (pre-defined, do not
switch!)
13. IEC power inlet with fuse holder
14. On/off switch
15. Amplifier module heatsink
