Introduction
CHAPTER 1
Introduction
Introduction
Introduction
Introduction
The ROBO-667 all-in-one single board computer is designed to fit a high
performance Pentium-III based CPU and compatible for high-end computer
system with PCI/ISA Bus architecture. It is made to meet today's demanding
pace, and keep complete compatibility with hardware and software
designed for the IBM PC/AT.
performance system for VARs, or system integrators. The on-board 3D
Graphics display, and fast Ethernet interface will bring full functionality and
high performance to all segments of the industrial PC market.
This single board computer runs with dual Intel Pentium-III (FC-PGA & FC-
PGA2) processors, and supports DIMM up to 1.5 GB SDRAM.
enhanced on-board PCI IDE interface can support 4 drives up to PIO mode 4
timing and Ultra DMA/33/66/100 synchronous mode feature. The on-
board Super I/O integrates one floppy controller, two serial ports, one
keyboard controller, one hardware monitor, one IrDA port and one parallel
port. Two high performance 16C550-compatible UARTs provide 16-byte
transmit/receive FIFOs, and the multi-mode parallel port supports
SPP/EPP/ECP function. Besides, three USB (Universal Serial Bus) ports
provide high-speed data communication between peripherals and PC. PCI
type daughter board can also be compatible to ROBO-667.
The PICMG standard makes the ROBO-667 work with the legacy ISA,
ISA/PCI or multi-slots PCI-bus backplane. The on-board 32-pin DIP socket
supports M-systems DiskOnChip 2000 product up to 288MB. The Watch-
Dog Timer function can be used to monitor your system status. One 6-pin
Mini-DIN connector (with Y-Cable) is provided to connect PS/2 Mouse and
Keyboard. The on-board Flash ROM is used to make the BIOS update
easier.
Two standard 5-1/4" drive power connectors are reserved to
directly get more power energy for big power applications, and the
additional 5-pin shrouded connector is reserved for connecting Keyboard
interface on the backplane. One 4-pin header is designed to support ATX
ROBO-667 User's Manual
It is beneficial to build up a high
The
1-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROBO-667 and is the answer not in the manual?

Questions and answers

Related Manuals for Portwell ROBO-667

Summary of Contents for Portwell ROBO-667

  • Page 1 Introduction Introduction Introduction The ROBO-667 all-in-one single board computer is designed to fit a high performance Pentium-III based CPU and compatible for high-end computer system with PCI/ISA Bus architecture. It is made to meet today’s demanding pace, and keep complete compatibility with hardware and software designed for the IBM PC/AT.
  • Page 2 Introduction power function. All of these features make ROBO-667 excellent in stand- alone applications. 1 1 1 1 - - - - 1 Check List 1 Check List 1 Check List 1 Check List The ROBO-667package should cover the following basic items accompany with this manual.
  • Page 3 Support one FDD port up to two floppy drives and 5-1/4"(360K, 1.2MB), 3-1/2" (720K, 1.2MB, 1.44MB, 2.88MB) diskette format and 3-mode FDD • Serial Ports Support two high-speed 16C550 compatible UARTs with 16-byte T/R FIFOs • IR Interface Support one 6-pin header for serial Standard Infrared wireless communication ROBO-667 User’s Manual...
  • Page 4 Intel 82559 LAN controller to support RJ-45 interface at 10/100 Base-T speed • On-board 68-pin PCI device connector Support one additional PCI device daughter board • High Driving Capability Support 64mA high driving capability for multi-slots ISA-bus ROBO-667 User’s Manual...
  • Page 5 PCB layout : 8 layer Power Requirements : +5V @15A , +12V @200mA Operating Temperature : 0°C ~ 55°C ( 32°F ~ 131°F ) Storage Temperature : -20°C ~ 75°C Relative Humidity : 5% 〜 95%, non-condensing ROBO-667 User’s Manual...
  • Page 6 3 System Architecture 3 System Architecture 3 System Architecture The following illustration will show you how ROBO-667 gives you a highly integrated system solution. The most up-to-date system architecture of ROBO-667 includes three main VLSI chips, VIA VT82C694T,VT82C686B and ATI Rage-Mobility M/M1, to support Pentium-III (FC-PGA/FC-PGA2)
  • Page 7 Introduction All of details of operating relations are shown in Figure 1-1 ROBO-667 System Block Diagram. Figure 1-1 ROBO-667 System Block Diagram ROBO-667 User’s Manual...
