Power to electret mic: +9V DC
•
limiter range (both mics): 30 dB
•
Speaker Driver Amp
Max. output power: 1.7 Wrms @ 16 Ω
•
Buzzer
Max. SPL: 85 dBA @ 0.1m
•
Headphone Driver Amps
Max output level:
•
monaural:
binaural:
Max output power:
•
monaural:
binaural:
Null Adjust
Rejection: 0 - 30dB adjustable
•
Program & AUX Inputs
input impedance: 2.4 kΩ
•
nominal input level: 0 dBu
•
max. input level: +21 dBu
•
Stage Announce Output
output impedance: 50 Ω (balanced)
•
nominal Output Level: 0 dBu
•
max. Output Level: +21 dBu
•
Dimensions & Weight
width: 420 mm / height: 88 mm
•
depth: 220 mm / weight: 4800 gram
•
DC input:
Supply Voltage: 24 – 30 V DC
•
0 dB is defined as 775 mV into open circuit
16 V rms @ 200 Ω
2x 10.3 V rms @ 400 Ω
1.3 W rms @ 200 Ω
2x 0.27 W rms @ 400 Ω
