- Page 1 USER MANUAL i3HUDDLE...
-
Page 3: User Manual
USER MANUAL 75" Please read this guide carefully before operating your set and retain it for future reference. CAUTION! ƒ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 4: Table Of Contents
Getting Started Contents Safety Information ---------------------------------------------------- Unique features, Accessories -------------------------------------- Components ----------------------------------------------------------- Installation Guide ---------------------------------------------------- Connections ----------------------------------------------------------- Remote Controller ---------------------------------------------------- Power on/off ----------------------------------------------------------- Android Screen -------------------------------------------------------- Touch On Screen Display(OSD) ----------------------------------- IFTD Settings in Android -------------------------------------------- External Devices and Touch Functions ------------------------- Network, Update &... -
Page 5: Safety Information
Important Safety Instructions The illustrations may differ slightly from the items shipped with your product. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT THERE IS A RISK OF EXPLOSION OR FIRE IF THE REMOVE t h e COVER (OR BACK). - Page 6 GETTING STARTED Do not expose this product to rain or place it near water or in a wet environment (near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool etc.). If this product accidentally gets wet, unplug it and contact an authorized dealer immediately.
- Page 7 GETTING STARTED Be sure to contact an authorized service center, when installing your product in a location with heavy dust, high or low temperatures, high humidity, chemical substances and where it operates continuously for 24 hours such as an airport, a train station etc. Failure to do so may cause serious damage to your product.
- Page 8 GETTING STARTED FCC Information to Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 9: Unique Features, Accessories
GETTING STARTED Unique features 1) UHD LED Display 2) HDMI 2.0 / Display Port 3) Touch Sensor : PCAP 4) Full Touch OSD 5) HOME Button 6) Dual OS Support : Windows (Via OPS) and HUDDLE LAUNCHER (Main) Accessories AC Power Cable Quick Manual Stylus * 2 i3 Charging Cradle... -
Page 10: Components
GETTING STARTED Introduction Symbols used in this manual Note Indicates special notes and operating features. Caution Indicates cautions for preventing possible damage from abuse or mistreatment of the product. Components Front View Rear View Touch Screen Main Board Cover I/O Ports Home Button Antena Side View(left) -
Page 11: Installation Guide
GETTING STARTED Installation Guide Step 1 Install the wall mount brackets on to the wall. Step 2 Install the wing brackets on the back of the product. (Use 4 x M8 screws) Step 3 Install the product as shown in the diagram. -
Page 12: Connections
GETTING STARTED Connections 1. AC INPUT Connect the power cable to this AC input. 2. LAN Connect an ethernet cable for Local Area Network use. 3. SB Connect the i3 SoundBar Connect an RS232C control device here. 4. RS232C 5. USB Connect USB for Media. -
Page 13: Remote Controller
GETTING STARTED 3.Antena 1. Home Key 2. LED illumination 4. Sound Bar 1. Home Key Easy navigation : Power on -> Blue Powered on : White 2. LED illumination Wifi Antena 3. Antena 4. Soundbar Mute on/off, Volume + -, Fuction... -
Page 14: Power On/Off
OPERATION Power On/Off 1. Connect the AC power cable to the AC power inlet. Click 2. Press the Power Button... -
Page 15: Android Screen
OPERATION Home Screen After turning on the display, the i3HUDDLE Home Screen will appear. 1. Default App i3NOTES: Basic Annotation app i3SYNC: Wireless Presenting app i3MEETINGHUB: Collaborating annotation app 2.Admin App Internet Browser app Video Conference app 3. Meeting Schedule setting Link to Outlook 365 4. -
Page 16: Touch On Screen Display(Osd)
OPERATION Settings You can access the settings in i3HUDDLE by selecting ‘settings’ and found 5 settings menu Network settings LIVE 4 PIP shows 4 input sources in one screen at the same time. Touch one of the input source screens to change to that input source. -
Page 17: Iftd Settings In Android
”When the option is turned on, you’ll see one of the following notifications: Portable Wi-Fi hotspot active Ethernet Settings Ethernet Connections: Make sure you connect a LAN cable to the designated port in the i3HUDDLE (As shown below) Automatically setting up the IP address by DHCP (Dynamic Host Configuration Protocol) -
Page 18: External Devices And Touch Functions
4. You can also use your own background by USB data Insert USB (Contain Mp4 video (less than 10mb) or image) to the designated USB ports in the back side of i3HUDDLE Date & time Settings You can easily set date and time on i3 Huddle. You can also choose to manuall set date and time, based on network provided time zone or select time zone by your own. -
Page 19: Network, Update & Language Settings
To change the language in i3HUDDLE, Select ‘Language in the display settings Input Methods To change the input method in i3HUDDLE, Select ‘Input Methods’ in the display settings Show Soft Key Depends you user’s preference, digital home key can be activated on the screen Screen Position You can adjust i3HUDDLE screen position in the display settings >... - Page 20 Operation i3HUDDLE Player update You can update i3HUDDLE Player firmware if there is new version updated. - Make sure your network available Reset & Password Reset to Factory settings You can remove all data from your i3 HUDDLE device by resetting it to factory settings Change Password If you want to change the password, put new password and confirm new password.
-
Page 21: Specification
Operation Network Settings, Software Updates & Language Options Network Settings You can access the IFTD's Android Network Settings by selecting the 'Settings' option in the Menu & Navigation bar. - Ethernet Connection: Connect a LAN cable to the designated port in the IFTD (as shown above). Ethernet connection options can then be altered in Android and Windows according to network specifications. -
Page 22: Panel Information
Appendix Panel Information Diagonal Size 75" Optimal Resolution Ultra HD 3840 * 2160@60Hz Back Light Unit E-Led Response Time 8.0M/s (Typ G to G) Viewing Angle H:178º / V178º Contrast Ratio 1200:1 (Typ) Brightness 410CD/m2 Touch Information Touch Technology Surface Projected Capacitive Touch Module Simultaneous Touch points 40 Points Touch Accuracy... -
Page 23: Accessory Kit
Appendix Features Diagonal Size 75" Dual OS Support Window Support Yes(VIA OPS) App Store Support Yes(Via i3 Store) Home Button Sound bar Wireless Presenting Yes(i3 sync) Accessory kit Diagonal Size 75" AC Power Cable Passive Stylus Pen Holder i3 Sync Touch Transmitter i3 Sync Charging Cradle User Guide Connection Information... -
Page 24: Environmental Information
Appendix Environmental Information Diagonal Size 75" Operating 0°C~40°C Temperature Storage Temperature -10°C~60°C Operating Humidity ~80% Storage Humidity ~90% Mechanical Information Diagonal Size 75" Outline Dimensions 1,739mm * 80mm * 1,037.2mm Packaged Outline 1.935mm * 295mm * 1,290mm Dimension Product Weight 101Kg (W i3 sound bar) 95Kg (W/O i3 sound bar) Gloss Weight 115kg... - Page 25 Appendix i3 Huddle Dimensions...
- Page 26 Date of Purchase www.i3huddle.com...
