- Page 1 Onyx Passive 12S / 15S / 18S Passive subwoofer User manual The information in this user manual is subject to change at any time without notice. Version: Date of creation and author's initials:23-09-2017 RV Revision date and author's initials: -...
- Page 2 Introduction Thank you for purchasing this Devine Onyx passive subwoofer. We advise that you read this user manual in its entirety before unpacking the contents of the box, so that you are familiar with all of the functionality that this product has to offer. Please be sure to check that all of the parts and accessories listed below under 'box contents' are included in the package.
-
Page 3: Safety Instructions
Safety instructions WARNING! Keep this device away from moisture, water and rain to avoid the chance of electric shocks. Everyone involved with the installation, operation and maintenance of this device must: - Be qualified - Be skilled - Have read the instructions in this user manual - Be sure that neither the device nor the included accessories are damaged. - Page 4 - Should the device not be used in the manner described in this user manual, damages or even injuries could occur. Devine cannot be held responsible for any injuries or damages that occur as a result of improper use of this product.
- Page 5 Guidelines and operation of this device 1. speaker input via 4-pin lockable speaker connector 2. speaker parallel output via 4-pin lockable speaker connector 3. handle (varies per model) 4. M20 screw thread flange for speaker pole 5. bass reflex ports 66.
-
Page 6: Operating The Device
WARNING The Devine Onyx passive subwoofers are not equipped with a built-in filter or crossover. These subwoofers are not suitable for full-frequency (20 - 20,000 Hz) reproduction. Always use an external signal processor or crossover to ensure that only low frequencies are sent to these subwoofers. -
Page 7: Audio Technology
The grille should therefore not be removed. Speaker pole mount The Devine Onyx subwoofers are equipped with a pole mount with an M20 screw thread. This means that a suitable speaker pole can be screwed in securely to provide a stable platform for mounting a full-range speaker on top. - Page 8 Speaker troubleshooting guide If you have a problem with your speaker, please consult this troubleshooting section for possible solutions. If, after consulting this section, the problem remains unresolved, please contact your dealer for more information and/or help. This troubleshooting section contains information on how to solve the most common speaker problems, but it does not and cannot cover every eventuality.
-
Page 9: Specifications
Specifications General specifications for all models: – robust subwoofer in strong plywood housing – available in 12, 15 and 18 inches – metal grille – acoustic foam behind grille to prevent any unwanted matter from getting inside the speaker – grille covers the front of the subwoofer for optimal protection –...
