Specifications

Pressure ranges
Pressure types
Uncertainty
Optional Intelliscale Uncertainty
Optional barometer uncertainty
Compensated temperature range
Calibration interval
Pressure units: English
Pressure units: Metric
Pressure units user defined
Slew rate
Overshoot
Control stability
Pressure ports
Filter elements
Permissible pressure media
Parts exposed to pressure media
Overpressure protection
Instrument mounting
Display
Resolution
Warm-up time
Digital interface
Power supply
Maximum pressure, supply port
Pneumatic overpressure protection
Operating temperature
Storage temperature
Air humidity
Operating position
Weight
Dimensions
CE-mark
Calibration
Data Sheet CPC3000
CPC 3000
Gauge: 0 ... 5 up to 0 ... 1500 psig (0 ... 0.35 to 0 ... 103 bar)
Absolute: 0 ... 14.5 to 0 ... 1515 psia (0 ... 1 to 0 ... 104 bar)
Bi-directional: 5 ≤ span ≤ 1515
Absolute, gauge or bi-directional ranges
0.025% full span for all standard pressure ranges specified above. Uncertainty (k=2) includes
hysteresis, linearity, repeatability, reference standard, drift and temperature effects over the calibrated
range for the calibration interval specified, with periodic re-zeroing.
Transducer Range (psig)
0 ... 14.5 to 0 ... 1500
Transducer Range (psia)
0 ... 14.5 to 0 ... 1515
Transducer Range (psi)
-15 ... 145 to -15 ... 1500
5 ≤ span < 145
(1) 0.025% IntelliScale-50 (0.025% IS-50): Uncertainty from Min to 50% of Max = (0.025% x 50%
x Max) or 0.025% of Reading from 50% to 100% of Max.
0.02% R from 8.5 to 17 psia for 365 days
°C
15 to 45
days
365
psi, psf, oz/si, tons/sq in, tons/sq ft, atm, inHg @0C, inHg @60F, mTorr, Torr, inSW, ftSW, inH2O @4C,
inH2O @20C, inH2O @60F, ftH2O @4C, ftH2O @20C, ftH2O @60F
mbar, bar, g/sq cm, kg/sq cm, dyn/sq cm, pascal, hPa, kPa, MPa,
mmHg @0C, cmHg @0C, mHg 0C, mSW, mmH2O @4C, cmH2O @4C, mH2O @4C, mmH2O @20C,
cmH2O @20C, mH2O @20C
2 (multiplier from psi or Pascal)
3 seconds to stable flag (+/-0.025% full scale pressure) for a 10% pressure change typical into
150cc volume at pressures greater than 5 PSI. Larger volumes can lengthen this time. Controlling to
pressures less than atmosphere can lengthen this time.
% FS,
<1 in high speed mode
0.003% of range
7/16-20 Female SAE threaded ports for Measure/Control, Exhaust, Reference, and Supply.
Barometric Reference port is a hose barb.
40 micron filter element included in each pressure port (excluding the optional barometer and the
reference port on a gauge sensor)
Clean, dry, non-corrosive gases
6000 series aluminum, 316 SS, brass, Teflon, Urethane, Silicone, RTV, Silicone grease, PVC, Epoxy, Ceramics
Pressure relief valves
Desk top with bezel and handle, or optional rack mount kit.
7.0" color LCD
Six significant digits
min
approx. 15
IEEE-488, Ethernet, USB
100 - 240 VAC, 50/60 Hz, 700 mA max
110 ... 120 %FS
internal relief valves
°C
0 ... 50
°C
0 ... 70
0 ... 95 (% relative humidity without moisture condensation)
Negligible, can be removed with re-zeroing
<20 lbs.(<9.1 kg) with all internal options
5¼ h x 8⅜ w x 12 d in (133 x 213 x 305 mm)
Conformity certificate
NIST traceable calibration certificate included, A2LA certification
Gauge
Total Uncertainty (cal interval)
(1)
0.025% IS-50 (365 days)
(1)
Absolute
Total Uncertainty (cal interval)
(1)
0.025% IS-50 (365 days)
(1)
Bi-directional
Total Uncertainty (cal interval)
(1)
0.025% IS-50 (365 days)
(1)
0.025% of Full Span (365 days)
