IA25U Rear Panel

1.Power Supply:
Use the power cord to provide with the unit . Before connecting it to the outlet, be sure
the power of the IA25U is off.
2.Power Switch:
Voltage selector. Select between 230V AC 50Hz / 115V AC 65Hz.
3.Main Output:
Connect your speakers to these speaker outputs. The IA25U should be powered off and
volume levels turned down when making these connections.
4.LINE Output:
Connect the line output to the input on either a recording device or another amplifier. The
signal from the line output is a passive output and can not be connected directly to a passive speaker.
5.DVD Input:
Connect any stereo signal such as a DVD, CD, TAPE, Mixer etc to this input. To play a
signal connected to this input make sure the DVD input is selected on the front panel.
6.AUX Input:
Connect any stereo signal such as a DVD, CD, TAPE, Mixer etc to this input. To play a
signal connected to this input make sure the AUX input is selected on the front panel.
6 5 4 3
IA25U
2 1
5
